| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-9672
|
Gasket |
1 |
|
|
2 |
375-9673
|
Solution tank inlet filter |
1 |
|
|
4 |
375-9674
|
Pin |
2 |
|
|
6 |
375-9675
|
1/2 inch cap |
1 |
|
|
7 |
203-0971
|
Washer D6 |
1 |
|
|
8 |
375-9676
|
Screw M6 x 10 inox |
1 |
|
|
9 |
375-9677
|
Plate |
1 |
|
|
10 |
375-9678
|
M6 thread insert |
2 |
|
|
11 |
375-9679
|
Plate |
2 |
|
|
12 |
189-1391
|
Washer D6 |
2 |
|
|
13 |
203-0971
|
Washer D6 |
2 |
|
|
14 |
999-1600
|
Screw M6 x 16 pan head zinc |
2 |
|
|
15 |
375-9636
|
Clamp |
2 |
|
|
16 |
203-0235
|
Washer |
2 |
|
|
18 |
375-9680
|
Screw M4 x 10 inox |
2 |
|
|
20 |
375-9682
|
Rubber |
2 |
|
|
28 |
375-9683
|
Poster flap |
1 |
|
|
29 |
189-1357
|
Screw 6 x 12 inch |
4 |
|
|
30 |
189-0897
|
Washer D8 |
4 |
|
|
31 |
375-9685
|
Washer D. 8 |
4 |
|
|
