| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
572-9018
|
Screw M4 x 10 threadlock |
$5.50
|
2 |
|
usually ships 16-41 days |
2 |
572-9139
|
Cylindrical blade (red) |
$54.98
|
1 |
|
ships same day |
3a |
N/A
|
Not available |
Call for price
|
1 |
(right hand side blade cylindrical strap) |
usually ships 3-26 days |
3b |
N/A
|
Not available |
Call for price
|
1 |
(left hand side blade cylindrical strap) |
usually ships 3-26 days |
4a |
572-8149
|
Right hand skirt bracket weldment |
$344.44
|
1 |
|
usually ships 16-41 days |
4b |
572-8150
|
Left hand skirt bracket weldment |
$344.44
|
1 |
|
usually ships 16-41 days |
5 |
172-0094
|
Latch |
$44.58
|
1 |
|
ships same day |
6 |
999-0955
|
Nut M4-.7 hex nylon lock |
$1.52
|
2 |
|
ships same day |
KIT5 |
N/A
|
Not available |
Call for price
|
1 |
(includes 1-2, 3b, 4b, 5-6) (left fixed blade kit) |
usually ships 3-26 days |
KIT6 |
N/A
|
Not available |
Call for price
|
1 |
(includes 1-2, 3a, 4a, 5-6) (right fixed blade kit) |
usually ships 3-26 days |
KIT10 |
572-9141
|
Left hand cylinder strap kit |
$145.42
|
1 |
(includes 5-6) |
usually ships 16-41 days |
KIT11 |
572-9143
|
Right hand cylinder strap kit |
$145.42
|
1 |
(includes 5-6) |
usually ships 16-41 days |
