| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
189-0329
|
Hose clamp |
1 |
|
|
1b |
189-4122
|
Hose clamp |
1 |
|
|
2 |
273-5693
|
Hose clamp |
1 |
|
|
3 |
189-4123
|
Drain plug tether |
1 |
|
|
4 |
189-4190
|
Recovery tank cover |
2 |
|
|
5 |
173-2002
|
Tank lid |
1 |
|
|
6 |
189-4142
|
Shut-off float |
1 |
|
|
7 |
173-2003
|
Tank lid gasket |
1 |
|
|
8 |
189-4144
|
Recovery tank lid gasket |
2 |
|
|
9 |
173-2106
|
Drain hose 1 1/2 x 12 inch |
1 |
|
|
10a |
173-5207
|
Hose insert |
1 |
|
|
10b |
189-4130
|
1/2 inch hosebarb |
1 |
|
|
11a |
173-5208
|
Drain plug |
1 |
|
|
11b |
173-1213
|
Drain plug |
1 |
|
|
12 |
173-2454
|
Screw 10-3/4 polyfast |
6 |
|
|
13 |
173-5209
|
Recovery tank |
1 |
|
|
14a |
173-5210
|
Hose mounting bracket (OBSOLETE) |
1 |
|
|
14b |
189-4135
|
Hose mounting bracket |
1 |
|
|
15 |
173-3412
|
Cord 1/8 x 12 inch |
1 |
|
|
16 |
173-2228
|
Warning decal |
1 |
|
|
17 |
189-4189
|
Main label |
1 |
|
|
18 |
189-4145
|
Recovery tank lid assembly |
1 |
(includes 5, 7) |
|
