Ladder Diagram Assembly- 6
Click to enlarge
#
Part
Description
Req
Notes
Availability
A5
572-6071
Autonomous module kit
1
A9
572-6016
Breakout box assembly
1
E9
572-7050
Distance sensor kit
1
E10
572-7050
Distance sensor kit
1
E11
572-7050
Distance sensor kit
1
E12
572-7050
Distance sensor kit
1
E13a
572-7073
Safety sensor kit-left
1
E13b
572-9207
Sensor lens
1
E14a
572-7076
Safety sensor kit-right
1
E14b
572-9207
Sensor lens
1
