- Batteries, Brushes, and Chargers

Click to enlarge

Part	Description	Req	Notes
162-0003	6V 225Ah wet battery (SNSR)	6
162-0005	6V 305Ah wet battery (SNSR)	6
162-0043	6V 224Ah AGM battery (Group GC2) (SNSR)	6
162-0046	6V 335Ah AGM battery (Group J305) (SNSR)	6
202-2310	36V 25amp battery charger	1
202-2148	36V 30amp wet SCR battery charger with large SB175 gray plug	1
202-8241	Charger, 36V,25A Onboard, Universal Charger w/Power Cord	1
202-7697	Charger, 36V,33A Onboard, Universal Charger w/Power Cord	1
202-5932	Brush,Super-Grit,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6124	Brush, Super-Grit, 15 inch , Green Block Used 30 inch Deck	2	(15 inch)
996-3218	17 inch super grit brush (green block)	2	(17 inch)
202-5931	Brush,Tough-Grit,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6123	Brush,Tough-Grit,15 inch, Green Block Used on 30 inch Deck	2	(15 inch)
996-3219	17 inch tough grit brush (green block)	2	(17 inch)
202-5917	Brush,Midi-Grit,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6113	Brush,Midi-Grit,15 inch, Green Block Used on 30 inch Deck	2	(15 inch)
202-5725	17 inch midi-grit brush (green block)	2	(17 inch)
202-5930	Brush,Light-Grit,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6122	Brush,Light-Grit,15 inch, Green Block Used on 30 inch Deck	2	(15 inch)
996-3220	17 inch light grit brush (green block)	2	(17 inch)
202-5929	Brush,Poly,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6121	Brush, 15 inch, Poly, Green Block Used on 30 inch Deck	2	(15 inch)
202-4196	17 inch polypropelene brush (green block)	2	(17 inch)
202-5926	Brush,Nylon,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6119	Brush,Nylon,15 inch, Green Block Used on 30 inch Deck	2	(15 inch)
996-3221	17 inch nylon brush (green block)	2	(17 inch)
202-5933	Brush,Tampico,13 inch, Green Block Used on 26 inch Deck	2	(13 inch)
202-6125	Brush,Tampico,15 inch, Green Block Used on 30 inch Deck	2	(15 inch)
996-3222	17 inch Tampico brush (green block)	2	(17 inch)
202-5924	Pad Driver, 13 inch, Green Block Snap on Retainer, Used on 2	2	(13 inch)
202-6117	Pad Driver, 15 inch, Green Block Used on 30 inch Deck	2	(15 inch)
996-3223	17 inch pad driver (green block)	2	(17 inch)
202-5925	Pad Driver,13 inch SNAP Diamond Polishing, Green Block, Used	2	(13 inch)
202-6118	Pad Driver, 15 inch SNAP Diamond Driver, Green Block Used on	2	(15 inch)
996-3224	17 inch diamond driver (green block)	2	(17 inch)
202-3929	13 inch super black pad (pkg of 5)	2	(13 inch)
202-5934	Floor Pads, 13 inch Black - Case of 5 pads	2	(13 inch)
202-6128	Floor Pads, 15 inch Black - Case of 5 pads	2	(15 inch)
202-6278	Floor Pads, 17 inch Black - Case of 5 pads	2	(17 inch)
202-3931	13 inch brown pads (pkg of 5)	2	(13 inch)
202-3933	13 inch green pads (pkg of 5)	2	(13 inch)
202-5935	Floor Pads, 13 inch Blue - Case of 5 pads	2	(13 inch)
202-3936	13 inch red pad (pkg of 5)	2	(13 inch)
202-3938	13 inch white pad (pkg of 5)	2	(13 inch)
202-7139	Brush, Cylindrical, 27 inch Tough-Grit Used on 29 inch Deck	1
202-7136	Brush, Cylindrical, 27 inch Midi-Grit Used on 29 inch Deck	1
202-7138	Brush, Cylindrical, 27 inch Light Grit Used on 29 inch Deck	1
202-4351	27 inch fine grit cylindrical brush (OBSOLETE)	1
202-7137	Brush, Cylindrical, 27 inch Nylon Used on 29 inch Deck	1
202-7140	Brush, Cylindrical, 27 inch Tampico Used on 29 inch Deck	1
202-9023	Pad, 14 inch X 28 inch, White - Case of 5	1
202-9022	Pad, 14 inch X 28 inch, Red - Case of 5	1
202-9021	Pad, 14 inch X 28 inch, Blue - Case of 5	1
202-9020	Pad, 14 inch X 28 inch, Green - Case of 5	1
202-9019	Pad, 14 inch X 28 inch, Black - Case of 5	1
202-9027	Pad 14 inch X 28 inch White Sand Paper Driver, Case of 10	1
202-7390	HD Non Woven Polishing Pad 400 Grit 20 inchx14 inch - 1/ea	1
202-7391	HD Non Woven Polishing Pad 800 Grit 20 inchx14 inch - 1/ea	1
202-7387	HD Non Woven Polishing Pad 1500 Grit 20 inchx14 inch - 1/ea	1
202-7389	HD Non Woven Polishing Pad 3000 Grit 20 inchx14 inch - 1/ea	1
202-9035	Diamond Poly Pad 6000Grit14x20 Case of 5(OBSOLETE)	1
202-9018	Tile / Grout Renovator Pad 28 inch, Blue	1
202-9024	Hi-Output Strip Pad , 14 inch X 28 - Case of 5	1
202-9025	Prep Pad, 14 inch X 28 inch - Case of 10	1

- Frequently Replaced Parts

Click to enlarge

Part	Description	Req	Notes
162-0003	6V 225Ah wet battery (SNSR)	6
162-0005	6V 305Ah wet battery (SNSR)	6
162-0043	6V 224Ah AGM battery (Group GC2) (SNSR)	6
162-0046	6V 335Ah AGM battery (Group J305) (SNSR)	6
202-2310	36V 25amp battery charger	1
202-2148	36V 30amp wet SCR battery charger with large SB175 gray plug	1
202-8241	Charger, 36V,25A Onboard, Universal Charger w/Power Cord	1
202-7697	Charger, 36V,33A Onboard, Universal Charger w/Power Cord	1
202-2300	Key switch with key entry (red) and ring (black)	2
202-3623	Key switch	1
991-1634	Key (pkg of 2)	3
202-3624	Manager lockout key (pkg of 2)	1
202-1992	Toggle switch	9
202-0097	Toggle switch	1
202-3127	4 inch chain (6 inch no longer available)	1
202-1897	Steering chain	1
202-0283	Master link	1
202-3038	36V solenoid valve	1
202-3772	36V solenoid valve	1
202-3584	Inline filter	1
202-9782	Filter screen (black)	1
202-3690	Squeegee blade 31 inch linatex front v2.1	1	(front blade v2.0)
202-3662	Squeegee blade 31 inch linatex rear v2.1	1	(rear blade v2.0)
202-3691	Squeegee blade 33 inch linatex front	1	(front blade v2.0)
302-0244	Squeegee blade 33 inch linatex rear	1	(rear blade v2.0)
202-3692	Squeegee blade 37 inch linatex front	1	(front blade v2.0)
202-3664	Squeegee blade 37 inch linatex rear	1	(rear blade v2.0)
202-9611	Squeegee blade front linatex	1	(front blade v2.0)
202-3694	Squeegee blade 45 inch linatex front	1	(front blade v2.0)
202-3666	Squeegee blade 45 inch linatex rear	1	(rear blade v2.0)
202-5710	Squeegee vacuum hose 1.5 x 55 inch	1
202-5655	Tank lid assembly	1
202-5650	Rubber gasket	1
202-3785	Recovery drain hose w/ turn cap	1
202-9684	36V 2 stage vacuum motor	1
202-5932	Brush,Super-Grit,13 inch, Green Block Used on 26 inch Deck	2
202-6124	Brush, Super-Grit, 15 inch , Green Block Used 30 inch Deck	2
996-3218	17 inch super grit brush (green block)	2
202-5931	Brush,Tough-Grit,13 inch, Green Block Used on 26 inch Deck	2
202-6123	Brush,Tough-Grit,15 inch, Green Block Used on 30 inch Deck	2
996-3219	17 inch tough grit brush (green block)	2
202-5917	Brush,Midi-Grit,13 inch, Green Block Used on 26 inch Deck	2
202-6113	Brush,Midi-Grit,15 inch, Green Block Used on 30 inch Deck	2
202-5725	17 inch midi-grit brush (green block)	2
202-6113	Brush,Midi-Grit,15 inch, Green Block Used on 30 inch Deck	2
202-5725	17 inch midi-grit brush (green block)	2
202-5930	Brush,Light-Grit,13 inch, Green Block Used on 26 inch Deck	2
202-6122	Brush,Light-Grit,15 inch, Green Block Used on 30 inch Deck	2
996-3220	17 inch light grit brush (green block)	2
202-5929	Brush,Poly,13 inch, Green Block Used on 26 inch Deck	2
202-6121	Brush, 15 inch, Poly, Green Block Used on 30 inch Deck	2
202-4196	17 inch polypropelene brush (green block)	2
202-5926	Brush,Nylon,13 inch, Green Block Used on 26 inch Deck	2
202-6119	Brush,Nylon,15 inch, Green Block Used on 30 inch Deck	2
996-3221	17 inch nylon brush (green block)	2
202-5933	Brush,Tampico,13 inch, Green Block Used on 26 inch Deck	2
202-6125	Brush,Tampico,15 inch, Green Block Used on 30 inch Deck	2
996-3222	17 inch Tampico brush (green block)	2
202-5924	Pad Driver, 13 inch, Green Block Snap on Retainer, Used on 2	2
202-6117	Pad Driver, 15 inch, Green Block Used on 30 inch Deck	2
996-3223	17 inch pad driver (green block)	2
202-5925	Pad Driver,13 inch SNAP Diamond Polishing, Green Block, Used	2
202-6118	Pad Driver, 15 inch SNAP Diamond Driver, Green Block Used on	2
996-3224	17 inch diamond driver (green block)	2
202-3929	13 inch super black pad (pkg of 5)	2
202-5934	Floor Pads, 13 inch Black - Case of 5 pads	2
202-6128	Floor Pads, 15 inch Black - Case of 5 pads	2
202-6278	Floor Pads, 17 inch Black - Case of 5 pads	2
202-3931	13 inch brown pads (pkg of 5)	2
202-3933	13 inch green pads (pkg of 5)	2
202-5935	Floor Pads, 13 inch Blue - Case of 5 pads	2
202-3936	13 inch red pad (pkg of 5)	2
202-3938	13 inch white pad (pkg of 5)	2
202-7139	Brush, Cylindrical, 27 inch Tough-Grit Used on 29 inch Deck	1
202-7136	Brush, Cylindrical, 27 inch Midi-Grit Used on 29 inch Deck	1
202-7138	Brush, Cylindrical, 27 inch Light Grit Used on 29 inch Deck	1
202-4351	27 inch fine grit cylindrical brush (OBSOLETE)	1
202-7137	Brush, Cylindrical, 27 inch Nylon Used on 29 inch Deck	1
202-7140	Brush, Cylindrical, 27 inch Tampico Used on 29 inch Deck	1
202-9023	Pad, 14 inch X 28 inch, White - Case of 5	1
202-9022	Pad, 14 inch X 28 inch, Red - Case of 5	1
202-9021	Pad, 14 inch X 28 inch, Blue - Case of 5	1
202-9020	Pad, 14 inch X 28 inch, Green - Case of 5	1
202-9019	Pad, 14 inch X 28 inch, Black - Case of 5	1
202-9027	Pad 14 inch X 28 inch White Sand Paper Driver, Case of 10	1
202-7390	HD Non Woven Polishing Pad 400 Grit 20 inchx14 inch - 1/ea	1
202-7391	HD Non Woven Polishing Pad 800 Grit 20 inchx14 inch - 1/ea	1
202-7139	Brush, Cylindrical, 27 inch Tough-Grit Used on 29 inch Deck	1
202-7136	Brush, Cylindrical, 27 inch Midi-Grit Used on 29 inch Deck	1
202-7138	Brush, Cylindrical, 27 inch Light Grit Used on 29 inch Deck	1
202-4351	27 inch fine grit cylindrical brush (OBSOLETE)	1
202-7137	Brush, Cylindrical, 27 inch Nylon Used on 29 inch Deck	1
202-7140	Brush, Cylindrical, 27 inch Tampico Used on 29 inch Deck	1
202-9023	Pad, 14 inch X 28 inch, White - Case of 5	1
202-9022	Pad, 14 inch X 28 inch, Red - Case of 5	1
202-9021	Pad, 14 inch X 28 inch, Blue - Case of 5	1
202-9020	Pad, 14 inch X 28 inch, Green - Case of 5	1
202-9019	Pad, 14 inch X 28 inch, Black - Case of 5	1
202-9027	Pad 14 inch X 28 inch White Sand Paper Driver, Case of 10	1
202-7390	HD Non Woven Polishing Pad 400 Grit 20 inchx14 inch - 1/ea	1
202-7391	HD Non Woven Polishing Pad 800 Grit 20 inchx14 inch - 1/ea	1
202-7387	HD Non Woven Polishing Pad 1500 Grit 20 inchx14 inch - 1/ea	1
202-7389	HD Non Woven Polishing Pad 3000 Grit 20 inchx14 inch - 1/ea	1
202-9035	Diamond Poly Pad 6000Grit14x20 Case of 5(OBSOLETE)	1
202-9018	Tile / Grout Renovator Pad 28 inch, Blue	1
202-9024	Hi-Output Strip Pad , 14 inch X 28 - Case of 5	1
202-9025	Prep Pad, 14 inch X 28 inch - Case of 10	1

