| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
775-0445
|
Seat support kit mounting |
1 |
(includes 2) |
|
2 |
775-0446
|
Breaker label |
1 |
|
|
3 |
375-0751
|
Trim molding (Tennant Industrial) |
1 |
|
|
4 |
375-9733
|
Charger mounting bracket weldment |
1 |
|
|
5 |
275-9575
|
SCREW, HEX, M8 X 1.25 X 25, 9.8, SEMS (Tennant Industrial) |
2 |
|
|
6 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
2 |
|
|
7 |
175-3226
|
Insulated stand off |
6 |
|
|
8 |
999-0238
|
Washer 1/4 internal star lock zinc plated |
6 |
|
|
9 |
175-9950
|
Bolt 1/4-20 x 1/2 hex head nylon lock |
6 |
|
|
10 |
999-0016
|
Washer 1/4 flat plain finish |
6 |
|
|
11 |
175-3227
|
Threaded rod |
6 |
|
|
12 |
999-0190
|
Nut 1/4-20 hex plain finish |
6 |
|
|
13 |
775-0447
|
36V 200amp SPDT contactor |
1 |
|
|
14 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
2 |
|
|
15 |
275-9900
|
Hour meter |
1 |
|
|
16 |
275-5483
|
2.5amp circuit breaker |
5 |
|
|
17 |
275-9986
|
10amp circuit breaker (Tennant Industrial) |
3 |
|
|
18 |
275-2596
|
Circuit breaker boot (Tennant Industrial) |
8 |
|
|
19a |
775-0448
|
Machine controller |
1 |
Requires Tennant True service or an authorized Tennant service provider (Before SN 010469) |
|
19b |
775-0496
|
Machine controller |
1 |
Requires Tennant True service or an authorized Tennant service provider (After SN 010468) |
|
20 |
175-2079
|
Screw M4-.07 x 35mm pan head stainless steel |
2 |
|
|
21 |
999-0266
|
Washer #8 SAE flat stainless steel |
4 |
|
|
22 |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
2 |
|
|
23 |
999-0786
|
Screw M8-1.25 x 35mm hex head stainless steel |
3 |
|
|
