- Batteries and Chargers

#PartDescription ReqNotesAvailability
162-0003 6V 225Ah wet battery (SNSR) 4
162-0043 6V 224Ah AGM battery (Group GC2) (SNSR) 4
777-9102 24V 100amp Lithium Ion battery pack kit w/ charger 1
272-2358 24V onboard battery charger 1

- Commonly Asked For Parts

#PartDescription ReqNotesAvailability
01 272-6583 Vacuum hose assembly
02 272-5577 Drain hose
03 272-7313 Shoe linkage hardware kit
04 272-7315 Shoe assembly
05 272-7373 Hose assembly
06 272-7376 Blade hopper
07 272-7436 Tension belt
08 272-7437 Spindle assembly
09 372-3326 Control board kit

- Extractor Fit All Parts

#PartDescription ReqNotesAvailability
001a 991-8000 12 inch stainless head wand, 1 jet 120 PSI plastic valve (wands)
001b 991-8001 12 inch aluminum head wand, 2 jet, 120 PSI (OBSOLETE) (wands)
001c 991-8002 12 inch aluminum head wand, 3 jet, 120 PSI plastic valve (wands)
001d 991-8227 500psi brass valve (wands)
002a 991-8222 30 inch stair wand (open spray) (stair wand)
002b 991-8223 30 inch swivel head ergonomic stair wand (open spray) (stair wand)
004 991-8129 Handle 1-1/2 inch low profile comfort grip assist (wands)
005a 991-8128 120 PSI, acetel plastic valve, low heat 140 degrees (wands)
005b 991-8127 120 PSI, brass valve, stainless steel stem (wands)
005c 991-8226 Valve
005d 991-8171 400psi cast aluminum valve
007 991-8130 3-1/2 inch wide 120 PSI standard detailer, external spray (wands)
008 991-8132 10ft hide-a-hose vac/sol hose assembly w/1/4 male fittings (hose assemblies and parts)
009 991-8133 20ft hide-a-hose vac/sol hose assembly w/1/4 male fittings (hose assemblies and parts)
010 991-8136 10ft hide-a-hose vac/sol hose assembly w 1/4 male & 1/4 feml (hose assemblies and parts)
011 991-8137 20ft hide-a-hose vac/sol hose assembly w/1/4 male & 1/4 feml (hose assemblies and parts)
012 991-8134 10ft hide-a-hose vac/sol hose w/1/4 female fittings 300psi (hose assemblies and parts)
013 991-8135 20ft hide-a-hose vac/sol hose assembly w/1/4 female fittings (hose assemblies and parts)
014 991-8138 10ft 100psi vac/sol hose assembly w/ 1/4 male fittings (hose assemblies and parts)
015 991-8139 20ft 100psi vac/sol hose assembly with male fittings (hose assemblies and parts) (Maximum heat rating of 70 degrees and 100 PSI)
016 991-8142 10ft 100psi vac/sol hose assembly w/1/4 female & 1/4 male (hose assemblies and parts)
017 991-8143 20ft 100psi vac/sol hose assembly w/1/4 female & 1/4 male (hose assemblies and parts)
018 991-8140 10ft 100psi vac/sol hose assembly w/ 1/4 female fittings (hose assemblies and parts)
021 991-8286 1 1/2 inch vacuum hose (sold by the foot) (hose assemblies and parts)
022 991-8005 1 1/2 inch replacement hose cuff (black) (hose assemblies and parts)
023 991-8131 1 1/2 inch hide-a-hose cuff (no swivel) (hose assemblies and parts)
026 991-8045 1/8 inch brass vee jet 8001 (1/8 brass vee jet)
027 991-8046 1/8 inch brass vee jet 8001.5 (1/8 brass vee jet)
028 991-8047 1/8 inch brass vee jet 8002 (1/8 brass vee jet)
029 991-8048 1/8 inch brass vee jet 8003 (1/8 brass vee jet)
030 991-8049 1/8 inch brass vee jet 8004 (1/8 brass vee jet)
031 991-8050 1/8 inch brass vee jet 8005 (OBSOLETE) (1/8 brass vee jet)
032 991-8051 1/8 inch brass vee jet 8006 (1/8 brass vee jet)
033 991-8052 1/8 inch brass vee jet 8008 (1/8 brass vee jet)
034 991-8053 1/8 inch brass vee jet 8010 (1/8 brass vee jet)
035 991-8054 1/8 inch brass vee jet 9502 (1/8 brass vee jet)
036 991-8055 1/8 inch brass vee jet 9503 (1/8 brass vee jet)
037 991-8056 1/8 inch brass vee jet 9504 (1/8 brass vee jet)
038 991-8057 1/8 inch brass vee jet 9505 (1/8 brass vee jet)
039 991-8058 1/8 inch brass vee jet 9506 (1/8 brass vee jet)
040 991-8059 1/8 inch brass vee jet 9508 (1/8 brass vee jet)
041 991-8060 1/8 inch brass vee jet 11001 (1/8 brass vee jet)
042 991-8061 1/8 inch brass vee jet 11001.5 (1/8 brass vee jet)
043 991-8062 1/8 inch brass vee jet 11002 (1/8 brass vee jet)
044 991-8063 1/8 inch brass vee jet 11003 (1/8 brass vee jet)
045 991-8064 1/8 inch brass vee jet 11004 (1/8 brass vee jet)
046 991-8065 1/8 inch brass vee jet 11005 (1/8 brass vee jet)
047 991-8066 1/8 inch brass vee jet 11006 (1/8 brass vee jet)
048 991-8067 1/8 inch brass vee jet 11008 (1/8 brass vee jet)
049 991-8068 1/8 inch brass vee jet 11010 (1/8 brass vee jet)
050 991-8021 1/4 inch brass vee jet 8001 (1/4 brass vee jet)
051 991-8022 1/4 inch brass vee jet 8001.5 (1/4 brass vee jet)
052 991-8023 1/4 inch brass vee jet 8002 (1/4 brass vee jet)
053 991-3005 1/4 inch brass vee jet 8003 (1/4 brass vee jet)
054 991-8025 1/4 inch brass vee jet 8004 (1/4 brass vee jet)
055 991-8026 1/4 inch brass vee jet 8005 (1/4 brass vee jet)
056 991-8027 1/4 inch brass vee jet 8006 (1/4 brass vee jet)
057 991-8028 1/4 inch brass vee jet 8008 (1/4 brass vee jet)
058 991-8029 1/4 inch brass vee jet 8010 (1/4 brass vee jet)
059 991-8030 1/4 inch brass vee jet 9502 (1/4 brass vee jet)
060 991-8031 1/4 inch brass vee jet 9503 (1/4 brass vee jet)
061 991-8032 1/4 inch brass vee jet 9504 (1/4 brass vee jet)
062 991-8033 1/4 inch brass vee jet 9505 (1/4 brass vee jet)
063 991-8034 1/4 inch brass vee jet 9506 (1/4 brass vee jet)