- Pad Holders

Click to enlarge

#	Part	Description	Notes
1	991-2214	Center-Lok II pad holder - left hand thread (red)
2a	991-2201	Center-Lok II pad holder - right hand thread (black)	(Pad driver side female, Floor side male)
2b	991-8577	Pad retainer	(Pad driver side male, Floor side female)
3a	991-2202	Big mouth pad holder set (blue)	(includes 3 screws)
3b	991-2205	Deep lock ring and pad grip ring
4	991-2203	Big mouth pad holder male thread portion
5	991-2206	Center-Lok 3 pad holder	(includes 3 screws)
6	996-0372	Big mouth pad holder (left hand thread)
7	N/A	Not available
8	991-2209	Split retainer - pad holder ring (OBSOLETE)
9	N/A	Not available	(replaced by #3 991-2202)
10	991-2211	Center lock pad holding cup (male) (yellow) (OBSOLETE)

- Pads - 13 inch

Click to enlarge

#	Part	Description
01	255-1340	13 inch aqua plus burnishing pad (pkg of 5)
02	255-1335	13 inch Armadillo concrete scrub pad (pkg of 5) (OBSOLETE)
03	255-1364	13 inch Blue ace pad (pkg of 5)
04	255-1342	13 inch Blue Jay burnishing pad (pkg of 5)
05	255-1312	13 inch Cure white pad (pkg of 5) (OBSOLETE)
06	255-1377	13 inch Diamondback extreme stripping pad (pkg of 5)
07	255-1338	13 inch EHD Extra Heavy Duty Concrete Leveling Pad (pkg of 2
08	255-1321	13 inch gorilla lite burnishing pad (pkg of 5)
09	255-1350	13 inch gorilla spray buff/polish/burnish pad (pkg of 5)
10	255-1365	13 inch Heat concrete bonding pad (pkg of 5)
11	255-1330	13 inch jaguar burnishing pad (pkg of 5)
12	255-1387	13 inch Melamine Mela-Kleen pad (pkg of 2)
13	255-1390	13 inch premium black stripping pad (pkg of 5)
14	255-1370	13 inch premium blue cleaning pad (pkg of 5)
15	255-1392	13 inch premium brown stripping pad (pkg of 5)
16	255-1380	13 inch premium green scrubbing pad (pkg of 5)
17	255-1360	13 inch premium red scrubbing pad (pkg of 5)
18	255-1352	13 inch premium tan polishing pad (pkg of 5)
19	255-1320	13 inch premium white polishing pad (pkg of 5)
20	255-1311	13 inch superspeed rubberized pad (pkg of 5)
21	255-1395	13 inch razorback stripping pad (pkg of 5)
22	255-1347	13 inch Redwood maroon floor prep pad (pkg of 10)
23	255-1355	13 inch Ruff non-abrasive brush pad (pkg of 2)
24	255-1323	13 inch sand screen driver pad (pkg of 2)
25	255-0198	13 inch Superscreen sand screen 100 grit (pkg of 10)
26	255-0199	13 inch Superscreen sand screen 120 grit (pkg of 10)
27	255-0200	13 inch Superscreen sand screen 150 grit (pkg of 10)
28	255-0201	13 inch Superscreen sand screen 180 grit (pkg of 10)
29	255-0202	13 inch Superscreen sand screen 220 grit (pkg 10)(OBSOLETE)
30	255-0203	13 inch Superscreen sand screen 400 grit (pkg of 10)
31	255-0196	13 inch Superscreen sand screen 60 grit(pkg of 10) (OBSOLETE
32	255-0197	13 inch Superscreen sand screen 80 grit (pkg of 10)
33	255-0113	13 inch Professional sand screen 100 grit (pkg of 10)
34	255-0114	13 inch Professional sand screen 120 grit (pkg of 10)
35	255-0115	13 inch Professional sand screen 150 grit (pkg of 10)
36	255-0116	13 inch Professional sand screen 180 grit (pkg of 10)
37	255-0117	13 inch Pro sand screen 220 grit (pkg of 10) (OBSOLETE)
38	255-0118	13 inch Professional sand screen 400 grit (pkg of 10)
39	255-0111	13 inch Professional sand screen 60 grit (pkg of 10)
40	255-0112	13 inch Professional sand screen 80 grit (pkg of 10)
41	255-1324	13 inch Tiger carpet bonnet (pkg of 2)
42	255-9542	13 inch Diamond by Gorilla 11000 Grit (pkg of 2)
43	255-9539	13 inch Diamond by Gorilla 1500 Grit (pkg of 2)
44	255-9536	13 inch Diamond by Gorilla 200 Grit (pkg of 2)
45	255-9540	13 inch Diamond by Gorilla 3000 Grit (pkg of 2)
46	255-9537	13 inch Diamond by Gorilla 400 Grit (pkg of 2)
47	255-9538	13 inch Diamond by Gorilla 800 Grit (pkg of 2)
48	255-9541	13 inch Diamond by Gorilla 8000 Grit (pkg of 2)
49	255-9638	13 inch Diamond starter pack (1 of each grit)
50	255-1382	13 inch Turbostrip segmented rotary pad (pkg of 4)(OBSOLETE)
51	255-1315	13 inch Duala clean and shine pad - low speed (pkg of 5)
52	255-1316	13 inch 2001 Duala clean and shine pad-high speed (OBSOLETE)

- Pads - 14x28 inch

Click to enlarge

#	Part	Description
01	255-9032	14 x 28 inch Melamine Mela-Kleen pad (pkg of 2)
02	255-9005	14 x 28 inch Premium Black Stripping Pad (pkg of 5)
03	255-9017	14 x 28 inch Premium Blue Cleaning Pad (pkg of 5)
04	255-9011	14 x 28 inch Premium Green Scrubbing Pad (pkg of 5)
05	255-9023	14 x 28 inch Premium Red Pad (pkg of 5)
06	255-9029	14 x 28 inch Premium White Polishing Pad (pkg of 5)
07	255-9037	14 x 28 inch Redwood maroon floor prep pad (pkg of 10)
08	255-9042	14 x 28 inch Ruff non-abrasive brush pad (pkg of 2)
09	255-0187	14 x 28 inch Professional sand screen 100 grit (pkg of 10)
10	255-0188	14 x 28 inch Professional sand screen 120 grit (pkg of 10)
11	255-0189	14 x 28 inch Professional sand screen 150 grit (pkg of 10)
12	255-0190	14 x 28 inch Professional sand screen 180 grit (pkg of 10)
13	255-0185	14 x 28 inch Professional sand screen 60 grit (pkg of 10)
14	255-0186	14 x 28 inch Professional sand screen 80 grit (pkg of 10)
15	255-0286	14 x 28 inch Superscreen sand screen 100 grit (pkg of 10)
16	255-0287	14 x 28 inch Superscreen sand screen 120 grit (pkg of 10)
17	255-0288	14 x 28 inch Superscreen sand screen 150 grit (pkg of 10)
18	255-0289	14 x 28 inch Superscreen sand screen 180 grit (pkg of 10)
19	255-0284	14 x 28 inch Superscreen sand screen 60 grit (pkg of 10)
20	255-0285	14 x 28 inch Superscreen sand screen 80 grit (pkg of 10)
21	255-9661	14 x 28 inch Diamond by Gorilla 100 Grit (pkg of 2)
22	255-9669	14 x 28 inch Diamond by Gorilla 11000 Grit (pkg of 2)
23	255-9665	14 x 28 inch Diamond by Gorilla 1500 Grit (pkg of 2)
24	255-9662	14 x 28 inch Diamond by Gorilla 200 Grit (pkg of 2)
25	255-9666	14 x 28 inch Diamond by Gorilla 3000 Grit (pkg of 2)
26	255-9663	14 x 28 inch Diamond by Gorilla 400 Grit (pkg of 2)
27	255-9664	14 x 28 inch Diamond by Gorilla 800 Grit (pkg of 2)
28	255-9667	14 x 28 inch Diamond by Gorilla 8000 Grit (pkg of 2)
29	255-9668	14 x 28 inch Diamond starter pack (1 of each grit)
30	255-0292	14 x 28 inch Duala clean and shine pad -low speed (pkg of 5)
31	255-0296	14 x 28 2001 Duala clean and shine pad -high speed (pkg 5)

