| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
775-0476
|
Pump bracket |
1 |
|
|
2 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
3 |
|
|
3 |
775-0477
|
36V electric solution pump |
2 |
|
|
4 |
475-7867
|
SCREW, HEX, 10-24 X 0.50, FMG, PL (Tennant Industrial) |
4 |
|
|
5 |
997-2009
|
Hose clamp |
2 |
|
|
6 |
175-9868
|
Swivel fitting 1/2 x 3/8 inch |
2 |
|
|
7 |
375-1055
|
Plastic swivel fitting (Tennant Industrial) |
2 |
|
|
8 |
175-9703
|
HOSE, AFMKT, PVC, BRD, 0.50ID, 08FT, CLR (Tennant Industria |
1 |
|
|
9 |
175-6081
|
Hose clamp |
10 |
|
|
10 |
175-5233
|
Plastic fitting |
3 |
|
|
11 |
175-3685
|
90 degree elbow fitting |
1 |
|
|
12 |
999-0784
|
Screw M8-1.25 x 16mm hex head stainless steel |
3 |
|
|
13 |
175-3594
|
Hose clamp |
5 |
|
|
14 |
775-0478
|
Bracket weldment |
1 |
|
|
15 |
575-7051
|
HOSE, AFMKT, PVC, BRD, 0.38ID, 12FT, CLR (Tennant Industrial |
1 |
|
|
16 |
375-0142
|
ec-H2O module kit |
1 |
(includes 17 & N/S) |
|
17 |
375-0144
|
Nanoclean cartridge |
1 |
|
|
N/S |
375-9401
|
Replacement controller kit |
1 |
|
|
18 |
775-0479
|
Pump mounting plate weldment |
1 |
|
|
19 |
375-0146
|
Dispenser pump assembly |
1 |
|
|
20 |
175-7795
|
Cable tie |
1 |
|
|
21 |
775-0480
|
Mounting bracket |
1 |
|
|
22 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
8 |
|
|
23 |
775-0481
|
Cover plate |
1 |
|
|
24 |
175-3344
|
Clevis pin |
2 |
|
|
25 |
175-2117
|
Cotter pin |
2 |
|
|
26 |
175-1231
|
Spring latch |
1 |
|
|
27 |
475-8860
|
RIVET, BLIND, .125D X 0.32 X .25D, ALM (Tennant Industrial) |
2 |
|
|
28 |
775-0482
|
Pump bracket weldment |
1 |
|
|
29 |
175-5234
|
Plastic fitting |
1 |
|
|
30 |
375-4258
|
Straight plastic fitting |
1 |
|
|
31 |
375-0148
|
Plastic tee fitting |
2 |
|
|
32 |
375-4254
|
Straight plastic fitting |
1 |
|
|
33 |
275-4944
|
Pressure switch |
1 |
|
|
34 |
999-1221
|
Screw M3-.5 x 25mm pan head stainless steel |
2 |
|
|
35 |
999-1161
|
Nut M3-.5 hex nylock stainless steel |
2 |
|
|
36 |
375-0150
|
6 foot hose |
1 |
|
|
37 |
375-4257
|
Plastic fitting tee |
1 |
|
|
38 |
375-1298
|
PVC hose (green) |
1 |
|
|
39 |
375-0075
|
90 degree elbow |
1 |
|
|
40 |
375-0079
|
90 degree elbow |
1 |
|
|
41 |
375-1296
|
PVC hose (green) |
1 |
|
|
42 |
375-0147
|
Straight plastic fitting |
1 |
|
|
43 |
375-3339
|
90 degree elbow |
1 |
|
|
44 |
275-8703
|
Straight plastic fitting (Tennant Industrial) |
1 |
|
|
45 |
175-7920
|
Washer M8 flat stainless steel |
3 |
|
|
46 |
575-0329
|
INDUCTOR, 12.7MMID [156 IMP AT 25MHZ] (Tennant Industrial) |
2 |
|
|
47 |
275-7845
|
8 foot clear PVC hose (Tennant Industrial) |
1 |
|
|