064 991-8035 1/4 inch brass vee jet 9508 (1/4 brass vee jet)
065 991-8036 1/4 inch brass vee jet 11001 (1/4 brass vee jet)
066 991-8037 1/4 inch brass vee jet 11001.5 (1/4 brass vee jet)
067 991-8038 1/4 inch brass vee jet 11002 (1/4 brass vee jet)
068 991-8039 1/4 inch brass vee jet 11003 (1/4 brass vee jet)
069 991-8040 1/4 inch brass vee jet 11004 (1/4 brass vee jet)
070 991-8041 1/4 inch brass vee jet 11005 (OBSOLETE) (1/4 brass vee jet)
071 991-8042 1/4 inch brass vee jet 11006 (1/4 brass vee jet)
072 991-3006 1/4 inch brass vee jet 11008 (1/4 brass vee jet)
073 991-8044 1/4 inch brass vee jet 11010 (1/4 brass vee jet)
074 991-8069 1/4 inch stainless vee jet 8001 (1/4 stainless vee jet)
075 991-8070 1/4 inch stainless vee jet 8002 (1/4 stainless vee jet)
076 991-8071 1/4 inch stainless vee jet 8003 (1/4 stainless vee jet)
077 991-8072 1/4 inch stainless vee jet 8004 (1/4 stainless vee jet)
078 991-8073 1/4 inch stainless vee jet 9501 (1/4 stainless vee jet)
079 991-8074 1/4 inch stainless vee jet 9502 (1/4 stainless vee jet)
080 991-8085 1/4 inch stainless/plastic tee jet 9502 (1/4 stainless vee jet)
081 991-8076 1/4 inch stainless vee jet 9504 (1/4 stainless vee jet)
082 991-8077 1/4 inch stainless vee jet 11003 (1/4 stainless vee jet)
083 991-8078 1/4 inch stainless vee jet 11004 (1/4 stainless vee jet)
084 991-8079 1/4 inch stainless vee jet 11006 (1/4 stainless vee jet)
085 991-8080 1/4 inch stainless vee jet 11008 (1/4 stainless vee jet)
086 991-8081 1/4 inch stainless/plastic tee jet 8002 (1/4 stainless/plastic tee jet)
087 991-8082 1/4 inch stainless/plastic tee jet 8003 (1/4 stainless/plastic tee jet)
088 991-8083 1/4 inch stainless/plastic tee jet 8004 (1/4 stainless/plastic tee jet)
089 991-8084 1/4 inch stainless/plastic tee jet 9501 (OBSOLETE) (1/4 stainless/plastic tee jet)
090 991-8085 1/4 inch stainless/plastic tee jet 9502 (1/4 stainless/plastic tee jet)
091 991-8086 1/4 inch stainless/plastic tee jet 9504 (1/4 stainless/plastic tee jet)
092 991-3010 1/4 inch stainless/plastic tee jet 11003 (1/4 stainless/plastic tee jet)
093 991-8088 1/4 inch stainless/plastic tee jet 11004 (1/4 stainless/plastic tee jet)
094 991-8089 1/4 inch stainless/plastic tee jet 11006 (1/4 stainless/plastic tee jet)
095 991-8090 1/4 inch stainless/plastic tee jet 11008 (1/4 stainless/plastic tee jet)
096 991-8091 1/4 inch x 1/8 hex nipple H21
097 991-8092 1/4 inch x 1/4 hex nipple H22
098 991-8093 1/4 inch x 3/8 hex nipple H23
099 991-8094 45 degree street elbow 1/4 inch H24
100 991-8095 45 degree street elbow 1/8 inch H25
101 991-8096 45 degree union elbow 1/4 inch H26
102 991-8098 90 degree street elbow short 1/4 inch H28
103 991-8098 90 degree street elbow short 1/4 inch H28
104 991-8099 90 degree street elbow 1/8 inch H29
105 991-8100 90 degree street elbow short 1/8 inch H30 (OBSOLETE)
106 991-8101 90 degree union elbow 1/4 inch H31
107 991-8102 90 degree union elbow 1/8 inch H32
108 991-8103 30 degree union elbow 1/4 inch H33
109 991-8104 1/4 inch coupling H34
110 991-8105 1/8 inch coupling H35
111 991-8106 1/4 inch adapter H36
112 991-8107 1/8 inch adapter H37
113 991-8108 1/4 inch branch tee H38
114 991-8109 1/8 inch branch tee H39
115 991-8110 1/8 inch tee H40
116 991-8111 7/16 inch stainless steel hose clamp H41
117 997-2002 Hose clamp #6
118 991-8113 Strainer for 1/8 inch vee jets H43
119 991-8114 Strainer for 1/4 inch vee jets H44
120 991-8115 Strainer/check valve for 1/4 inch vee jets H45
121 991-8116 Brass strainer/check valve for tee jets H46
122 991-8117 500 PSI ball valve 1/4 inch fpt x 1/4 inch fpt H47
123 991-8118 500 PSI ball valve 3/8 inch fpt x 3/8 inch fpt H48
124 991-8119 500 PSI ball valve 1/4 inch mpt x 3/8 inch fpt H49
125 991-8120 1/4 inch brass flood jets K1 or K2 H54
126 991-8158 1/4 inch BH2-60 female coupler (mate to QD40)
127 991-8150 1/4 inch BH2-61 male nipple (mate to QD80)
128 991-8144 B2C, 1/4 inch mpt, male nipple, mate to QD50 or QD55
129 991-8152 B12, 1/4 inch mpt, female coupler, mate to QD10 or QD15
130 991-8145 B3C, 1/4 inch fpt, male nipple, mate to QD50 or QD55
131 991-8153 B13, 1/4 inch fpt, female coupler, mate to QD10 or QD15
132 991-8146 BH2C, 1/4 inch, mpt male nipple, mate to QD60 or QD65
133 991-8154 B22, 1/4 inch mpt, female coupler, mate to QD20 or QD25
134 991-8147 BH3C, 1/4 inch fpt, male nipple, mate to QD60 or QD65
135 991-8155 B23, 1/4 inch fpt, female coupler, mate to QD20 or QD25
136 991-8148 Hansen 02 male nipple, mate to QD70
137 991-8156 Quick disconnect socket female to QD30
138 991-8149 1/8 inch male quick disconnect
139 991-8157 1/8 inch female quick disconnect socket
140 991-8151 BH3-61,3/8 inch FPT, Male Nipple, mate to QD85
141 991-8159 BH3-60, 3/8 inch fpt, female coupler, mate to QD45
142 991-8123 Bottom hex nut for Kingston or P valve H57
143 991-8121 1/8 inch brass flood jets K1 or K2 H55
144 991-8124 Inline filter H58
145 991-8122 1/8 inch special brass flood jets for V1245 H56
146 991-8008 120V 50 PSI Flo Jet pump (pumps)
147 991-8009 120V 100 PSI Flo Jet pump (pumps)
148 991-8218 120V 120 PSI pump (pumps)
149 991-8220 1/8 fpt brass female connector
150 991-1835 Crevice tool