- Pads - 15 inch

Click to enlarge

#	Part	Description
01	255-1540	15 inch aqua plus burnishing pad (pkg of 5)
02	255-1535	15 inch Armadillo concrete scrubbing pad (pkg/5) (OBSOLETE)
03	255-1564	15 inch Blue ace pad (pkg of 5)
04	255-1542	15 inch Blue Jay burnishing pad (pkg of 5)
05	255-1512	15 inch Cure white pad (pkg of 5)
06	255-1577	15 inch Diamondback extreme stripping pad (pkg of 5)
07	255-1538	15 inch EHD Extra Heavy Duty Concrete Leveling Pad (pkg of 2
09	255-1550	15 inch gorilla spray buff/polish/burnish pad (pkg of 5)
10	255-1565	15 inch Heat concrete bonding pad (pkg of 5)
11	255-1530	15 inch jaguar burnishing pad (pkg of 5)
12	255-1590	15 inch premium black stripping pad (pkg of 5)
13	255-1570	15 inch premium blue cleaning pad (pkg of 5)
14	255-1592	15 inch premium brown stripping pad (pkg of 5)
15	255-1580	15 inch premium green scrubbing pad (pkg of 5)
16	255-1560	15 inch premium red scrubbing pad (pkg of 5)
17	255-1552	15 inch premium tan polishing pad (pkg of 5)
18	255-1520	15 inch premium white polishing pad (pkg of 5)
19	255-1595	15 inch razorback stripping pad (pkg of 5)
20	255-1547	15 inch Redwood maroon floor prep pad (pkg of 10)
21	255-1511	15 inch superspeed rubberized pad (pkg of 5)
22	255-1555	15 inch Ruff non-abrasive brush pad (pkg of 2)
23	255-1523	15 inch sand screen driver pad (pkg of 2)
24	255-0125	15 inch Professional sand screen 100 grit (pkg of 10)
25	255-0126	15 inch Professional sand screen 120 grit (pkg of 10)
26	255-0127	15 inch Professional sand screen 150 grit (pkg of 10)
27	255-0128	15 inch Professional sand screen 180 grit (pkg of 10)
28	255-0129	15 inch Professional sand screen 220 grit (pkg of 10)
29	255-0123	15 inch Professional sand screen 60 grit (pkg of 10)
30	255-0124	15 inch Professional sand screen 80 grit (pkg of 10)
31	255-0210	15 inch Superscreen sand screen 100 grit (pkg of 10)
32	255-0211	15 inch Superscreen sand screen 120 grit (pkg of 10)
33	255-0212	15 inch Superscreen sand screen 150 grit (pkg of 10)
34	255-0213	15 inch Superscreen sand screen 180 grit (pkg of 10)
35	255-0214	15 inch Superscreen sand screen 220 grit (pkg of 10)
36	255-0208	15 inch Superscreen sand screen 60 grit (pkg of 10)
37	255-0209	15 inch Superscreen sand screen 80 grit (pkg of 10)
38	255-1524	15 inch Tiger carpet bonnet (pkg of 2)
39	255-9556	15 inch Diamond by Gorilla 11000 Grit (pkg of 2)
40	255-9553	15 inch Diamond by Gorilla 1500 Grit (pkg of 2)
41	255-9550	15 inch Diamond by Gorilla 200 Grit (pkg of 2)
42	255-9554	15 inch Diamond by Gorilla 3000 Grit (pkg of 2)
43	255-9551	15 inch Diamond by Gorilla 400 Grit (pkg of 2)
44	255-9552	15 inch Diamond by Gorilla 800 Grit (pkg of 2)
45	255-9555	15 inch Diamond by Gorilla 8000 Grit (pkg of 2)
46	255-9640	15 inch Diamond starter pack (1 of each grit)
47	255-1582	15 inch Turbostrip segmented rotary pad (pkg of 4)(OBSOLETE)
48	255-1515	15 inch Duala clean and shine pad - low speed (pkg of 5)
49	255-1516	15 inch 2001 Duala clean and shine pad - high speed (pkg 5)

- Pads - 17 inch

Click to enlarge

#	Part	Description
01	255-1740	17 inch aqua plus burnishing pad (pkg of 5)
02	255-1735	17 in Armadillo concrete scrubbing pad (pkg of 5) (OBSOLETE)
03	255-1764	17 inch Blue ace pad (pkg of 5)
04	255-1742	17 inch Blue Jay burnishing pad (pkg of 5)
05	255-1712	17 inch Cure white pad (pkg of 5) (OBSOLETE)
06	255-1777	17 inch Diamondback extreme stripping pad (pkg of 5)
07	255-1738	17 inch EHD Extra Heavy Duty Concrete Leveling Pad (pkg of 2
08	255-1721	17 inch gorilla lite burnishing pad (pkg of 5)
09	255-1750	17 inch gorilla spray buff/polish/burnish pad (pkg of 5)
10	255-1765	17 inch Heat concrete bonding pad (pkg of 5)
11	255-1730	17 inch jaguar burnishing pad (pkg of 5)
12	255-1767	17 inch Laminated 2001 Gorilla polish pad (pkg of 5)
13	255-1768	17 inch Microclean daily cleaning pad (pkg of 2) (OBSOLETE)
14	255-1769	17 inch Micropolish polishing and burnishing pad (pkg of 2)
15	255-1790	17 inch premium black stripping pad (pkg of 5)
16	255-1770	17 inch premium blue cleaning pad (pkg of 5)
17	255-1792	17 inch premium brown stripping pad (pkg of 5)
18	255-1780	17 inch premium green scrubbing pad (pkg of 5)
19	255-1760	17 inch premium red scrubbing pad (pkg of 5)
20	255-1752	17 inch premium tan polishing pad (pkg of 5)
21	255-1720	17 inch premium white polishing pad (pkg of 5)
22	255-1711	17 inch superspeed rubberized pad (pkg of 5)
23	255-1795	17 inch razorback stripping pad (pkg of 5)
24	255-1747	17 inch Redwood maroon floor prep pad (pkg of 10)
25	255-1755	17 inch Ruff non-abrasive brush pad (pkg of 2)
26	255-1723	17 inch sand screen driver pad (pkg of 2)
27	255-0139	17 inch Professional sand screen 100 grit (pkg of 10)
28	255-0019	17 inch Professional sand screen 120 grit (pkg of 10)
29	255-0140	17 inch Professional sand screen 150 grit (pkg of 10)
30	255-0141	17 inch Professional sand screen 180 grit (pkg of 10)
31	255-0142	17 inch Professional sand screen 220 grit (pkg of 10)
32	255-0143	17 inch Professional sand screen 400 grit (pkg of 10)
33	255-0138	17 inch Professional sand screen 60 grit (pkg of 10)
34	255-0018	17 inch Professional sand screen 80 grit (pkg of 10)
35	255-0225	17 inch Superscreen sand screen 100 grit (pkg of 10)
36	255-0226	17 inch Superscreen sand screen 120 grit (pkg of 10)
37	255-0227	17 inch Superscreen sand screen 150 grit (pkg of 10)
38	255-0228	17 inch Superscreen sand screen 180 grit (pkg of 10)
39	255-0229	17 inch Superscreen sand screen 220 grit (pkg of 10)
40	255-0230	17 inch Superscreen sand screen 400 grit (pkg of 10)
41	255-0223	17 inch Superscreen sand screen 60 grit (pkg of 10)
42	255-0224	17 inch Superscreen sand screen 80 grit (pkg of 10)
43	255-1724	17 inch Tiger carpet bonnet (pkg of 2)
44	255-9570	17 inch Diamond by Gorilla 11000 Grit (pkg of 2)
45	255-9567	17 inch Diamond by Gorilla 1500 Grit (pkg of 2)
46	255-9564	17 inch Diamond by Gorilla 200 Grit (pkg of 2)
47	255-9568	17 inch Diamond by Gorilla 3000 Grit (pkg of 2)
48	255-9565	17 inch Diamond by Gorilla 400 Grit (pkg of 2)
49	255-9566	17 inch Diamond by Gorilla 800 Grit (pkg of 2)
50	255-9569	17 inch Diamond by Gorilla 8000 Grit (pkg of 2)
51	255-9642	17 inch Diamond starter pack (1 of each grit)
52	255-1782	17 inch Turbostrip segmented rotary pad (pkg of 4)
53	255-1715	17 inch Duala clean and shine pad - low speed (pkg of 5)
54	255-1716	17 inch 2001 Duala clean and shine pad - high speed (pkg 5)

Attaching Decks Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	202-6592	Guard,Front,LH	1
2	202-6593	Guard,Front,RH	1
3	202-6615	Band,Curtain	1
4	202-9708	Cylindrical curtain	1
5	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	4
6	999-0423	Nut 5/16-18 nylon insert lock stainless steel	8
7	N/A	Not available	1	(screw)
8	N/A	Not available	8	(pin)

Attaching Squeegee Trail Arm, Bumper and Axle Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	202-5316	Lifting bracket	1
2	202-9736	Actuator adaptor	1
3	202-7656	Bushing,Flanged,5/16 inchIDx1/2 inchODx 1/4 inch, Hardened S	2
5	202-4299	Main frame	1
7	202-4043	Axle	1
8	202-3700	36V fast actuator	1
9	999-1326	Screw M12-1.75 x 40mm hex head	1
10	999-1122	Nut M12-1.75 hex nylon insert lock stainless steel	1
11	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	12
12	999-0423	Nut 5/16-18 nylon insert lock stainless steel	10
13	999-1416	Washer 7/16 flat stainless steel	2
14	999-0559	Washer 1/2 x 1/4 flat stainless steel	2
15	999-0560	Washer 1/2 lock stainless steel	2
17	999-1917	Screw 1/2-13 x 1 button socket cap SS	2
18	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	4
19	999-0967	Bolt 5/16-18 x 3/4 carriage head stainless steel	4
20	202-3275	Rubber bumper	2
22	202-5603	U-bolt 1/4-20 x 1	2
23	202-9707	Clevis pin	2
24	202-9560	Ring,Retaining,1 inch Heavy Duty	2
25	202-9728	Squeegee trail arm swing complete assembly	1	(standard)
26	202-9729	Fixed squeegee trail arm assembly	1	(optional)
27a	202-5601	Poly wheel assembly (gray)	2
27b	202-8252	Wheel Assembly,Rear,Poly,2.7 inchW Black Poly, 65 ShA, Groov	2

Cylindrical Decks Assembly 1

Click to enlarge

#	Part	Description	Req	Notes
1	202-6095	Bracket, Deck Lifting	1
2	202-6396	Power Post, Black, 1/4 Terminal	1
3	202-6397	Power Post, Red, 1/4 Terminal	2
4	202-3136	Retaining pin	2
5	202-3137	Hinge	2
7	202-4022	Quick disconnect bracket	1
9	202-1239	Flanged bearing	4
10	202-0754	Flanged bearing	4
11	202-5098	2 inch bolt on level	2
15	202-5803	Lateral Arm, Adjustable, 6.25 inch	2
16	202-4301	36V stroke actuator	2
18	202-4306	Cylindrical lifting bracket	1
19	202-3730	Cylindrical lateral arm	2
20	202-4307	Lift arm cross bar	1
21	202-9644	Scrub arm bracket	2
22	202-2174	Side support HD	2
24	202-9650	Motor adjustment bracket	2
26	202-9720	Left hand cylindrical rear support bracket	1
27	202-9721	Right hand cylindrical rear support bracket	1
30	N/A	Not available	1	(pin)
33	202-9722	Clevis pin	4
35	999-0424	Bolt 5/16-18 x 1 hex head stainless steel	2
37	999-0086	Nut 10-32 nylon insert lock zinc plated	2
38	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	22
39	999-0423	Nut 5/16-18 nylon insert lock stainless steel	45
40	202-2067	Nut 10-32 keps	2
41	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	25
42	999-0617	Washer 3/8 x 1 flat stainless steel	20
43	999-1631	Screw 10-32 x 1 1/2 pan head phillips stainless steel	2
45	202-3157	Screw 1/4 x 1/4 inch socket head stainless steel	3
47	999-1442	Bolt 1/4-20 x 1/2 carriage stainless steel	2
48	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	18
49	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	4
50	999-0967	Bolt 5/16-18 x 3/4 carriage head stainless steel	33
51	999-9066	Bolt 5/16-18 x 1 carriage head stainless steel	4
52	999-1370	Bolt 5/16-18 x 1 1/2 carriage head stainless steel	4
55	202-2208	Compression spring	4
56	202-2208	Compression spring	4
57	999-0120	Washer 3/8 SAE flat	4
59	N/A	Not available	2	(bolt)
61	N/A	Not available	3	(clip)
62	N/A	Not available	1	(end cap)
64	202-5589	36V actuator	1	(before SN 129871)
65a	202-7044	Hopper, 25 inch, SS	1
65b	202-7045	Hopper, 29 inch, SS	1
65c	202-7046	Hopper, 33 inch, SS	1
66a	202-4308	25 inch cylindrical shell	1
66b	202-9711	29 inch cylindrical shell	1
66c	202-9712	33 inch cylindrical shell	1
67a	202-2164	25 inch cylindrical feed tube	1
67b	202-2165	29 inch cylindrical feed tube	1
67c	202-2166	33 inch cylindrical feed tube	1
68a	202-2167	29 inch stiffener stainless steel	1
68b	202-2168	33 inch stiffener stainless steel	1
68c	202-2169	37 inch stiffener stainless steel	1
69a	202-2170	29 inch attinuator	1
69b	202-2171	33 inch attinuator	1
69c	202-2172	37 inch attinuator	1
70a	202-9654	25 inch right hand cylindrical bracket	1
70b	202-9655	25 inch left hand cylindrical bracket	1
70c	202-9656	29 inch right hand cylindrical bracket	1
70d	202-9657	29 inch left hand cylindrical bracket	1
70e	202-9658	33 inch right hand cylindrical bracket	1
70f	202-9659	33 inch left hand cylindrical bracket	1
N/S	999-1575	Bolt 5/16-18 x 1/2 carriage head zinc plated	6

