| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-9424
|
Right hand brush motor |
1 |
(see brush motor assembly) |
|
2 |
375-9425
|
Left hand brush motor |
1 |
(see brush motor assembly) |
|
3 |
375-4109
|
Water channel fitting assembly |
1 |
(includes 4-6) |
|
4 |
N/A
|
Not available |
1 |
(water channel 6mm) (part available in kit) |
|
5 |
N/A
|
Not available |
2 |
(water channel 4mm) (part available in kit) |
|
6 |
N/A
|
Not available |
1 |
(water coupling brush motor) (part available in kit) |
|
7 |
375-9426
|
Right hand caster transport kit |
1 |
(includes 8-11) |
|
8 |
N/A
|
Not available |
1 |
(shaft transport caster) (part available in kit) |
|
9 |
N/A
|
Not available |
1 |
(transport caster) (part available in kit) |
|
10 |
N/A
|
Not available |
1 |
(right hand transport wheel pilar) (part available in kit) |
|
11 |
N/A
|
Not available |
1 |
(nut M5 nylon) (part available in kit) |
|
12 |
375-9427
|
Motor cover |
1 |
|
|
13 |
375-9428
|
Left hand cast transport kit |
1 |
(includes 14-17) |
|
14 |
N/A
|
Not available |
1 |
(shaft transport caster) (part available in kit) |
|
15 |
N/A
|
Not available |
1 |
(transport caster) (part available in kit) |
|
16 |
N/A
|
Not available |
1 |
(left hand transport wheel pilar) (part available in kit) |
|
17 |
N/A
|
Not available |
1 |
(nut M5 nylon) (part available in kit) |
|
18 |
375-4113
|
Brush hinge kit |
1 |
(includes 19-24) |
|
19 |
N/A
|
Not available |
1 |
(chassis hinge) (part available in kit) |
|
20 |
N/A
|
Not available |
1 |
(nylok screw M4 x 12 countersunk) (part available in kit) |
|
21 |
375-9026
|
Bushing |
4 |
|
|
22 |
N/A
|
Not available |
1 |
(left hand brush unit hinge support) (part available in kit) |
|
23 |
N/A
|
Not available |
1 |
(construction cover seal) (part available in kit) |
|
24 |
N/A
|
Not available |
1 |
(right hand brush unit hinge support) (part available in kit) |
|
25 |
375-9429
|
Brush bumper |
1 |
|
|
26 |
375-9430
|
Bottom brush cover |
1 |
|
|
27 |
375-9431
|
Guards splash kit |
1 |
(includes 28-30) |
|
28 |
N/A
|
Not available |
1 |
(left hand splashing guard imop) (part available in kit) |
|
29 |
N/A
|
Not available |
1 |
(right hand splashing guard imop) (part available in kit) |
|
30 |
N/A
|
Not available |
2 |
(screw M5 x 20 nylock hex head) (part available in kit) |
|
31a |
375-4117
|
Motor brush cover |
1 |
(includes 31b-41) |
|
31b |
375-9027
|
Left hand brush drive |
1 |
(includes 32-36) |
|
32 |
N/A
|
Not available |
1 |
(support disk driving wheel side hole) (part available in kit) |
|
33 |
475-1582
|
SCREW, FLT, SOC, M5 X 18.5 LH NL [ IMOP] |
1 |
|
|
34 |
N/A
|
Not available |
1 |
(cover brush motor screw blue) (part available in kit) |
|
35 |
N/A
|
Not available |
3 |
(screw 50 x 14) (part available in kit) |
|
36 |
N/A
|
Not available |
1 |
(left hand driving wheel bottom gray) (part available in kit) |
|
37a |
375-9028
|
Right hand brush drive |
1 |
(includes 37b-41) |
|
37b |
N/A
|
Not available |
1 |
(right hand driving wheel bottom gray) (part available in kit) |
|
38 |
N/A
|
Not available |
1 |
(support disk driving wheel side hole) (part available in kit) |
|
39 |
475-1581
|
SCREW, FLT, SOC, M5 X 18.5 NL [10X,IMOP] |
1 |
|
|
40 |
N/A
|
Not available |
1 |
(cover brush motor screw blue) (part available in kit) |
|
42 |
475-1520
|
SCREW, FLT, SOC, M6 X 16 NL [10X,IMOP] |
4 |
|
|
43 |
375-9432
|
Bumper |
1 |
|
|
44 |
375-9433
|
Right hand motor mount plate |
1 |
|
|
45 |
375-9434
|
Left hand motor mount plate |
1 |
|
|