- Frequently Replaced Parts

#PartDescription ReqNotesAvailability
162-0003 6V 225Ah wet battery (SNSR) 4
162-0043 6V 224Ah AGM battery (Group GC2) (SNSR) 4
272-2358 24V onboard battery charger 1
777-9102 24V 100amp Lithium Ion battery pack kit w/ charger 1
991-9284 50amp charger plug SB50 with pins (red) 2
272-2195 Key switch assembly 1
272-7493 Chain assembly 2
172-9068 Roller chain 1
272-8757 Ground chain 1
272-5312 24V solenoid valve 1
272-6583 Vacuum hose assembly 1
272-9269 Recovery tank lid 1
272-6343 Recovery tank gasket 1
272-5577 Drain hose 1
272-7502 Vacuum motor and gasket kit 1 (standard)
272-7503 Vacuum motor gasket 1 (EMC suppression)
272-9271 Vacuum motor 1
272-8810 Carbon brush kit 1
170-1960 Carbon brush set 1 (OEM)
991-1221 Carbon brush without plastic cover (pkg of 2) 1 (NON-OEM)
272-8540 24V pump 1
172-0517 Float cage half (2 required for full float cage) 2
172-0192 Float ball 1
272-7484 Spray nozzle 1
272-7487 Spray nozzle 1
272-6344 Filter 2
272-7183 Filter 1
272-2342 Solution filter 1
272-8576 Belt 1
272-7436 Tension belt 1
272-6613 28 inch multi surface brush 1 (front)
272-7474 Brush assembly 1 (rear)

- Know Your Machine

#PartDescription ReqNotesAvailability
1 472-0250 SQUEEGEE 12.5IN 13 KIT 1
2 472-0244 12.5 inch brush (white) 1

- Simplified Solution System

#PartDescription ReqNotesAvailability
372-0001 Vacuum bag (5pack)

-Simplified Recovery System

#PartDescription ReqNotesAvailability
0 162-0011 12V 105Ah wet battery (SNSR) 2
1a 372-3350 24V vacuum motor kit 1 (see vacuum motor assembly for parts included)
1b 572-3450 VACUUM MOTOR 280W 24V PKD 1
2 372-3064 24V battery charger 1
3 991-9284 50amp charger plug SB50 with pins (red) 2
4a 372-3419 Key kit 1 (see electronic cover assembly for parts included)
4b 991-1634 Key (pkg of 2) 1
5a 572-3477 Water filter 1
5b 572-3478 NET WATER FLTR REINFORCED PKD 1
6a 372-3391 28 inch squeegee kit 1 (see squeegee assembly for parts included)
6b 372-3392 Squeegee blade kit 28 inch gum rubber 2
6c 372-3393 Squeegee blade kit 28 inch polyurethane 2
6d 372-3087 Squeegee blade kit 28 inch red gum rubber 2
7 272-5487 24V solenoid valve 1
8 372-3330 Fresh water hose with cap kit 1
9 372-3348 Drain hose 1
10 372-3349 Squeegee suction hose 1
11a 996-5046 17 inch polypropelene scrubbing brush (blue) 1
11b 181-2004 17 inch midgrit lite scrubbing brush - 180 grit (blue) 1
11c 181-2005 Brush midrit 240 1
11d 181-2006 Brush prolite 1
11e 181-2007 Brush union mix 1
12 181-2008 Pad driver 1