Cylindrical Decks Assembly 2

Click to enlarge

#	Part	Description	Req	Notes
6	202-3140	32 toothed sprocket	2
8	202-7059	Sprocket, Timing, 56 Tooth	2
13	202-3146	Bearing housing	2
14	202-7788	Seal,Cylindrical Driver	2
17	202-8375	Driver, Cylindrical Spiral, 8 Spline, Brass Brass	2
22	202-2174	Side support HD	2
23	202-0023	Cylindrical belt	2
24	202-9650	Motor adjustment bracket	2
25	202-2175	Motor spacer	2
28	N/A	Not available	1	(square keyway)
29	N/A	Not available	1	(nut)
31	202-9193	Plug,Hole,7/8 inch	2
32	202-3153	Square keyway	2
34	202-3154	Screw 1/4-20 x 1/4 set	8
35	999-0424	Bolt 5/16-18 x 1 hex head stainless steel	2
36	999-0562	Bolt 3/8-16 x 1 hex head stainless steel	8
39	999-0423	Nut 5/16-18 nylon insert lock stainless steel	45
42	999-0617	Washer 3/8 x 1 flat stainless steel	20
44	999-1009	Screw 10-32 x 1/2 flat head phillips stainless steel	8
46	999-1481	Screw 3/8-16 x 1/2 button head stainless steel	2
54	202-3158	Washer 3/8 inch serrated stainless steel	8
58	N/A	Not available	1	(key)
63a	202-5125	36V 3/4HP motor	1	(25 inch)
63b	202-3145	36V brush motor	1	(29 and 33 inch)

Cylindrical Doors Assembly

Click to enlarge

#	Part	Description	Req	Notes
0	202-2174	Side support HD	1	(includes 1-10)
1	202-3168	Idler drive bearing	1
2	202-7788	Seal,Cylindrical Driver	1
3	202-3170	Grommet	1
4	202-0404	Latch	1
5a	202-8374	Driver, Cylindrical Spiral, 8 Spline, Alum HC W/Gasket	1	(hardcoat)
5b	202-8375	Driver, Cylindrical Spiral, 8 Spline, Brass Brass	1	(brass)
6	202-2176	Drive cover	1
7	999-1151	Nut 3/8-24 nylon insert jam lock stainless steel	1
8	202-3153	Square keyway	1
9	999-0617	Washer 3/8 x 1 flat stainless steel	1
10	999-1009	Screw 10-32 x 1/2 flat head phillips stainless steel	4

Cylindrical Wipers Assemby

Click to enlarge

#	Part	Description	Req	Notes
0a	202-9727	Left hand horizontal arm shroud complete	1	(includes 1-22, 23a, 24)
0b	202-9724	Right hand horizontal arm shroud complete	1	(includes 1-22, 23b, 24)
1	202-5123	Wiper band	1
2	202-3127	4 inch chain (6 inch no longer available)	1
3	202-9647	Vertical arm shroud	1
4	202-9648	Vertical arm wiper	1
5	202-9649	Side shroud	1
6	999-1633	Clevis pin 3/8 x 3 1/2	1
7	999-1508	Bolt 10-32 x 5/8 round carriage head stainless steel	1
8	999-1457	Bolt 5/16-18 x 5/8 round head carriage stainless steel	4
9	999-0297	Bolt 1/4-20 x 1 hex head stainless steel	1
10	999-0609	Nut 1/4-20 hex stainless steel	1
11	999-0086	Nut 10-32 nylon insert lock zinc plated	1
12	202-2067	Nut 10-32 keps	1
13	202-3316	Washer flat stainless steel	1
14	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	6
15	999-0617	Washer 3/8 x 1 flat stainless steel	2
16	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	5
17	999-1401	Bolt 1/4-20 x 1 carriage head stainless steel	2
18	202-2208	Compression spring	1
19	999-0304	Nut 1/4-20 nylon lock jam stainless steel	9
20	999-1019	Nut 5/16-18 hex jam stainless steel	4
21	202-2036	Cotter pin	1
22	202-3129	Cotter pin	1
23a	202-9726	Left hand horizontal arm shroud	1
23b	202-9725	Right hand horizontal arm shroud	1
24a	202-3019	Shroud curtain linatex (red)	1
24b	202-3381	Shroud curtain gum rubber (tan)	1
24c	202-6613	Curtain,Wiper,Urethane	1

Decal Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	202-4343	Military control panel side decal	1
2	202-4344	GTX decal set	1
3	202-4345	Touch screen control panel side decal	1
4	202-4346	CRZ decal	1
5	202-0436	Tomcat front decal	1
6	202-4344	GTX decal set	1
7	202-4348	V2.0 decal	1
8	202-5855	Decal, Tank, Onboard	1
9	202-5856	Decal, Tank, SUDS	1
10	202-9819	O3 plus decal	1
11	N/A	Not available	1	(31 inch squeegee decal)
12	202-9922	33 inch squeegee decal	1
13	202-4349	37 inch squeegee decal	1
14	202-3656	41 inch squeegee decal	1
15	202-4350	45 inch squeegee decal	1

Disk Deck Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(rue ring)
2	202-4300	Adjustable lateral arm body	2
3	202-5078	Star knob	4
4	202-6102	Adjustable Rod End, LH	2
5	202-6103	Adjustable Rod End, RH	2
6	202-6396	Power Post, Black, 1/4 Terminal	1
7	202-6397	Power Post, Red, 1/4 Terminal	2
8	202-1948	34 inch rear curtain band	1
9	202-1947	26 and 30 inch rear curtain band	1
10	202-2260	30 inch front curtain band	1
11	202-1943	26 and 30 inch front curtain	1
12	202-5080	Adjustment knob shroud	4
13	202-5136	Squeegee drag brace	2
14	202-7039	Spacer, Driver	2
15	202-5098	2 inch bolt on level	2
16	202-7656	Bushing,Flanged,5/16 inchIDx1/2 inchODx 1/4 inch, Hardened S	4
17	202-2746	Lift lever spring	4
18	202-0324	Scrub head lateral arm	2
19	202-0331	Brush driver key (pkg of 2)	2
20	202-0332	1/2 inch barbed tee	1
21	202-4301	36V stroke actuator	1
22	202-4302	Scrub deck stainless steel	1
23	202-4303	Lift arm cross bar	1
24	202-4304	Disk scrub deck bracket	1
25	202-9644	Scrub arm bracket	2
26	202-0335	Barbed elbow	2
27	999-1508	Bolt 10-32 x 5/8 round carriage head stainless steel	10
28	202-9159	Nut,Hex Jam,1/2-20,LH	2
29	999-0330	Nut 1/2-13 acorn brass	8
30	202-0680	Hose clamp	5
31	202-9722	Clevis pin	1
32	999-0424	Bolt 5/16-18 x 1 hex head stainless steel	2
33	999-0562	Bolt 3/8-16 x 1 hex head stainless steel	8
34	202-9358	Nut,Hex Jam,1/2-20	2
35	999-0086	Nut 10-32 nylon insert lock zinc plated	10
36	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	6
37	999-0423	Nut 5/16-18 nylon insert lock stainless steel	20
38	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	14
39	999-0617	Washer 3/8 x 1 flat stainless steel	6
40	999-0553	Washer 5/16 medium split lock stainless steel	2
41	999-0659	Washer 3/8 medium split lock stainless steel	12
42	999-0560	Washer 1/2 lock stainless steel	4
43	999-0894	Screw 3/8-16 x 2 1/2 carriage head stainless steel	4
44	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	6
45	999-0967	Bolt 5/16-18 x 3/4 carriage head stainless steel	8
46	999-9066	Bolt 5/16-18 x 1 carriage head stainless steel	8
47	999-1370	Bolt 5/16-18 x 1 1/2 carriage head stainless steel	4
49	999-9071	Nut 3/8-16 nylon insert jam lock stainless steel	4
50	202-2036	Cotter pin	1
51	202-4305	Clevis pin	1
52	202-4217	Barb elbow 1/2 x 1/4 inch	2
53	202-9499	Tee, 1/4 inch, Plastic	1
54	202-3482	Shim	4
55	202-4225	Hose	1
56	202-4225	Hose	1
57	202-4225	Hose	1
58	202-5106	Reinforced hose 1/2 x 60 inch	1
59	202-5106	Reinforced hose 1/2 x 60 inch	1
60	202-5106	Reinforced hose 1/2 x 60 inch	1
61	202-5588	36V actuator	1	(before SN 129871)
62a	202-2259	26 inch front curtain band	1	(for 26 inch)
62b	202-2260	30 inch front curtain band	1	(for 30 inch)
63	202-3145	36V brush motor	1	(1.5 HP 350 RPM motor)
64	202-5125	36V 3/4HP motor	1	(.75 HP 270 RPM motor)
65	202-7037	Driver, Brush, Rounded Tooth, Brass	1	(for brass brush drive)
N/S	202-2208	Compression spring	2

Disk Shrouds Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	202-5079	4 inch wheel	2
2	202-1995	Shroud curtain gum rubber (tan)	1
3	202-4309	Shroud curtain band	1
4	999-1632	Nut 3/8-16 acorn stainless steel	1
5	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	6
6	999-0659	Washer 3/8 medium split lock stainless steel	1
7	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	6
8	999-1149	Bolt 3/8-16 x 2 carriage head stainless steel	1
9	999-0304	Nut 1/4-20 nylon lock jam stainless steel	6
10a	202-4310	26 inch left hand shroud	1
10b	202-4311	26 inch right hand shroud	1
10c	202-4312	28 inch left hand shroud	1
10d	202-4313	28 inch right hand shroud	1
10e	202-4314	30 inch left hand shroud	1
10f	202-4315	30 inch right hand shroud	1
10g	202-4316	34 inch left hand shroud	1
10h	202-4317	34 inch right hand shroud	1
11a	202-4205	Side skirt	1
11b	202-1995	Shroud curtain gum rubber (tan)	1
11c	202-3560	Shroud curtain urethane	1
12a	202-4318	26 inch complete right hand shroud	1	(includes 1-9, 10b, 11)
12b	202-4319	28 inch complete right hand shroud	1	(includes 1-9, 10d, 11)
12c	202-4320	30 inch complete right hand shroud	1	(includes 1-9, 10f, 11)
12d	202-4321	34 inch complete right hand shroud	1	(includes 1-9, 10h, 11)
13a	202-4322	26 inch complete left hand shroud	1	(includes 1-9, 10a, 11)
13b	202-4323	28 inch complete left hand shroud	1	(includes 1-9, 10c, 11)
13c	202-4324	30 inch complete left hand shroud	1	(includes 1-9, 10e, 11)
13d	202-4325	34 inch complete left hand shroud	1	(includes 1-9, 10g, 11)

