| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-5535
|
Right hand bumper channel weldment (Tennant Industrial) |
1 |
|
|
2 |
275-5536
|
Left hand bumper channel weldment (Tennant Industrial) |
1 |
|
|
3 |
275-5537
|
Tank mounting bracket (Tennant Industrial) |
2 |
|
|
4 |
999-1372
|
Bolt M10-1.5 x 25mm hex head stainless steel |
10 |
|
|
5 |
275-1169
|
Washer .40 x 12mm flat |
12 |
|
|
6 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
4 |
|
|
7 |
275-7776
|
Bumper (Tennant Industrial) |
2 |
|
|
8 |
475-7423
|
SCREW, HEX, .38-16 X 0.88, SS (Tennant Industrial) |
2 |
|
|
9 |
999-0032
|
Washer 3/8 USS flat plain finish |
4 |
|
|
10 |
275-5538
|
Guard tube (Tennant Industrial) |
1 |
|
|
11 |
275-8451
|
SCREW, HEX, M10 X 1.50 X 80, 8.8 (Tennant Industrial) |
2 |
|
|
12 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
2 |
|
|
13 |
175-9789
|
PIN, HITCH, .375D X 3.12L, PL (Tennant Industrial) |
1 |
|
|
14 |
275-5539
|
12 inch cable (Tennant Industrial) |
1 |
|
|
15 |
275-0923
|
Screw M5 - 7/8 hex lock |
1 |
|
|
16 |
999-0998
|
Washer #10 flat stainless steel |
1 |
|
|
17 |
999-0740
|
Nut M5-.8 hex stainless steel |
1 |
|
|