Chassis Assembly - 1

#PartDescription ReqNotesAvailability
2 999-0114 Washer 1/2 SAE flat 2 (included in Kit 1)
5 999-9128 Washer 3/8 SAE flat stainless steel 2 (included in Kit 1)
8 N/A Not available 1 (screw 5/16-18 x 1 socket head) (only available in Kit 4)
16 999-0423 Nut 5/16-18 nylon insert lock stainless steel 1 (included in Kit 4)
18 999-0304 Nut 1/4-20 nylon lock jam stainless steel 2 (included in Kit 4)
20 999-0296 Nut 5/16-24 nylon insert lock stainless steel 2 (included in Kit 4)
22 999-1845 Screw 3/8-16 x 5/8 hex head stainless steel 4 (included in Kit 2 and Kit 4)
24 999-1867 Nut 1-14 hex lock zinc finish 1 (included in Kit 4)
25 272-7446 Deck linkage hardware assembly 6 (cotter hair pin) (only availble in Kit 1 and Kit 4)
28 999-0504 Bolt M12-1.75 x 35mm hex hd stainless steel full thread 2 (included in Kit 1)
29 999-1170 Bolt M10-1.5 x 20mm hex head stainless steel 2 (included in Kit 4)
30 999-0775 Screw M10-1.5 x 40mm hex head stainless steel 4 (included in Kit 4)
37 N/A Not available 2 (screw 10-24 x 3/8 hex head) (only available in Kit 4)
45 N/A Not available 1 (bearing cup) (only available in Kit 2 and Kit 3)
46 N/A Not available 1 (bearing cone) (only available in Kit 2 and Kit 3)
47 N/A Not available 1 (shaft seal) (only available in Kit 2 and Kit 3)
50 172-0068 Bushing 1
54 N/A Not available 1 (bearing block) (only available in Kit 2)
57 172-2292 Grommet 2
58 172-2349 Hose 1
60 272-7450 Chassis weldment 1
61 472-7082 DECK LINKAGE WELDMENT 1
67 272-7451 Y-tube 1
68 272-6581 Hose assembly 1
69 272-7373 Hose assembly 1
70 272-7452 Lift bar 1
72 272-7453 Wire rope assembly 1
73 372-2613 Shoe linkage assembly 1
82 272-1606 Washer flat 2
83 N/A Not available 2 (bushing) (only available in Kit 1)
85 N/A Not available 1 (ball bearing) (only available in Kit 2 and Kit 3)
90 N/A Not available 1 (grommet) (only available in Kit 5)
91 N/A Not available 2 (flange bearing) (only available in Kit 1)
92 272-9976 #32 hose clamp SAE 4
95 997-2102 Cable tie 4
96 172-2679 Rod end 2
97 172-2122 P clamp 1
98a 272-8807 Drive wheel motor 1 (includes 98b-98j)
98b 272-5562 Tire with hub 1
98c 272-8808 Replacement drive motor 1
98d 272-8809 Tire 1
98e 272-8810 Carbon brush kit 1
98f 272-8811 Parking brake 1
98g 272-8604 Tire puller kit 1
98h 272-8598 Drive motor cover 1
98i 272-8813 Brake lever kit 1
98j 272-8597 Gearbox motor cover 1
99 272-8814 Spindle weldment 1
100 172-3320 Steering plate 1
101 172-3283 Wheel and bearing assembly 2
107 N/A Not available 2 (ring pin) (only available in Kit 1)
108 999-0024 Washer 5/16 flat stainless steel 1
109 172-8870 P clamp 1
110 999-0132 Bolt 5/16-18 x 3/4 hex head grade 5 zinc plated 1
111 N/A Not available 1 (gasket strip)
112 272-1612 Bolt 10mm-1.50 x 45mm hex nylon locking 4
113 272-6334 Wheel bracket 2
114 172-4211 Screw M4 x 40 cylinder head stainless steel 1
N/S 272-3726 Pump head assembly 1 (for 272-7455)
N/S 472-4392 CHECK VALVE ASSY 1 (for 272-7455)
N/S 272-7463 Quick jet body and nozzle 1
Kit 1 272-7446 Deck linkage hardware assembly 1 (includes 2, 5, 25, 28, 83, 91, 107)
Kit 2 272-7447 Bearing block assembly 1 (includes 22, 45-47, 54, 85)
Kit 3 N/A Not available 1 (includes 45-47, 85) (spindle bearing kit)
Kit 4 272-7448 Chassis hardware assembly 1 (includes 8, 16, 18, 20-22, 24-24, 29-30, 37)
Kit 5 272-7449 Deck lift hardware assembly 1 (includes 90)

Chassis Assembly - 2

#PartDescription ReqNotesAvailability
1 272-3449 Flange bearing 2
4 999-0641 Screw 5/16-18 x 3/4 socket head stainless steel 3 (included in Kit 4)
6 N/A Not available 2 (washer 3/8 flat sae) (only available in Kit 4)
7 N/A Not available 1 (screw 1/4-20 x 5/8 pan head) (only available in Kit 4)
9 999-0412 Washer #8 SAE flat 2 (included in Kit 4 and Kit 15)
10 N/A Not available 2 (cotter pin 1/8 x 1) (only available in Kit 5)
11 N/A Not available 2 (screw 3/8-16 x 1 hex head) (only available in Kit 4)
12 999-0520 Screw 10-24 x 1 pan head phillips stainless steel 2 (included in Kit 4 and Kit 15)
13 N/A Not available 1 (nut 5/16-18 hex nylock) (only available in Kit 4)
14 N/A Not available 1 (nut 1/4-20 hex nylock) (only available in Kit 4)
15 N/A Not available 2 (nut 3/8-16 hex nylock) (only available in Kit 4)
17 N/A Not available 2 (nut 10-24 hex nylock thin) (only available in Kit 4 and Kit 15)
18 N/A Not available 2 (nut 1/4-20 hex nylock thin) (only available in Kit 4)
19 999-0120 Washer 3/8 SAE flat 4 (included in Kit 5 and Kit 6)
21 999-1131 Screw 8-32 x 3/8 pan head phillips thread rolling SS 2 (included in Kit 4)
23 N/A Not available 4 (clevis pin 1/4 x 1 1/4) (only available in Kit 5 Kit 6)
26 N/A Not available 2 (retaining ring) (only available in Kit 5 and Kit 6)
27 999-1846 Screw 5/16-18 x 3 3/4 hex head stainless steel 1 (included in Kit 4)
32 N/A Not available 4 (cotter hair pin) (only available in Kit 5 and Kit 6)
33 N/A Not available 2 (clevis pin 3/8 x 1 3/4) (only available in Kit 4)
35 N/A Not available 1 (washer 9/32 x 1 1/4 flat) (only available in Kit 4)
36 N/A Not available 1 (internal washer #10) (only available in Kit 4)
37 N/A Not available 2 (screw 10-24 x 3/8 hex head) (only available in Kit 4)
39 999-0003 Nut 5/8-18 hex jam stainless steel 1 (included in Kit 4)
40 999-1019 Nut 5/16-18 hex jam stainless steel 1 (included in Kit 5)
41 N/A Not available 1 (washer 11/62 x 15/16 flat) (only available in Kit 4)
42 999-1496 Screw 1/4-20 x 1/2 button head socket stainless steel 2 (included in Kit 4)
43 172-3252 Grommet 1
48 172-8494 #6 hose clamp SAE 1
51 272-0226 Pump mount 1
52 272-0606 1/8 inch quick connect female 1
53 272-7456 P clamp 1
55 272-5312 24V solenoid valve 1
56 N/A Not available 1 (24V pump) (only available in Kit 15)
59 172-8815 Flanged bearing 2
62 272-7457 Wire rope pulley 1
63 272-7458 Actuator weldment bracket 1
64 272-7459 Actuator bracket 1
65 272-7460 Yoke weldment 1
66 372-2614 Valve assembly 1
71 272-7461 Wire rope assembly 1
74 272-7462 Misting nozzle assembly 1
75 272-7464 Connector bracket weldment 1
76 272-7465 Misting chamber adapter 1
77 272-7466 T knob assembly 1
78 272-7467 Gasket 1
79 272-7468 Pin 1
80 272-7469 24V actuator motor 1
81a 272-7470 Lift actuator assembly 1
81b 272-6571 Spring housing 1
81c 272-6570 Spring housing 1
81d 172-7998 Actuator 1
81e 172-8941 Compression spring 3
81f 172-8493 #24 hose clamp SAE 2
84 172-1336 Barbed adapter 1/4 x 1/8 brass 1
86 172-1191 Clip .75 conduit 2
87 172-2365 Pin 1
88 172-8839 Backup alarm 1
89 N/A Not available 2 (squeegee cable spacer) (only available in Kit 6)
92 272-9976 #32 hose clamp SAE 4
93 272-9373 Hose 2
94 172-1337 90 degree barb 1/4 2
95 997-2102 Cable tie 4
102 272-8757 Ground chain 1
103 170-5169 Hose clamp SAE #4 6 (included in Kit 15)
104 172-4056 90 degree barbed elbow 1 (included in Kit 15)
105 172-1793 Clip 1
106 372-2615 Squeegee pulley cable 1
N/S 272-3726 Pump head assembly 1 (for Kit 15)
N/S 472-4392 CHECK VALVE ASSY 1 (for Kit 15)
N/S 272-7463 Quick jet body and nozzle 1
Kit 4 272-7448 Chassis hardware assembly 1 (includes 4, 6-7, 9, 11-15, 17-18, 21, 27, 33-39, 41-42)
Kit 5 272-7449 Deck lift hardware assembly 1 (includes 10, 19, 23, 26, 32, 40)
Kit 6 272-7454 Shoe lift hardware assembly 1 (includes 19, 23, 26, 32)
Kit 15 272-7455 Pump assembly 1 (includes 9, 12, 17, 44, 48, 56, 103-104)