Doors Assembly - 26 inch Disk and 25 inch Cylindrical

Click to enlarge

#	Part	Description	Req
1	202-0403	Hinge	1
2	202-0404	Latch	1
5	999-1442	Bolt 1/4-20 x 1/2 carriage stainless steel	4
7	999-0304	Nut 1/4-20 nylon lock jam stainless steel	4
8a	202-4341	25 inch right hand cylindrical door	1
8b	202-4342	25 inch left hand cylindrical door	1
N/S	999-0429	Nut 1/4-20 acorn nickel plated	4
N/S	999-0632	Washer 1/4 split lock stainless steel	4
N/S	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	4

Doors Assembly - 28 and 30 inch Disk and 29 inch Cylindrical

Click to enlarge

#	Part	Description	Req
1	202-0756	Guide roller	4
2	202-0404	Latch	1
3	202-1058	Washer 5/8 teflon	2
4	999-0989	Bolt 5/8-11 x 13 hex head grade 5 zinc plated	1
5	999-0968	Nut 5/8-11 nylon insert jam lock zinc plated	1
6a	202-4339	29 inch right hand cylindrical door	1
6b	202-4340	29 inch left hand cylindrical door	1
7a	202-9815	Right hand hinge bracket	1
7b	202-9816	Left hand hinge bracket	1

Doors Assembly - 34 inch Disk and 33 inch Cylindrical

Click to enlarge

#	Part	Description	Req
1	202-0756	Guide roller	4
2	202-0404	Latch	1
3	202-4338	33 inch right hand cylindrical door	1
4	202-9815	Right hand hinge bracket	1
5	202-1058	Washer 5/8 teflon	2
6	999-0989	Bolt 5/8-11 x 13 hex head grade 5 zinc plated	1
7	999-0968	Nut 5/8-11 nylon insert jam lock zinc plated	1

Front Drive Wheel Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	202-1894	60 toothed sprocket	1
2	202-1896	Pivot plate	1
3	202-1897	Steering chain	1
4	202-2960	Wire guide	1
5	202-0767	Bearing cap	2
6	202-1166	Slotted castle nut	1
7	202-5067	Tapered roller bearing	2
8	202-5068	Bearing seal	1
9	202-5069	Drive guard	2
10	202-0280	10 toothed sprocket	1
11	202-0283	Master link	1
12	202-5549	Bearing housing assembly	1
13	202-4296	Lower steering shaft	1
14	202-9637	Bearing block assembly	1
15	202-4297	10 inch drop plate assembly	1
16	202-9638	Steering spindle	1
17	202-1040	Washer	2
18	999-1300	Screw M6-1 x 25mm socket head stainless steel	10
19	999-9136	Screw 1/4-20 x 2 3/4 pan head phillips stainless steel	4
20	999-1909	Screw 5/16-18 x 3 1/2 button socket cap SS	2
21	999-0857	Screw 3/8-24 x 1 3/4 hex head stainless steel	2
22	999-9091	Screw M10-1.5 x 30mm hex head stainless steel	4
23	999-1635	Screw 10-32 x 1/4 socket set	2
24	999-1908	Screw M6-1 x 10mm hex head stainless steel	2
25	202-2216	Shaft collar with set screw	1
26	202-0281	Snap ring	1
27	999-0334	Bolt 1/4-20 x 3/4 inch hex head stainless steel	1
28	999-0556	Bolt 5/16-18 x 3/4 hex head stainless steel	2
29	202-9351	Screw,Hex Cap,3/8-24x1-1/4 inch Stainless	5
30	999-0609	Nut 1/4-20 hex stainless steel	1
31	999-0169	Nut 3/8-24 hex jam plain finish	7
32	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	8
33	999-0423	Nut 5/16-18 nylon insert lock stainless steel	4
34	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	6
35	999-0632	Washer 1/4 split lock stainless steel	1
36	999-0553	Washer 5/16 medium split lock stainless steel	2
37	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	4
38	999-0346	Screw 5/16-18 x 1/4 set cup point socket alloy plain finish	1
39	202-0278	Square keyway	1
40	999-9071	Nut 3/8-16 nylon insert jam lock stainless steel	2
41	202-2967	S hook	1
42	202-9556	Cap, Vinyl, 1/2 inch	12
43	202-3613	Tubing (clear)	1
44a	202-1893	Drive wheel assembly w/motor - includes brake	1
44b	202-5047	36V 10 inch front drive wheel	1	(option)
44c	202-5059	10 inch front wheel drive motor assembly	1	(grey) (option)
45	202-5075	36V electric brake	1
46a	202-3524	Front wheel drive motor	1
46b	202-5072	36V brush motor kit with springs	1
46c	202-7746	Traction Harness XR/GTX	1
47a	202-4298	10 inch rough tread tire (gray)	1
47b	202-5039	10 inch tire and wheel (black)	1
47c	202-5658	P-7 tire	1

Front Wheel and Side Rollers Assembly

Click to enlarge

#	Part	Description	Req
1	202-5316	Lifting bracket	1
2	202-0976	20 inch roller bracket	2
3	202-0756	Guide roller	8
4	202-2754	Adjustment knob	2
5	202-5560	Lower roller bracket	2
6	202-5546	9-60V LED head light	2
7	202-4299	Main frame	1
8	202-5284	Nut 1/4-20 hex crimp long	7
9	999-1829	Screw 5/16-18 x 2 1/2 socket head stainless steel	2
10	202-3538	P clamp	1
11	999-9119	Nut 1/2-13 nylon hex jam	1
12	999-1209	Bolt 5/8-11 x 4 hex head zinc plated	2
13	999-1209	Bolt 5/8-11 x 4 hex head zinc plated	2
14	999-6723	Bolt 5/8-11 x 7 hex head grade 5 zinc plated	2
15	999-0069	Nut 5/16-18 hex	2
16	202-3175	P clamp	1
17	999-0968	Nut 5/8-11 nylon insert jam lock zinc plated	2
18	999-0334	Bolt 1/4-20 x 3/4 inch hex head stainless steel	8
19	202-3084	Bolt hex head 1/2 x 2 inch stainlee steel	1
20	999-0593	Nut 5/16-18 hex stainless steel	2
21	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	9
22	999-0423	Nut 5/16-18 nylon insert lock stainless steel	7
23	999-0704	Nut 5/8-11 nylon insert lock stainless steel	3
24	999-1466	Nut 1/4-20 lock with external toothed lockwasher SS	2
25	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	7
26	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	5
27	999-0632	Washer 1/4 split lock stainless steel	7
28	999-0553	Washer 5/16 medium split lock stainless steel	9
29	999-0457	Screw 1/4-20 x 3/4 flat head phillips stainless steel	4
30	999-1345	Screw 1/4-20 x 1 flat head phillips stainless steel	1
31	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	5
32	999-1401	Bolt 1/4-20 x 1 carriage head stainless steel	1
33	999-9066	Bolt 5/16-18 x 1 carriage head stainless steel	9
34	202-5562	Bolt 15/16 inch plastic hex cap	2

Legacy Central Command 1

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(QR sticker)
2	202-5893	Bracket, Hose	1
3	202-5903	Air Dryer Assembly	1
4	202-3622	Power keychain	1
8	202-6396	Power Post, Black, 1/4 Terminal	1
12	202-2300	Key switch with key entry (red) and ring (black)	2
14	991-1634	Key (pkg of 2)	3
16	202-1317	LCD window display	1
17	202-7287	Resistor,Wirewound,8 OHM,50W	3
18	202-3307	36V relay with mounting plate	2
19	202-1992	Toggle switch	9
20	202-0097	Toggle switch	1
21	202-1369	Main controller	1
25	202-0090	Wand clip	1
26	202-8269	Decal, Central Command	1
27	202-8269	Decal, Central Command	1
28	202-9675	Central command dust curtain	1
29	202-9530	Vinyl Foam Rubber 1/8 inch Thick 1 /4 inch Wide 17' Length	1
30	202-3811	Resistor plate	1
32	202-4244	Resister	3
34	202-0541	Busbar	2
37	202-0704	Hinge	1
38	202-0830	Busbar (5 hole)	2
39	999-1982	Bolt 10-32 x 1 round carriage head stainless steel	6
41	202-1864	Toggle switch protective boot (red)	1
42	202-1977	Toggle switch protective boot (yellow)	1
44	202-1865	Toggle switch protective boot (blue)	1
45	202-1355	Toggle switch protective boot (black)	1
46	202-2221	Toggle switch protective boot (gray)	1
48	999-0190	Nut 1/4-20 hex plain finish	7
49	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	5
50	999-1464	Nut 8-32 keps lock with external tooth lockwasher ss	6
51	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	6
53	202-2370	Screw 4-40 x 1/2 Phillips pan head stainless steel	12
54	999-1919	#8-15 x 1/2 phillips pan head sheet metal SS	10
55	999-0867	Bolt 1/4-20 x 3/4 button head socket cap stainless steel	4
56	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	9
57a	202-9674	LCD screen control panel (red)	1
57b	202-9673	LCD screen control panel (granite)	1
58a	202-9672	Access cover (red)	1
58b	202-9671	Access cover (granite)	1
N/S	202-3818	Front control panel sticker	1
N/S	999-0916	Screw 8-32 x 1/2 pan head phillips stainless steel	2

Legacy Central Command 2

Click to enlarge

#	Part	Description	Req
4	202-3622	Power keychain	1
5	202-3622	Power keychain	1
6	202-3622	Power keychain	1
7	202-3622	Power keychain	1
9	202-3623	Key switch	1
10	202-3624	Manager lockout key (pkg of 2)	1
11	202-0832	Full recovery indicator (red)	2
13	202-7203	Light,24V,Green,Bulb Style	1
14	991-1634	Key (pkg of 2)	3
15	202-7204	Light,24V,Yellow,Bulb Style	2
16	202-1317	LCD window display	1
19	202-1992	Toggle switch	9
22	202-2499	15amp fuse	2
23	202-0341	6 Amp circuit breaker	1
24	202-8199	Breaker, 5a	2
33	202-0879	Push button switch	1
35	202-0822	2amp fuse	1
36	202-3625	Dual USB ports	1
40	202-1976	Toggle switch protective boot (white)	2
41	202-1864	Toggle switch protective boot (red)	1
43	202-1866	Toggle switch protective boot (green)	1
44	202-1865	Toggle switch protective boot (blue)	1
45	202-1355	Toggle switch protective boot (black)	1
46	202-2221	Toggle switch protective boot (gray)	1
47	202-3465	Toggle switch protective boot (orange)	2

