| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
992-0565
|
Meter case (black) |
1 |
|
|
1b |
992-0566
|
Meter case (dark gray) |
1 |
|
|
1c |
992-0567
|
Meter case (white) |
1 |
|
|
2a |
992-0568
|
Wrapper (black) |
1 |
|
|
2b |
992-0569
|
Wrapper (dark gray) |
1 |
|
|
2c |
992-0570
|
Wrapper (white) |
1 |
|
|
3 |
992-0571
|
Screw |
6 |
|
|
4 |
992-0572
|
Rear access panel |
1 |
|
|
5 |
992-0316
|
Expansion clip |
6 |
|
|
8 |
992-0339
|
Nut |
1 |
|
|
9a |
992-0573
|
Control panel (black) |
1 |
|
|
9b |
992-0574
|
Control panel (dark gray) |
1 |
|
|
9c |
992-0575
|
Control panel (white) |
1 |
|
|
10 |
992-0576
|
Operating instruction decal |
1 |
|
|
11 |
992-0309
|
Bolt |
1 |
|
|
12 |
992-0577
|
Single overlay |
1 |
|
|
13 |
992-0578
|
Overlay |
1 |
|
|
14 |
992-0540
|
Switch |
1 |
|
|