Control System Assembly

#PartDescription ReqNotesAvailability
1 172-3430 Seat kit 1
2 999-0114 Washer 1/2 SAE flat 1
3 999-0024 Washer 5/16 flat stainless steel 2
4 999-0120 Washer 3/8 SAE flat 4
5 999-0346 Screw 5/16-18 x 1/4 set cup point socket alloy plain finish 2
6 999-0123 Washer 1/4 SAE flat zinc plated 4
7 999-0522 Screw 1/4-20 x 1/2 pan head phillips stainless steel 3
8 999-0456 Screw 1/4-20 x 3/4 pan head phillips stainless steel 3
9 999-0262 Nut 1/2-13 nylon insert jam lock zinc plated 1
10 272-1538 Bolt 1/4-20 X 3/8 hex head lock 3
11 999-1373 Screw 3/8-16 x 3/8 socket set lock stainless steel 2
12 999-1133 Bolt M8-1.25 x 20mm hex head full thread plain 2
13 999-1372 Bolt M10-1.5 x 25mm hex head stainless steel 4
14 172-2573 Woodruff key 1
15 172-9387 Woodruff key 3
16 172-0294 Retaining ring 1
17 172-0392 Retaining ring 3
18 999-0471 Nut M8-1.25 nylon insert lock zinc plated 2
19 999-0829 Screw 5/16-18 x 1 1/4 hex head plain finish 3
20 999-1131 Screw 8-32 x 3/8 pan head phillips thread rolling SS 2
21 999-1129 Screw 1/4-20 x 1/2 pan head phillips thread rolling zinc 4
22 172-9057 Bushing 1
23 172-9388 Flanged bearing 2
24 172-4008 Bushing 2
25 172-3176 Knob 1 1/4 x 1/4 - 28 1
26 172-0115 Shaft collar 2
27 172-9068 Roller chain 1
28 272-9481 Flanged bearing 2
29 272-9480 Steering column ratchet 1
30 172-9074 Universal joint 1
31 172-8093 Sprocket 1
32 172-4528 Spring 1
33 272-8880 Foot pedal assembly 1
34 272-8887 Steering wheel 1
35 272-6336 Lower column weldment 1
36 272-8889 Upper column weldment 1
37 272-8890 Lower steering shaft 1
38 272-8891 Upper steering shaft 1
39 272-8881 Knob 1
40 272-3517 Steering pawl weldment 1
41 272-8892 Pull lever 1
42 272-3558 Seat panel weldment 1
43 272-8893 Lower column shroud 1
44 272-8894 Steering boot 1
45 272-9417 Seat switch 1
46 272-8774 Cap plug 1
47 272-2177 Conduit clip 1
48 272-8882 Foot pedal plate 1
49 272-6337 Flanged bushing 3

Decal Assembly

#PartDescription ReqNotesAvailability
0 272-7471 Decal assembly 1 (includes 1-8)
1 N/A Not available 1 (caution decal)
2 N/A Not available 2 (Advance decal)
3 N/A Not available 1 (decal)
4 N/A Not available 1 (wet/dry decal)
5 N/A Not available 1 (open when charging decal)
6 N/A Not available 1 (circuit breaker decal)
7 N/A Not available 1 (battery wiring decal)
8 N/A Not available 1 (prop decal)