Military Central Command 1

Click to enlarge

#	Part	Description	Req	Notes
1	202-5893	Bracket, Hose	1
2	202-5903	Air Dryer Assembly	1
3	202-5386	Handle grip (blue)	1
6	202-6396	Power Post, Black, 1/4 Terminal	1
15	991-1634	Key (pkg of 2)	2
17	202-5254	I-drive controller	1
18	202-3307	36V relay with mounting plate	4
19	202-1992	Toggle switch	7
24	202-0348	15amp relay	4
26	202-5612	Valve lever	1
27	202-8269	Decal, Central Command	1
28	202-9675	Central command dust curtain	1
29	202-9530	Vinyl Foam Rubber 1/8 inch Thick 1 /4 inch Wide 17' Length	1
32	202-0541	Busbar	2
35	202-0704	Hinge	1
36	202-0830	Busbar (5 hole)	2
37	202-1196	Washer 17/64 x 21/64 nylon flat	1
38	202-3302	Bolt 10-32 x 1/2 carriage head stainless steel	4
40	202-1864	Toggle switch protective boot (red)	1
44	999-0190	Nut 1/4-20 hex plain finish	11
45	202-2964	Shaft collar	3
46	999-0357	Nut 8-32 nylon insert lock stainless steel	2
47	999-0086	Nut 10-32 nylon insert lock zinc plated	6
48	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	6
49	999-1464	Nut 8-32 keps lock with external tooth lockwasher ss	6
50	999-1466	Nut 1/4-20 lock with external toothed lockwasher SS	11
51	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	6
52	999-0916	Screw 8-32 x 1/2 pan head phillips stainless steel	2
53	999-1574	Screw 8-32 x 1 pan head phillips stainless steel	4
54	999-1918	Screw #8-32 x 1 1/4 phillips pan head SS	3
55	999-1350	Screw 10-32 x 1/2 inch phillips pan head stainless steel	2
56	999-1919	#8-15 x 1/2 phillips pan head sheet metal SS	10
57	999-1480	Screw 1/4-20 x 5/8 button head socket cap stainless steel	3
58	999-0867	Bolt 1/4-20 x 3/4 button head socket cap stainless steel	4
59	999-1442	Bolt 1/4-20 x 1/2 carriage stainless steel	8
60	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	6
61	202-3816	Nut #8-32 socket head	2
62a	N/A	Not available	1	(red control box)
62b	N/A	Not available	1	(granite control box)
63a	202-9672	Access cover (red)	1
63b	202-9671	Access cover (granite)	1

Military Central Command 2

Click to enlarge

#	Part	Description	Req	Notes
3	202-5386	Handle grip (blue)	1
4	202-3622	Power keychain	1
5	202-3622	Power keychain	1
7	202-4159	40amp brush pressure gauge	1
8	202-5609	36V battery/hour meter	1
9	202-3631	Rocker switch (amber)	1
10	202-3632	Rocker switch (green)	1
11	202-3633	Rocker switch (blue)	1
12	202-0832	Full recovery indicator (red)	2
13	202-2300	Key switch with key entry (red) and ring (black)	1
14	202-7203	Light,24V,Green,Bulb Style	1
15	991-1634	Key (pkg of 2)	2
16	202-7204	Light,24V,Yellow,Bulb Style	2
19	202-1992	Toggle switch	7
20	202-2499	15amp fuse	2
21	202-0341	6 Amp circuit breaker	1
22	202-8199	Breaker, 5a	2
23	202-0369	2 position rocker switch	1
25	202-0090	Wand clip	1
26	202-5612	Valve lever	1
30	N/A	Not available	1	(central command top)
31	202-3818	Front control panel sticker	1
33	202-0822	2amp fuse	1
34	202-3625	Dual USB ports	1
39	202-1976	Toggle switch protective boot (white)	2
40	202-1864	Toggle switch protective boot (red)	1
41	202-1866	Toggle switch protective boot (green)	2
42	202-3465	Toggle switch protective boot (orange)	2
43	999-0435	Screw 1/4-20 x 5/8 socket head alloy plain finish	4
54	999-1918	Screw #8-32 x 1 1/4 phillips pan head SS	3
60	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	6

Orbital Deck Wipers Assembly

Click to enlarge

#	Part	Description	Req	Notes
0a	202-6609	Wiper, Shroud, RH Complete	1	(includes 1, 3-7)
0b	202-6610	Wiper, Shroud, LH, Complete	1	(includes 1-7)
1	202-5079	4 inch wheel	1
2	202-5082	Left side wiper shroud	1
3a	202-5112	linatex wiper	1
3b	202-5113	Polyurethane wiper	1
4	202-5083	Wiper band	1
5	999-0423	Nut 5/16-18 nylon insert lock stainless steel	1
6	202-3077	Carriage bolt 5/16 x 1-1/2 stainless steel	1
7	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	5
N/S	999-0304	Nut 1/4-20 nylon lock jam stainless steel	5

Orbital Decks Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	202-5078	Star knob	6
2	202-5079	4 inch wheel	2
3	202-6410	Weight, 16.5 Lbs, Green	1
4	202-5080	Adjustment knob shroud	4
5	202-5081	Right side wiper shroud	1
6	202-5082	Left side wiper shroud	1
7	202-5083	Wiper band	2
8	202-4230	Spacer	4
9	202-9660	Weight gasket	1
10	202-9661	35 pound weight	1
11	202-2961	Terminal cover (black)	2
12	202-5084	Crush washer	2
13	202-5091	Isolator decal	1
14	202-5092	36V 1HP motor	1
17	202-2177	Isolator shield	4
18	202-5098	2 inch bolt on level	2
19	202-7433	Weight, 5 lb	2
21	202-5099	Adjustable lateral arm assembly	2
22	202-5100	Left side deck lifting bracket	1
23	202-5101	Right side deck lifting bracket	1
24	202-5102	Lateral arm	1
25	202-5589	36V actuator	1
26	202-2746	Lift lever spring	4
27	202-9644	Scrub arm bracket	2
28	202-0376	Hour meter	1
29	202-9090	Decal, Edge, 28 inch	2
30	202-5105	1 inch rubber loop clamp	1
31	202-5205	Bolt #10-32 x 1 1/2 inch carriage stainless steel	3
32	999-1874	Washer #10 nylon flat	6
33	999-0457	Screw 1/4-20 x 3/4 flat head phillips stainless steel	8
34	202-2210	Washer 3/8 x 3/4 flat nylon	12
35	202-2145	Washer 3/4 rubber	4
36	999-0547	Bolt 5/16-18 x 1/2 hex head stainless steel	10
37	999-0562	Bolt 3/8-16 x 1 hex head stainless steel	4
38	999-1113	Bolt 1/2-13 x 2 1/2 hex cap stainless steel	1
39	999-0086	Nut 10-32 nylon insert lock zinc plated	3
40	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	1
41	999-0423	Nut 5/16-18 nylon insert lock stainless steel	32
42	999-1208	Nut 1/2-13 nylon insert lock stainless steel	1
43	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	1
44	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	18
45	999-0559	Washer 1/2 x 1/4 flat stainless steel	2
46	999-0553	Washer 5/16 medium split lock stainless steel	10
47	999-0659	Washer 3/8 medium split lock stainless steel	10
48	999-0894	Screw 3/8-16 x 2 1/2 carriage head stainless steel	6
49	999-0916	Screw 8-32 x 1/2 pan head phillips stainless steel	4
51	999-0867	Bolt 1/4-20 x 3/4 button head socket cap stainless steel	3
53	202-3077	Carriage bolt 5/16 x 1-1/2 stainless steel	2
54	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	10
55	999-0967	Bolt 5/16-18 x 3/4 carriage head stainless steel	8
56	999-9066	Bolt 5/16-18 x 1 carriage head stainless steel	4
57	999-1370	Bolt 5/16-18 x 1 1/2 carriage head stainless steel	4
58	999-0566	Washer 1/2 flat nylon	4
59	999-1258	Screw 5/16-18 x 3/4 flat head phillips stainless steel	4
60	202-0140	Steering shaft key	1
61	999-0304	Nut 1/4-20 nylon lock jam stainless steel	10
62	999-9071	Nut 3/8-16 nylon insert jam lock stainless steel	4
63	202-9545	Plug,Square,3/4 inch,Black	2
64	202-4226	Solution hose	1
65	202-4227	Hose	1
66	202-5100	Left side deck lifting bracket	1	(right side)
67	202-5101	Right side deck lifting bracket	1	(left side)
68	202-5111	Isolator kit (pkg of 6)	1	(includes 10 isolators, 10 bolts, 10 washers, 10 lock washers, 10 nylock nuts)
69a	202-5530	24 inch feed tube kit	1	(for 24 inch)
69b	202-5093	28 inch solution feed tube	1	(for 28 inch)
70a	202-5529	24 inch square deck	1
70b	202-7031	Kit, Deck, Square Head, SS, 28 inch	1
71a	202-5112	linatex wiper	1
71b	202-5112	linatex wiper	1
71c	202-5113	Polyurethane wiper	1
72	202-2186	Eccentric kit	1	(includes 1 eccentric, 8 bolts, 1 pack blue loctite)
73a	202-2182	24 inch driver plate aluminum	1
73b	202-2183	28 inch driver plate aluminum	1
74	202-2180	Isolator kit	1	(includes 4 isolators, 4 bolts, 4 nuts)
75a	202-2184	24 inch grip face	1
75b	202-2185	28 inch grip face	1
N/S	202-9662	Isolator	4
N/S	999-0457	Screw 1/4-20 x 3/4 flat head phillips stainless steel	8
N/S	202-2831	Screw 5/16-18 x 3/4 flat head socket stainless steel	4

Rear Options Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(spray jet hose)
2	202-9928	Power cord AC	1
3	202-0090	Wand clip	3
4	202-0103	Spray nozzle	1
5	202-8241	Charger, 36V,25A Onboard, Universal Charger w/Power Cord	1
6	202-3808	Horizontal charger mount	1
7	202-7540	Light,48V,Blue,LED	1
8	202-3635	Cord wrap	1
9	202-3802	Hose wrap	2
10	202-9804	Tank utility handle	1
11	202-0383	Strobe light	1
12	999-1928	Nut 1/2 inch lock brass	1
13	999-1929	Pipe cap 1/2 inch female brass	1
14	999-0086	Nut 10-32 nylon insert lock zinc plated	9
17	999-1290	Screw #14 x 1 truss head phillips stainless steel	4
18	999-1350	Screw 10-32 x 1/2 inch phillips pan head stainless steel	6
19	202-2122	Screw 10-32 x 5/8 inch phillips pan head	3
20	999-1507	Screw 5/16-18 x 1 button head socket stainless steel	1
21	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	4
23	999-1019	Nut 5/16-18 hex jam stainless steel	1
24	202-3439	Male brass fitting	1
25	202-4003	Grommet	2
26	202-3805	Tubing cover	1
N/S	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	4
N/S	999-1482	Nut 3/8-16 nylon lock stainless steel	1
N/S	202-9411	Bolt,Carriage,1/4-20 x 4.5 inch	4

Recovery Tank Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(thread cover black tubing)
2	N/A	Not available	1	(spray jet hose)
3	202-0703	Elbow	1
4	202-3127	4 inch chain (6 inch no longer available)	1
5	202-0232	Float shut-off ball	1
6	202-0230	Strainer gasket	1
7	202-1487	Latch	1
8	997-2011	Hose clamp	1
9	202-0675	Detergent warning plate	1
10	202-0090	Wand clip	1
11	202-0103	Spray nozzle	1
12	202-5710	Squeegee vacuum hose 1.5 x 55 inch	1
13	202-4330	Vacuum hose	1
14	202-5650	Rubber gasket	1
15	202-5648	4 inch hinge stainless steel	1
17	202-4186	Sight tube	1
18	202-5655	Tank lid assembly	1
19	202-5651	Vacuum inlet screen	1
20	202-3573	Recovery tank (granite)	1
21	202-4187	Elbow	1
22a	202-5652	Vacuum inlet gasket	1	(rounded corner)
22b	302-0266	Solution fill gasket (round)	1	(round)
23	202-5653	Small drain saver basket	1
24	202-3802	Hose wrap	1
25	202-9804	Tank utility handle	1
26	202-3785	Recovery drain hose w/ turn cap	1
27	202-0231	Filter screen	1
28	999-0429	Nut 1/4-20 acorn nickel plated	1
29	999-1928	Nut 1/2 inch lock brass	1
30	999-1929	Pipe cap 1/2 inch female brass	1
31	999-0334	Bolt 1/4-20 x 3/4 inch hex head stainless steel	2
32	999-0297	Bolt 1/4-20 x 1 hex head stainless steel	1
33	999-0086	Nut 10-32 nylon insert lock zinc plated	1
34	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	1
35	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	3
36	999-0632	Washer 1/4 split lock stainless steel	3
37	999-1290	Screw #14 x 1 truss head phillips stainless steel	1
38	999-1350	Screw 10-32 x 1/2 inch phillips pan head stainless steel	1
39	202-2122	Screw 10-32 x 5/8 inch phillips pan head	1
40	999-1044	Screw 10-32 x 3/4 pan head phillips stainless steel	1
41	999-1930	Screw #6-18 x 3/8 phillips pan head SS	1
42	999-0870	Screw 8 x 3/4 pan head phillips stainless steel	2
43	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	1
44	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	1
45	202-3244	Neoprene washer	1
46	202-3439	Male brass fitting	1

