Brush bristle length 5-inch/ 127 mm
Brush design description Double bristle row, ABS core; spiral patterned
Brush diameter 2.5-inch/ 65 mm
Brush length 24-inch/ 610 mm
Brush motor amps 1 A
Brush motor power 0.2 hp/ 0.15 kW
Brush motor RPM 1800 rpm
Brush motor type Permanent magnet DC, circuit breaker protected
Brush motor voltage 120 V
Brush RPM 1200 rpm
Airflow at orifice 101 cfm/ 2.86 m³/h
Waterlift at orifice 114-inch/ 2895 mm
Vacuum motor amps 10 A
Vacuum motor diameter 5.7-inch/ 145 mm
Vacuum motor power 1.57 hp/ 1.17 kW
Vacuum motor stages 2 stage
Vacuum motor voltage 120 V
Vacuum motor type Thru-flow, thermally protected w/ auto reset, UL recognized
Vacuum bag description 99.9% efficiency for particles of .3 micron
Vacuum bag filtration description
Optional Clean Air Exhaust Filter-99% efficiency at 0.3 microns.
Capacity: 1/3 bushel/ 10L. Optional cloth bag available-98% efficiency
at 0.3 microns.
Length 19-inch/ 480 mm
Machine Width 26-inch/ 660 mm
Height 44-inch/ 1117 mm
Weight 44 lb/ 19.96 kg
Chassis construction Rotationally-molded polyethylene
Metal parts coating Zinc & chrome plating, epoxy powder coat
Power cord length 50 ft/ 15.24 m
Power cord type 16 gauge, 3-wire, SJTO, non-marking safety yellow w/
grounded plug. Recognized by UL
Power consumption amps 11 A
Power consumption voltage & watts 120 V, 1320 watts
Ten foot/ 3 m decibel 66 dBa
Five foot/ 1.5 m decibel 68 dBa
Operator position 73 dBa
Tennant 3260 Parts and Support
brush bristle diameter 0.008-inch/ 0.20 mm
brush bristle length 5-inch/ 127 mm
brush design description double bristle row, abs core; spiral patterned
brush diameter 2.5-inch/ 65 mm
brush length 24-inch/ 610 mm
brush motor amps 1 a
brush motor power 0.2 hp/ 0.15 kw
brush motor rpm 1800 rpm
brush motor type permanent magnet dc, circuit breaker protected
brush motor voltage 120 v
brush rpm 1200 rpm
airflow at orifice 101 cfm/ 2.86 m³/h
waterlift at orifice 114-inch/ 2895 mm
vacuum motor amps 10 a
vacuum motor diameter 5.7-inch/ 145 mm
vacuum motor power 1.57 hp/ 1.17 kw
vacuum motor stages 2 stage
vacuum motor voltage 120 v
vacuum motor type thru-flow, thermally protected w/ auto reset, ul recognized
vacuum bag description 99.9% efficiency for particles of .3 micron
vacuum bag filtration description
optional clean air exhaust filter-99% efficiency at 0.3 microns.
capacity: 1/3 bushel/ 10l. optional cloth bag available-98% efficiency
at 0.3 microns.
length 19-inch/ 480 mm
machine width 26-inch/ 660 mm
height 44-inch/ 1117 mm
weight 44 lb/ 19.96 kg
chassis construction rotationally-molded polyethylene
metal parts coating zinc & chrome plating, epoxy powder coat
power cord length 50 ft/ 15.24 m
power cord type 16 gauge, 3-wire, sjto, non-marking safety yellow w/
grounded plug. recognized by ul
power consumption amps 11 a
power consumption voltage & watts 120 v, 1320 watts
ten foot/ 3 m decibel 66 dba
five foot/ 1.5 m decibel 68 dba
operator position 73 dba
brush bristle length 5-inch/ 127 mm
brush design description double bristle row, abs core; spiral patterned
brush diameter 2.5-inch/ 65 mm
brush length 24-inch/ 610 mm
brush motor amps 1 a
brush motor power 0.2 hp/ 0.15 kw
brush motor rpm 1800 rpm
brush motor type permanent magnet dc, circuit breaker protected
brush motor voltage 120 v
brush rpm 1200 rpm
airflow at orifice 101 cfm/ 2.86 m³/h
waterlift at orifice 114-inch/ 2895 mm
vacuum motor amps 10 a
vacuum motor diameter 5.7-inch/ 145 mm
vacuum motor power 1.57 hp/ 1.17 kw
vacuum motor stages 2 stage
vacuum motor voltage 120 v
vacuum motor type thru-flow, thermally protected w/ auto reset, ul recognized
vacuum bag description 99.9% efficiency for particles of .3 micron
vacuum bag filtration description
optional clean air exhaust filter-99% efficiency at 0.3 microns.
capacity: 1/3 bushel/ 10l. optional cloth bag available-98% efficiency
at 0.3 microns.
length 19-inch/ 480 mm
machine width 26-inch/ 660 mm
height 44-inch/ 1117 mm
weight 44 lb/ 19.96 kg
chassis construction rotationally-molded polyethylene
metal parts coating zinc & chrome plating, epoxy powder coat
power cord length 50 ft/ 15.24 m
power cord type 16 gauge, 3-wire, sjto, non-marking safety yellow w/
grounded plug. recognized by ul
power consumption amps 11 a
power consumption voltage & watts 120 v, 1320 watts
ten foot/ 3 m decibel 66 dba
five foot/ 1.5 m decibel 68 dba
operator position 73 dba