Deck System Assembly

#PartDescription ReqNotesAvailability
2 999-0571 Screw 10-24 x 3/8 pan head phillips stainless steel 5 (included in Kit 7)
3 999-0346 Screw 5/16-18 x 1/4 set cup point socket alloy plain finish 4 (included in Kit 20)
4 999-0123 Washer 1/4 SAE flat zinc plated 6 (included in Kit 20)
5 999-1857 Screw 5/16-18 x 1 hex cap stainless steel 2 (included in Kit 20)
6 999-0294 Nut 1/4-20 hex nylon lock type NE stainless steel 1 (included in Kit 20)
7 999-1099 Bolt 1/4-20 x 3/4 hex head stainless steel 8 (included in Kit 20)
8 272-7478 Belt guard 1
9 999-0497 Nut M6-1 nylon insert lock stainless steel 1 (included in Kit 8)
10 999-0497 Nut M6-1 nylon insert lock stainless steel 3 (included in Kit 20)
11 999-1169 Bolt M6-1 x 100mm hex head full thread plain finish 1 (included in Kit 8)
12 N/A Not available 1 (screw 1/4-20 x 3/8 hex head) (only available in Kit 20)
13 999-0571 Screw 10-24 x 3/8 pan head phillips stainless steel 4 (included in Kit 9)
14 N/A Not available 2 (washer 3/8 x 37/64 bowed) (only available in Kit 20)
15 N/A Not available 4 (internal washer 5/16) (only available in Kit 20)
16 472-7085 TUBE INTAKE 1
17 999-1019 Nut 5/16-18 hex jam stainless steel 2 (included in Kit 20)
18 N/A Not available 2 (flat washer) (only available in Kit 20)
19 999-1496 Screw 1/4-20 x 1/2 button head socket stainless steel 2 (included in Kit 20)
20 272-6613 28 inch multi surface brush 1
21a 272-2148 24V brush motor 2
21b 172-8948 Brush cap assembly 1
21c 172-8951 Carbon brush and spring kit 1
21d N/A Not available 4 (brush assembly)
21e N/A Not available 4 (brush spring)
22 272-2152 Belt cover 1
23 172-3373 Idler end assembly 1 (includes 53-57)
24 272-8576 Belt 1
25 272-9344 Sheave 1
26 N/A Not available 1 (wheel) (only avaiable in Kit 8)
27 272-9336 Drive end assembly 1 (includes 58-65)
28 272-7479 Deck weldment 1
29 472-7079 BRACKET - BELT COVER 1
30 N/A Not available 1 (hopper weldment) (only available in Kit 18)
31 999-0571 Screw 10-24 x 3/8 pan head phillips stainless steel 2 (included in Kit 18)
32 172-0548 Washer 17/64 x 47/64 flat stainless steel 2 (included in Kit 18)
33 272-7376 Blade hopper 1 (included in Kit 18)
34 272-7480 Intake gasket 1
35 N/A Not available 1 (rear deflector) (only available in Kit 7)
36 472-7087 CLAMPING BAR 1
37 272-7481 Molded hose 1
38 272-7482 Brush bearing end cover assembly 1
39a 272-7483 Maintenance nozzle assembly 1
39b 272-7484 Spray nozzle 1
40 272-7485 Deck weldment bracket 1
41 272-7436 Tension belt 1
42 N/A Not available 1 (bumper) (only available in Kit 9)
43 N/A Not available 1 (bumper retainer) (only available in Kit 9)
44a 272-7486 Restoration nozzle assembly 1
44b 272-7487 Spray nozzle 1
45 N/A Not available 1 (bumper) (only available in Kit 9)
46 N/A Not available 1 (bumper retainer) (only available in Kit 9)
47 272-7488 Sheave 1
48 172-2503 Tank leveler 2
49 172-9147 Terminal insulator 4
50 N/A Not available 1 (bushing) (only available in Kit 8)
51 272-8789 T-knob assembly 1
52 170-5169 Hose clamp SAE #4 2
53 172-4656 Ball bearing 1
54 172-1837 Bearing washer 1
55 272-2170 Idler bearing plate 1
56 172-2150 Knob 1
57 172-1838 Hub 1
58 181-0003 Screw 1/4-20 x 1/2 socket set lock 2
59 172-8956 Square keyway 1
60 172-4656 Ball bearing 2
61 272-9347 Spindle 1
62 272-9346 Sheave 1
63 272-2169 Bearing plate 1
64 172-8957 Spacer 1
65 172-1837 Bearing washer 1
66 472-7804 BRUSH ASSEMBLY MULTI-SURFACE 1 (includes screw, brush drive hub, bearing ball, spindle, washer bearing, plug bearing, and multi-surface brush)
67 272-7437 Spindle assembly 1
68 272-7474 Brush assembly 1
N/S 272-7489 Screw mount magnet 1 (included in Kit 18)
N/S 999-0227 Nut 6-32 hex nylon insert lock jam zinc plated 1 (included in Kit 18)
N/S 999-1859 Screw 6-32 x 3/8 flat head phillips stainless steel 1 (included in Kit 18)
Kit 7 272-7472 Rear deflector assembly 1 (includes 2, 35, 36)
Kit 8 472-7098 BUMPER WHEEL KIT 1 (includes 9, 11, 26, 50)
Kit 9 272-7473 Bumper kit assembly 1 (includes 13, 42-43, 45-46)
Kit 14 272-7475 Bearing assembly 1
Kit 18 272-7476 Hopper assembly 1 (includes 30-33)
Kit 20 272-7477 Scrub system hardware assembly 1 (includes 1, 3-7, 10, 12, 14-15, 17-19)

Electrical System Assembly

#PartDescription ReqNotesAvailability
2 999-0522 Screw 1/4-20 x 1/2 pan head phillips stainless steel 4 (included in Kit 22)
3 999-0358 Screw 8-32 x 5/8 pan head phillips stainless steel 2 (included in Kit 22)
4 N/A Not available 3 (nut 1/4-20 hex) (only available in Kit 22)
5 N/A Not available 2 (nut 1/4-20 hex thin nylock) (only available in Kit 22)
7 999-0599 Screw 1/4-20 x 1 3/4 pan head phillips stainless steel 2 (included in Kit 22)
8 N/A Not available 1 (screw 10-24 x 3/8 hex head) (only available in Kit 22)
10 N/A Not available 2 (washer .260 x 1 x .074 flat stainless steel) (only available in Kit 22)
11 N/A Not available 3 (1/4-20 stud) (only availabale in Kit 22)
12 181-0421 Spacer 2
13 172-0343 Grommet 2
14 272-2149 Brush harness 2
15 172-1228 Grommet 1
16 172-6196 Cable tie 1
18a 372-3326 Control board kit 1
18b 272-7499 Interface panel assembly 1
18c 272-2195 Key switch assembly 1
18d 272-2196 Keys (pkg of 2) 1
19 N/A Not available 2 (capacitor assembly) (electrical system with supression)
20 172-0223 Battery cable boot 8
21 272-7500 Ferrite bead 1 (electrical system with supression)
22 172-9233 Emergency stop button 1
23 172-8828 Battery cable 3
24a 172-8836 150amp fuse 1 (OEM)
24b 991-3061 150amp fuse 1 (NON-OEM)
25a 172-2163 24V solenoid 4 post (2 large 2 small) 1 (OEM)
25b 991-1226 24V solenoid 4 post (2 large 2 small) 1 (NON-OEM)
26 272-9765 Ferrite bead 1 (electrical system with supression)
27a 172-2523 70amp circuit breaker 1 (OEM)
27b 991-1633 70amp circuit breaker 1 (NON-OEM)
28 172-0232 Clear boot cap 1
29 172-0103 Electrical mount 3
30 997-2102 Cable tie 10
31 372-2096 Cable tie 8
32 272-9374 10amp circuit breaker 1
33 272-3514 Speed control 1
34 272-6349 Panel 1
35 272-8791 Connector assembly 1
36 272-8792 Connector assembly 1
38 272-8794 24V contactor 1
39 272-3570 Panel 1
40 272-8795 Seat rod 1
41 272-8796 Gasket 1
42 272-8797 Gasket 1
44 272-8799 Emergency button guard 1
45 272-8800 Foam insert 1
46 172-2306 Cap plug 1
N/S 272-7498 Main harness 1
N/S 272-6625 Traction harness 1
N/S 272-8798 Cable assembly 1
Kit 22 672-0000 Electrical system hardware kit 1 (electrical system hardware kit) (includes 1-11)