Side Broom Assembly

Click to enlarge

#	Part	Description	Req
1	202-1495	Polypropylene side broom	2
2	202-3066	36V motor left hand	1
3	302-0131	36V motor	1
4	202-1932	36V actuator	1
5	202-3071	Pivot bracket	1
6	202-1397	Flanged bushing	2
9	202-3702	Left hand side arm broom	1
10	202-3703	Left hand side broom axle bracket	1
11	202-3704	Right hand side broom axle bracket	1
12	202-3083	Clevis pin	1
13	202-2216	Shaft collar with set screw	2
14	999-0423	Nut 5/16-18 nylon insert lock stainless steel	6
15	999-0559	Washer 1/2 x 1/4 flat stainless steel	2
16	999-0990	Screw 1/4-20 x 5/8 flat head phillips stainless steel	2
17	999-1480	Screw 1/4-20 x 5/8 button head socket cap stainless steel	4
18	202-3077	Carriage bolt 5/16 x 1-1/2 stainless steel	2
19	999-0919	Bolt 5/16-18 x 1 1/4 carriage head stainless steel	4
20	999-0346	Screw 5/16-18 x 1/4 set cup point socket alloy plain finish	2
21	202-2059	Cotter ring	1
22	202-1495	Polypropylene side broom	1

Solution System Assembly

Click to enlarge

#	Part	Description	Req
2	202-3584	Inline filter	1
3	202-9782	Filter screen (black)	1
4	202-1008	Barbed elbow	1
5	202-2368	36V water jet pump	1
6	202-0332	1/2 inch barbed tee	1
7	202-0333	Elbow barb	2
8	202-0107	1/2 inch hosebarb	1
9	202-3038	36V solenoid valve	1
10	202-0884	Barbed elbow	1
11	202-0680	Hose clamp	4
12	202-9642	3/4 inch clamp zinc	2
13	202-5106	Reinforced hose 1/2 x 60 inch	1
14	202-5106	Reinforced hose 1/2 x 60 inch	1
15	202-5106	Reinforced hose 1/2 x 60 inch	1
16	202-5106	Reinforced hose 1/2 x 60 inch	1
17	202-5106	Reinforced hose 1/2 x 60 inch	1
18	202-5106	Reinforced hose 1/2 x 60 inch	1

Solution Tank Assembly

Click to enlarge

#	Part	Description	Req
1	202-4091	Tank strap	1
2	202-3373	Drain hose cap	2
3	202-3036	Strainer screen	1
4	202-5630	Soft draw latch	2
5	202-3279	Tank support strap	2
6	202-0692	Polypropylene ball	1
7	202-0686	90 degree barb 1/4 x 1/4	2
8	202-3270	Vertical float valve switch w/ washer	1
9	202-2734	Corner seal strip	1
10	202-8038	4 inch Clear Access Port	1
11	202-0403	Hinge	2
12	202-4106	O-ring	2
13	202-5638	Seat switch	2
15	202-4183	Sight tube	1
16	202-4184	Drain saver curtain	1
17	202-9790	Seat	1
18	202-3574	Solution tank (granite)	1
19	202-9797	Tank cable	2
20	202-0884	Barbed elbow	1
21	999-0334	Bolt 1/4-20 x 3/4 inch hex head stainless steel	6
22	999-0423	Nut 5/16-18 nylon insert lock stainless steel	4
23	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	6
24	999-0632	Washer 1/4 split lock stainless steel	6
25	202-2918	Screw 1/4-20 x 3/4 self tapping	6
26	999-0870	Screw 8 x 3/4 pan head phillips stainless steel	4
27	202-4188	Screw #10	6
28	999-0617	Washer 3/8 x 1 flat stainless steel	4
29	202-9496	Elbow, 1/4 inch Barb x 3/4 inch NPT Black	1
30	202-3576	Seal	1
N/S	202-5638	Seat switch	1

Squeegee Assembly

Click to enlarge

#	Part	Description	Req	Notes
0a	202-9631	31 inch squeegee assembly	1	(includes 1-21, 23a, 24a, 25a, 26a, 27a)
0b	202-9632	33 inch squeegee assembly (OBSOLETE)	1	(includes 1-21, 23b, 24b, 25b, 26b, 27b)
0c	202-9765	37 inch squeegee complete	1	(includes 1-21, 23c, 24c, 25c, 26c, 27c)
0d	202-9634	41 inch squeegee assembly	1	(includes 1-21, 23d, 24d, 25d, 26d, 27d)
0e	202-9635	45 inch squeegee assembly	1	(includes 1-21, 23e, 24e, 25e, 26e, 27e)
1	202-5078	Star knob	2
2	202-5079	4 inch wheel	2
3	202-3590	2 inch caster (gray)	2
4	202-3651	1 1/2 inch standoff	2
5	202-9688	Steel tube	2
6	202-3655	Roller spacer	2
7	202-3656	41 inch squeegee decal	1
8	202-9697	Squeegee caster bracket	2
9	202-9739	Left hand squeegee caster bracket	1
10	202-3658	Right hand squeegee castor bracket	1
11	999-0488	Nut 3/8-16 flange lock serrated zinc plated	2
12	999-0357	Nut 8-32 nylon insert lock stainless steel	2
13	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	8
14	999-0423	Nut 5/16-18 nylon insert lock stainless steel	2
15	999-1482	Nut 3/8-16 nylon lock stainless steel	2
16	999-1044	Screw 10-32 x 3/4 pan head phillips stainless steel	2
17	202-3077	Carriage bolt 5/16 x 1-1/2 stainless steel	2
18	999-1401	Bolt 1/4-20 x 1 carriage head stainless steel	4
19	999-0605	Screw 1/4-20 x 2 carriage head stainless steel	4
20	202-2832	Bolt 3/8 - 16 x 1 carriage head stainless steel	2
21	999-0626	Screw 3/8-16 x 3 carriage head stainless steel	2
22	202-9697	Squeegee caster bracket	1	(for squeegee without casters)
23a	202-3667	31 inch squeegee weight	1
23b	202-3668	33 inch squeegee weight	1
23c	202-3669	37 inch squeegee weight	1
23d	202-3657	41 inch squeegee weight	1
23e	202-3670	45 inch squeegee weight	1
24a	202-3671	Squeegee band 31 inch rear with latch	1
24b	202-3672	Squeegee band 33 inch rear with latch	1
24c	202-3673	Squeegee band 37 inch rear with latch	1
24d	202-9610	Complete rear squeegee band	1
24e	202-3674	Squeegee band 45 inch rear with latch	1
25a	202-3675	Squeegee band 31 inch front with latch	1
25b	202-3676	Squeegee band 33 inch front with latch	1
25c	202-3677	Squeegee band 37 inch front with latch	1
25d	202-3678	Squeegee band 41 inch front with latch	1
25e	202-3679	Squeegee band 45 inch front with latch	1
26a	202-3680	Squeegee body 31 inch stainless steel	1
26b	302-0260	Squeegee body 33 inch stainless steel	1
26c	202-3682	Squeegee body 37 inch stainless steel	1
26d	202-3683	Squeegee body 41 inch stainless steel	1
26e	302-0163	45 inch squeegee body	1
27a	202-3685	Squeegee spacer 31 inch bottom	1
27b	202-3686	Squeegee spacer 33 inch bottom	1
27c	202-3687	Squeegee spacer 37 inch bottom (OBSOLETE)	1
27d	202-3688	Squeegee spacer 41 inch bottom	1
27e	202-3689	Squeegee spacer 45 inch bottom	1
N/S	202-3690	Squeegee blade 31 inch linatex front v2.1	1	(front blade v2.0)
N/S	202-3662	Squeegee blade 31 inch linatex rear v2.1	1	(rear blade v2.0)
N/S	202-3691	Squeegee blade 33 inch linatex front	1	(front blade v2.0)
N/S	302-0244	Squeegee blade 33 inch linatex rear	1	(rear blade v2.0)
N/S	202-3692	Squeegee blade 37 inch linatex front	1	(front blade v2.0)
N/S	202-3664	Squeegee blade 37 inch linatex rear	1	(rear blade v2.0)
N/S	202-9611	Squeegee blade front linatex	1	(front blade v2.0)
N/S	202-3694	Squeegee blade 45 inch linatex front	1	(front blade v2.0)
N/S	202-3666	Squeegee blade 45 inch linatex rear	1	(rear blade v2.0)

Squeegee Fixed Trail Arm Assembly - Optional

Click to enlarge

#	Part	Description	Req
1	202-6417	Knob,Yellow	1
3	202-0403	Hinge	2
4	202-9730	3 in 1 tool	1
5	202-9731	Squeegee lift plate	1
6	202-9732	Squeegee adjustment bracket	2
7	202-9733	Squeegee triangle plate	1
8	202-9734	Adjustable rod end anchor	1
9	202-9735	Adjustable rod end	1
10	999-1871	Bolt 3/8-16 x 5 hex head full thread tapping stainless steel	1
11	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	17
12	999-1482	Nut 3/8-16 nylon lock stainless steel	7
13	999-1044	Screw 10-32 x 3/4 pan head phillips stainless steel	1
14	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	20
N/S	202-3590	2 inch caster (gray)	2
N/S	202-2208	Compression spring	2

Squeegee Swing Trail Arm Assembly - Standard

Click to enlarge

#	Part	Description	Req
1	302-0132	3 in 1 tool	1
2	202-6417	Knob,Yellow	1
3	202-6431	Body, Adjustable Lateral Arm	1
4	202-6443	Rod End, Adjustable, LH	1
5	202-6444	Rod End, Adjustable, RH	1
6	202-3590	2 inch caster (gray)	2
7	202-8256	Arm, Squeegee Trail	1
8	202-8266	Bracket, Squeegee Drag, Mounting	1
9	202-8391	Squeegee Swing Plate	1
10	302-0257	Squeegee triangle plate	1
11	202-9158	Nut,Hex Jam,5/16-18 LH	1
12	202-2210	Washer 3/8 x 3/4 flat nylon	10
13	999-0298	Bolt 1/4-20 x 1 1/4 hex head stainless steel	2
14	999-0556	Bolt 5/16-18 x 3/4 hex head stainless steel	2
15	999-0593	Nut 5/16-18 hex stainless steel	1
16	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	2
17	999-0423	Nut 5/16-18 nylon insert lock stainless steel	6
18	999-1482	Nut 3/8-16 nylon lock stainless steel	5
19	999-0617	Washer 3/8 x 1 flat stainless steel	3
20	999-1044	Screw 10-32 x 3/4 pan head phillips stainless steel	1
21	999-0967	Bolt 5/16-18 x 3/4 carriage head stainless steel	4
22	202-2832	Bolt 3/8 - 16 x 1 carriage head stainless steel	3
23	999-0563	Washer 1/4 x 1/16 flat nylon	2
24	202-2208	Compression spring	2

