| # | Part | Description |
Req | Notes | Availability |
|---|
0 |
775-0457
|
36V 250 mm drive wheel with encoder |
1 |
(includes 1-11) |
|
1 |
775-0534
|
Wheel / hub kit (blue) |
1 |
(includes 2-5) |
|
2 |
675-4657
|
VR, TIRE KIT, PULLER (Tennant Industrial) |
1 |
|
|
3 |
475-4116
|
VR, WHEEL, PYU [250X90 BLUE] |
1 |
|
|
4 |
375-2646
|
Hub |
1 |
|
|
5 |
775-0535
|
Hub screw kit |
1 |
|
|
6 |
775-0536
|
Cover screw kit |
1 |
|
|
7 |
375-7795
|
Traction encoder |
1 |
|
|
8 |
775-0537
|
Drive motor cover |
1 |
|
|
9 |
775-0538
|
Connector box cover |
1 |
|
|
10 |
775-0458
|
Wheel motor brush kit |
1 |
Requires Tennant True service or an authorized Tennant service provider. |
|
11 |
775-0539
|
Complete brake kit |
1 |
|
|