Onboard Charger Assembly

#PartDescription ReqNotesAvailability
1 999-0019 Bolt 1/4-20 x 5/8 hex head grade 5 zinc plated 1
2 999-0018 Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated 4
3 999-0360 Screw 1/4-20 x 3/8 hex head thread rolling unslotted 1
4 172-0343 Grommet 1
5 272-8806 P clamp 1
6 272-2358 24V onboard battery charger 1
7a 272-2225 Onboard charger cord 1 (OEM)
7b 991-8566 Onboard battery charger power cord 1 (NON-OEM)
8 272-8817 Charger mounting bracket 1
9 372-2096 Cable tie 1

Recovery System Assembly

#PartDescription ReqNotesAvailability
1 999-0509 Screw 1/4-20 x 3/8 pan head phillips zinc plated 4 (included in Kit 16)
2 999-0123 Washer 1/4 SAE flat zinc plated 6 (included in Kit 16)
3 999-1503 Screw 1/4-20 x 3 hex head socket stainless steel 6 (included in Kit 16)
4 999-1861 Screw 10-24 x 7/8 pan head phillips stainless steel 2 (included in Kit 16)
5 N/A Not available 2 (washer 1/4 flat sae) (only available in Kit 16)
6 999-0332 Screw 10-24 x 5/8 pan head phillips stainless steel 6 (included in Kit 16)
7 N/A Not available 4 (screw 10-24 x 3/4 pan) (only available in Kit 16)
8 999-1862 Washer #10 flat SAE stainless steel 6 (included in Kit 16)
9 N/A Not available 5 (rivet) (only available in Kit 16)
10 N/A Not available 2 (screw 1/4-10 x 1/2 pan head plastite) (only available in Kit 16)
11 999-1864 Screw 10-16 x 3/4 pan head phillips type AB stainless steel 2 (included in Kit 16)
12 N/A Not available 2 (vacuum duct gasket) (only available in Kit 17)
13 N/A Not available 2 (vacuum motor gasket) (only available in Kit 17)
14 272-6583 Vacuum hose assembly 1
15 N/A Not available 2 (gasket) (only available in Kit 17)
16 272-3577 Foam tube assembly 1
17 172-0517 Float cage half (2 required for full float cage) 2
18 472-7084 COVER-VAC MOTOR 1
19 272-7504 Recovery tank 1
20 272-7505 Elbow weldment 1
21 272-7506 Inlet gasket 1
22 272-7507 Bracket 1
23 272-7509 Flap 1
24 272-6344 Filter 2
25 172-0192 Float ball 1
26 272-1159 Plastic clamp 2
27 272-9976 #32 hose clamp SAE 1
28 997-2102 Cable tie 1
29 272-3579 Vacuum filter gasket 2
31 272-7183 Filter 1
32 272-6341 Exhaust gasket 1
33 272-6342 Vacuum gasket 1
34 272-7242 Hinge clamp 2
35 272-6343 Recovery tank gasket 1
36a N/A Not available 2 (24V vacuum motor) (only available in Kit 17)
36b N/A Not available 2 (24V vacuum motor with supression) (only available in Kit 24)
36c 170-1960 Carbon brush set 1 (OEM)
36d 991-1221 Carbon brush without plastic cover (pkg of 2) 1 (NON-OEM)
37 572-9312 Strainer basket 1
38 272-9269 Recovery tank lid 1
39 272-3583 Drain hose hook 1
40 572-9306 Filter cover strap 2
41 272-3584 Filter box 1
42a 272-5577 Drain hose 1
42b 272-8537 Drain hose cap assembly 1
42c 272-9273 19 inch drain hose extension 1
43 272-3585 Debris cover 1
44 272-7510 Filter box cover with gasket 1
N/S 272-7508 Vacuum plate 1
Kit 16 272-7501 Recovery system hardware assembly 1 (includes 1-11)
Kit 17 272-7502 Vacuum motor and gasket kit 1 (includes 12-13, 15, 36a) (standard)
Kit 24 272-7503 Vacuum motor gasket 1 (includes 36b) (EMC suppression)

Shoe Linkage Assembly

#PartDescription ReqNotesAvailability
1 999-0114 Washer 1/2 SAE flat 2 (included in Kit 13)
2 999-1860 Washer #10 SAE zinc finish 4 (included in Kit 13)
3 999-0294 Nut 1/4-20 hex nylon lock type NE stainless steel 12 (included in Kit 12)
4 999-0211 Nut 5/16-18 hex nylon insert lock zinc plated 4 (included in Kit 13)
5 999-0523 Screw 1/4-20 x 1 1/2 pan head phillips stainless steel 2 (included in Kit 12)
6 999-0456 Screw 1/4-20 x 3/4 pan head phillips stainless steel 4 (included in Kit 12)
7 N/A Not available 2 (nut M12-1.75 hex nylock) (only available in Kit 13)
8 999-0504 Bolt M12-1.75 x 35mm hex hd stainless steel full thread 2 (included in Kit 13)
9 999-1369 Screw 10-24 x 1/2 hex head thread cutting stainless steel 2 (included in Kit 13)
10 N/A Not available 2 (flange bearing) (only available in Kit 13)
11 N/A Not available 2 (compression spring) (only available in Kit 13)
12 272-0420 Gas spring 2
13 272-9309 Flange bearing 2
14 N/A Not available 2 (pin) (only available in Kit 13)
15 272-9317 Foam shoe spacer 1 (included in Kit 12)
16 272-9318 Foam strip 2
17 N/A Not available 2 (shoe bracket weldment) (only availalble in Kit 12)
18 272-7490 Shoe support weldment 1
19 N/A Not available 4 (shoe extractor) (only available in Kit 12)
20 272-7493 Chain assembly 2
21 272-7492 Deflector 1
22 999-0625 Screw 1/4-20 x 1 1/4 pan head phillips stainless steel 6
Kit 12 272-7315 Shoe assembly 2 (includes 3, 5, 6, 17, 19, 22)
Kit 13 272-7313 Shoe linkage hardware kit 1 (includes 1, 2, 4, 7-11, 14)

