| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
203-4765
|
Retainer closure |
2 |
|
|
4 |
375-9595
|
O-ring |
2 |
|
|
5 |
203-0920
|
Spacer |
2 |
|
|
6 |
375-9597
|
Knob |
2 |
|
|
7 |
375-9499
|
Nut M6 inox |
2 |
|
|
11 |
375-9600
|
Gasket |
1 |
|
|
14 |
375-9601
|
Right hand blade holders |
1 |
|
|
15 |
375-9602
|
Right hand squeegee strap |
1 |
|
|
16b |
375-9468
|
Squeegee blade Front (linatex) |
1 |
|
|
16c |
375-9604
|
Front squeegee blade polyurethane |
1 |
|
|
18 |
375-9605
|
Squeegee body |
1 |
|
|
19 |
375-9606
|
Screw M6 x 65 stainless steel |
2 |
|
|
20 |
375-9607
|
Screw M6 x 55 stainless steel |
2 |
|
|
21 |
203-4780
|
Closure |
2 |
|
|
22b |
375-9469
|
Squeegee blade rear (linatex) |
1 |
|
|
25 |
375-9611
|
Plate |
1 |
|
|
26 |
375-9612
|
Insert |
2 |
|
|
27 |
999-1419
|
Nut M3-.5 hex stainless steel |
8 |
|
|