Steering Column and Central Command Assembly

Click to enlarge

#	Part	Description	Req
4	202-0717	Drive cover	1
5	202-0761	Upper steering shaft	1
6	202-0760	U-joint	1
7	202-2404	Fitting	1
12	202-0773	Steering cover	1
13	202-8461	Lid,Recovery Tank,Blank (OBSOLETE)	1
14	202-1196	Washer 17/64 x 21/64 nylon flat	6
15	202-0847	Square keyway	2
21	202-3154	Screw 1/4-20 x 1/4 set	3
22	999-0069	Nut 5/16-18 hex	10
23	202-2216	Shaft collar with set screw	3
24	999-0424	Bolt 5/16-18 x 1 hex head stainless steel	11
26	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	11
27	999-0553	Washer 5/16 medium split lock stainless steel	11
28	999-0986	Screw 10-32 x 1 round pan head stainless steel	6
29	999-0867	Bolt 1/4-20 x 3/4 button head socket cap stainless steel	6
31	999-0346	Screw 5/16-18 x 1/4 set cup point socket alloy plain finish	3
32a	202-4333	Front apron (granite)	1
32b	202-4334	Front apron (red)	1
N/S	202-4335	Central command	1
N/S	202-0756	Guide roller	1
N/S	202-1008	Barbed elbow	1
N/S	202-4336	Jaw roller	1
N/S	202-2368	36V water jet pump	1
N/S	202-5546	9-60V LED head light	1
N/S	202-4337	Non skid floor plate	1
N/S	999-1508	Bolt 10-32 x 5/8 round carriage head stainless steel	1
N/S	999-1982	Bolt 10-32 x 1 round carriage head stainless steel	2
N/S	202-3236	Threaded barb	1
N/S	202-0680	Hose clamp	1
N/S	202-3601	Nut #10-32 hex crimp	6
N/S	999-0704	Nut 5/8-11 nylon insert lock stainless steel	1
N/S	999-9066	Bolt 5/16-18 x 1 carriage head stainless steel	3

Steering Column Assembly

Click to enlarge

#	Part	Description	Req
1	202-4191	Emergency stop button	1
2	202-1181	Washer 1/2 flat bronze	2
3	202-0719	Index plunger	1
4	202-3312	Flanged bearing	2
5	202-0142	Upper steering bearing	1
6	202-0143	Bearing mount	2
7	202-4190	Steering tower decal	1
8	202-0381	Horn button	1
9	202-1196	Washer 17/64 x 21/64 nylon flat	6
10	999-1508	Bolt 10-32 x 5/8 round carriage head stainless steel	1
11	202-2431	P clamp	1
12	202-4161	Dome plug	1
13	999-0190	Nut 1/4-20 hex plain finish	10
14	202-3315	Blind rivet	4
15	999-0593	Nut 5/16-18 hex stainless steel	4
16	999-0086	Nut 10-32 nylon insert lock zinc plated	1
17	999-0423	Nut 5/16-18 nylon insert lock stainless steel	2
18	999-0549	Washer 5/16 x 3/4 SAE flat stainless steel	2
19	999-0553	Washer 5/16 medium split lock stainless steel	3
20	999-1509	Screw 10-32 x 3/8 flat head phillips stainless steel	2
21	999-0867	Bolt 1/4-20 x 3/4 button head socket cap stainless steel	6
22	999-1507	Screw 5/16-18 x 1 button head socket stainless steel	6
23a	202-0715	Upper steering column (red)	1
23b	202-2012	Upper steering column (granite)	1
24a	202-0716	Pedestal cover (red)	1
24b	202-2013	Pedestal cover (granite)	1
25a	202-4331	Lower steering pedestal (red)	1
25b	202-4332	Lower pedestal with crimp nuts (granite)	1

Suds Sysstem Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(suds drain hose)
2	N/A	Not available	1	(green drain hose)
4	202-5483	1/4 inch two way ball valve brass	1
5	202-3584	Inline filter	1
6	202-9782	Filter screen (black)	1
7	202-1008	Barbed elbow	1
8	202-3301	36V soap pump	1
9	202-2368	36V water jet pump	1
10	202-0332	1/2 inch barbed tee	1
11	202-0333	Elbow barb	2
12	202-0107	1/2 inch hosebarb	1
13	202-3038	36V solenoid valve	1
14	202-9129	Clamp,Loop,5/8 inch,Rubber	2
16	202-0680	Hose clamp	5
17	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	1
18	999-0963	Bolt 1/4-20 x 3/4 carriage head stainless steel	1
20	202-9475	Fitting, 1/4 NPTF x 3/16 Barb	1
21	202-9489	Fitting,1/4 inchNPTx1/4 inchBarb	1
22	202-9499	Tee, 1/4 inch, Plastic	1
23	202-9642	3/4 inch clamp zinc	2
24	202-4229	Hose 1/4 inch x 5 foot	1
25	202-4229	Hose 1/4 inch x 5 foot	1
26	202-5106	Reinforced hose 1/2 x 60 inch	1
26	202-5106	Reinforced hose 1/2 x 60 inch	1
27	202-5106	Reinforced hose 1/2 x 60 inch	1
28	202-5106	Reinforced hose 1/2 x 60 inch	1
29	202-5106	Reinforced hose 1/2 x 60 inch	1
30	202-5106	Reinforced hose 1/2 x 60 inch	1
31	202-5106	Reinforced hose 1/2 x 60 inch	1
N/S	202-0884	Barbed elbow	1
N/S	202-3343	Barbed fitting	1
N/S	202-9788	Citrus green soap	1
N/S	202-3779	Low PH soap	1
N/S	202-3780	High power soap	1
N/S	202-3781	Gloss	1
N/S	202-9789	HD cleaner	1

Touch Central Command 1

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(QR code)
2	202-5893	Bracket, Hose	1
3	202-5903	Air Dryer Assembly	1
4	202-3622	Power keychain	1
6	202-6396	Power Post, Black, 1/4 Terminal	1
8	202-2300	Key switch with key entry (red) and ring (black)	1
10	991-1634	Key (pkg of 2)	2
12	202-7287	Resistor,Wirewound,8 OHM,50W	3
13	202-3307	36V relay with mounting plate	2
14	202-1992	Toggle switch	5
19	202-8269	Decal, Central Command	1
20	202-9675	Central command dust curtain	1
21	202-9530	Vinyl Foam Rubber 1/8 inch Thick 1 /4 inch Wide 17' Length	1
22	202-9676	Touch control panel top (blue)	1
23	202-9677	Touch screen protector	1
24	202-3811	Resistor plate	1
26	202-8389	Controller, Touch Screen	1
27	202-8390	LCD Touch Screen	1
28	202-4244	Resister	3
29	202-0541	Busbar	2
32	202-0704	Hinge	1
33	202-0830	Busbar (5 hole)	2
35	999-1570	Bolt 10-32 x 1 1/4 round head carriage stainless steel	2
37	202-1864	Toggle switch protective boot (red)	1
41	999-0435	Screw 1/4-20 x 5/8 socket head alloy plain finish	4
42	999-0190	Nut 1/4-20 hex plain finish	7
43	999-0086	Nut 10-32 nylon insert lock zinc plated	4
44	999-0294	Nut 1/4-20 hex nylon lock type NE stainless steel	5
45	999-1464	Nut 8-32 keps lock with external tooth lockwasher ss	6
46	202-2067	Nut 10-32 keps	2
47	999-1466	Nut 1/4-20 lock with external toothed lockwasher SS	4
48	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	6
49	999-0916	Screw 8-32 x 1/2 pan head phillips stainless steel	2
50	999-1574	Screw 8-32 x 1 pan head phillips stainless steel	4
51	202-2370	Screw 4-40 x 1/2 Phillips pan head stainless steel	12
52	999-1350	Screw 10-32 x 1/2 inch phillips pan head stainless steel	2
53	999-1993	Screw #4-40 x 3/8 flat head phillips	4
54	999-1919	#8-15 x 1/2 phillips pan head sheet metal SS	10
55	999-0867	Bolt 1/4-20 x 3/4 button head socket cap stainless steel	4
56	999-1442	Bolt 1/4-20 x 1/2 carriage stainless steel	4
57	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	5
58a	202-9678	Touch screen control panel (red)	1
58b	202-9679	Touch screen control panel (granite)	1
59a	202-9672	Access cover (red)	1
59b	202-9671	Access cover (granite)	1
N/S	202-3302	Bolt 10-32 x 1/2 carriage head stainless steel	2

Touch Central Command 2

Click to enlarge

#	Part	Description	Req
5	202-3622	Power keychain	1
7	202-0832	Full recovery indicator (red)	1
8	202-2300	Key switch with key entry (red) and ring (black)	1
9	202-7203	Light,24V,Green,Bulb Style	1
10	991-1634	Key (pkg of 2)	2
11	202-7204	Light,24V,Yellow,Bulb Style	2
14	202-1992	Toggle switch	5
15	202-2499	15amp fuse	2
16	202-0341	6 Amp circuit breaker	1
17	202-8199	Breaker, 5a	2
18	202-0090	Wand clip	1
25	202-3818	Front control panel sticker	1
30	202-0822	2amp fuse	1
31	202-3625	Dual USB ports	1
36	202-1976	Toggle switch protective boot (white)	1
38	202-1866	Toggle switch protective boot (green)	1
39	202-1355	Toggle switch protective boot (black)	1
40	202-3465	Toggle switch protective boot (orange)	1
41	999-0435	Screw 1/4-20 x 5/8 socket head alloy plain finish	4

Vacuum Motor Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(2 inch hose)
2	N/A	Not available	1	(clean air intake)
3	N/A	Not available	1	(vacuum box drain)
4	N/A	Not available	1	(vacuum switch hose)
5	N/A	Not available	1	(hose)
6	202-6320	Flap,Drain Saver Basket	1
7	202-1908	Vacuum shut-off switch	1
8	997-2011	Hose clamp	2
9	202-9680	Vac box	1
10	202-9681	Vac muffler housing	1
11	202-9682	2 1/8 inch plastic spacer	3
12	202-9683	Vac motor gasket set	2
13	202-9684	36V 2 stage vacuum motor	1
15	202-9338	Screw,Hex Cap,1/4-20x3 inch Stainless	3
16	999-0335	Washer 1/4 x 5/8 SAE flat stainless steel	3
17	999-0632	Washer 1/4 split lock stainless steel	3
18	202-9488	Fitting,1/4 inchNPTx1/8 inchBarb	2
19	202-1986	Washer 3/8 x 1-1/8 x 3/32 neoprene thread	3
N/S	202-9255	PPH SMS #10 x 1/2 inch SBO	2

ZerO3 System Assembly

Click to enlarge

#	Part	Description	Req	Notes
1	N/A	Not available	1	(blue zero hose)
2	N/A	Not available	1	(hose)
3	202-5892	Red Injector	1
4	202-5893	Bracket, Hose	1
5	202-5895	Pump,12v, 35PSI, 1 GPM	1
6	202-5903	Air Dryer Assembly	1
7	202-3772	36V solenoid valve	1
12	202-0333	Elbow barb	2
13	202-9687	Corona generator pack (pkg of 3)	2
14	202-3236	Threaded barb	2
15	202-2851	Bolt 1/4-20 x 5/8 inch carriage head stainless steel	1
16	202-9476	Fitting, 3/8 NPTF x 1/4 inch Barb	1
17	202-5379	3/8 inch elbow	1
18	202-9642	3/4 inch clamp zinc	2
19	202-4225	Hose	1
20	202-4225	Hose	1
21	202-4225	Hose	1