Solenloid Valve Assembly

#PartDescription ReqNotesAvailability
0 372-2614 Valve assembly 1 (includes 1-14)
1 999-1131 Screw 8-32 x 3/8 pan head phillips thread rolling SS 4
2 N/A Not available 2 (nipple) (only available in Kit 19)
3 181-1108 Solution feed hose 1
4 172-1335 Hose 2
5 272-2767 Hose 1/4 x 21 inch 1
6 272-5312 24V solenoid valve 2
7 272-7495 Valve bracket 1
8 N/A Not available 1 (elbow) (only available in Kit 19)
9 272-9373 Hose 1
10 N/A Not available 1 (adapter barb) (only available in Kit 19)
11 N/A Not available 2 (barb) (only available in Kit 19)
12 272-7496 Barb hose tee 1
13 170-5169 Hose clamp SAE #4 6
14 N/A Not available 1 (tee) (only available in Kit 19)
Kit 19 272-7494 Valve fitting assembly 1 (includes 2, 8, 10, 11, and 14)

Solution System Assembly

#PartDescription ReqNotesAvailability
1 999-1862 Washer #10 flat SAE stainless steel 7 (included in Kit 21)
2 999-0333 Screw 10-24 x 1/2 pan head phillips stainless steel 5 (included in Kit 21)
3 999-0123 Washer 1/4 SAE flat zinc plated 3 (included in Kit 21)
4 999-0522 Screw 1/4-20 x 1/2 pan head phillips stainless steel 8 (included in Kit 21)
5 999-1865 Screw 6-32 x 5/16 pan head phillips thread cutting ss 2 (included in Kit 21)
6 999-1232 Screw 5/16-18 x 3/4 hex head stainless steel 4 (included in Kit 21)
7 999-0442 Nut 10-24 nylon insert lock stainless steel 2 (included in Kit 21)
8 999-0123 Washer 1/4 SAE flat zinc plated 2 (included in Kit 21)
9 999-0567 Screw 1/4-20 x 5/8 pan head phillips stainless steel 2 (included in Kit 21)
10 N/A Not available 3 (1/4 bushing) (only available in Kit 21)
11 N/A Not available 4 (washer .344 x .938 x .125) (only available in Kit 21)
12 999-1866 Screw 10-24 x 3/8 pan head phillips nylon stainless steel 6 (included in Kit 21)
13 272-9827 Chemical ratio decal 1
14 172-8494 #6 hose clamp SAE 3
15 997-2005 Hose clamp 2
16 172-0254 Nylon pipe cap 1
17 272-1410 Hose 1
18 272-1448 90 degree elbow barb 1
19 472-8346 HOSE-CHEMICAL-RESISTANT-34 IN 1
20 272-8135 Tee assembly 1
21 272-5404 Chemical resistant hose 1
22 272-2175 Chemical pump 1
23 272-2171 Hinge 1
24 272-2342 Solution filter 1
25 272-2180 Solution fill cap 1
26 272-2182 Dry break cap 1
27 272-2184 Dry break insert 1
28 272-7512 Hose 1
29 172-0197 Rubber washer 1
30 172-8218 Fastener 2
31 272-2424 Retainer 2
32 272-2426 Receptacle 2
33 272-3640 Ball valve 1
34 172-1868 PVC hose 1
35 172-1154 P clamp 3
36 172-2099 Nipple 1
37 172-9027 Adapter barb NPT 1
38 272-3641 Solution tank 1
39 272-3642 Panel 1
40 272-3643 Chemical bottle cover 1
41 272-3644 Reducer nipple 1
42 272-8863 Battery box 1
43 272-8864 Mat 1
44 272-3646 Plate 1
45 272-6376 Hose 1
46 272-8865 Charger cover weldment 1
47 272-6377 Bracket 1
48 272-3648 Pressure sensing tube with elbow 1
49 272-6378 Plate 1
50 272-9832 Chemical bottle assembly 1
51 272-8868 Gasket 1
52 272-8869 Gasket 1
53 272-3638 Hose clip 2
54 272-9352 Raw cap with tether 1
55 272-8871 Gasket 1
56 170-0264 Hose barb 1
Kit 21 272-7511 Solution system hardware assembly 1 (inlcudes 1-12)

Wiring Diagram - 1

#PartDescription ReqNotesAvailability
A1 372-3326 Control board kit 1
A2 272-3514 Speed control 1
BT1 N/A Not available 1 (battery)
CB1a 172-2523 70amp circuit breaker 1 (OEM)
CB1b 991-1633 70amp circuit breaker 1 (NON-OEM)
CB2 272-9374 10amp circuit breaker 1
F1a 172-8836 150amp fuse 1 (OEM)
F1b 991-3061 150amp fuse 1 (NON-OEM)
H1 172-8839 Backup alarm 1
K1 272-8794 24V contactor 1
K2a 172-2163 24V solenoid 4 post (2 large 2 small) 1 (OEM)
K2b 991-1226 24V solenoid 4 post (2 large 2 small) 1 (NON-OEM)
L1 272-5312 24V solenoid valve 1
L2 272-5312 24V solenoid valve 1
L3 272-5312 24V solenoid valve 1
LP1 272-7513 Beacon assembly 1 (optional)
M1 272-8807 Drive wheel motor 1
M2 272-2175 Chemical pump 1
M3 272-7469 24V actuator motor 1
M4 272-7470 Lift actuator assembly 1
M5 272-9271 Vacuum motor 1
M6 272-9271 Vacuum motor 1
M7 272-2148 24V brush motor 1
M8 272-2148 24V brush motor 1
M9 272-8540 24V pump 1
R1 N/A Not available 1 (part of foot pedal assembly)
S1 272-2195 Key switch assembly 1
S2 272-9417 Seat switch 1
S4 172-9233 Emergency stop button 1
Y1 272-8811 Parking brake 1
N/S 272-2358 24V onboard battery charger 1
