| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
175-3253
|
Bearing assembly cup/cone |
$99.33
|
2 |
|
usually ships 10-16 days |
2 |
175-6776
|
WASHER, FLAT, 1.26B 1.88D .13, STL (Tennant Industrial) |
$6.17
|
1 |
|
usually ships 1-5 days |
3 |
675-0448
|
BOLT, SHLD, 1.25D X 4.45L,1.0-20 DRILLED (Tennant Industrial |
$168.70
|
1 |
|
usually ships 10-16 days |
4 |
175-0640
|
NUT, HEX, SLTD, 1.00-20 (Tennant Industrial) |
$18.17
|
1 |
|
usually ships 1-5 days |
5 |
175-6797
|
NUT, WHEEL, .50-20 X 60 ANGLE (Tennant Industrial) |
$5.00
|
5 |
|
usually ships 10-16 days |
6 |
375-4339
|
Stainless steel flat bar (Tennant Industrial) |
$7.67
|
1 |
|
usually ships 10-16 days |
7a |
175-7214
|
Hydraulic fitting |
$13.64
|
2 |
(before SN 003000) |
usually ships 1-5 days |
7b |
575-3050
|
FITTING, HYD, E90, FM06/OM06 (Tennant Industrial) |
$31.17
|
2 |
(after SN 002999) |
usually ships 10-16 days |
8 |
175-6778
|
FITTING, GREASE, STR PM04 .63L (Tennant Industrial) |
$8.84
|
2 |
|
usually ships 10-16 days |
9 |
275-4060
|
MOTOR, HYD, GEAR, INT 18.7 BI-DIR 3000 (Tennant Industrial) |
$2,599.19
|
1 |
|
usually ships 1-5 days |
10a |
275-2948
|
FITTING, HYD, STR, JM10/OM10 (Tennant Industrial) |
$11.50
|
1 |
(before SN 003000) |
usually ships 1-5 days |
10b |
575-1735
|
FITTING, HYD, STR, FM10/OM10 (Tennant Industrial) |
$20.67
|
1 |
(after SN 002999) |
usually ships 10-16 days |
11a |
175-6919
|
Elbow fitting |
$14.30
|
1 |
(before SN 003000) |
usually ships 10-16 days |
11b |
575-3559
|
FITTING, HYD, E90, FM04/OM04 (Tennant Industrial) |
$34.51
|
1 |
(after SN 002999) |
usually ships 10-16 days |
12a |
275-3110
|
FITTING, HYD, E45, JM10/OM10 (Tennant Industrial) |
$28.51
|
1 |
(before SN 003000) |
usually ships 1-5 days |
12b |
575-6588
|
FITTING, HYD, E45, FM10/OM10 (Tennant Industrial) |
$71.35
|
1 |
(after SN 002999) |
usually ships 10-16 days |
13 |
675-2741
|
HUB ASSY, WHEEL, 5 BOLT 4.50BC 1.5 TAPER (Tennant Industrial |
$322.56
|
1 |
(includes 14) |
usually ships 10-16 days |
14 |
375-0669
|
Wheel stud (Tennant Industrial) |
$6.17
|
5 |
|
usually ships 10-16 days |
15a |
675-6935
|
TIRE ASSY, PNEU, 150/75-08 (Tennant Industrial) |
$1,246.58
|
1 |
(includes 15b-21) |
usually ships 10-16 days |
15b |
675-5519
|
RIM ASSY, 08.0 X 4.3, 4.5BC /5BOLT (Tennant Industrial) |
$686.14
|
1 |
|
usually ships 10-16 days |
16 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
$3.92
|
5 |
|
ships same day |
17 |
275-0025
|
Screw M10-1.5 x 25 hex head 8.8 |
$3.96
|
5 |
|
usually ships 10-16 days |
18a |
675-5531
|
TIRE, PNEU, 16X6.0X08 [WITH TUBE & FLAP] (Tennant Industrial |
$692.97
|
1 |
(includes 18b-20) |
usually ships 10-16 days |
18b |
675-5041
|
TIRE, PNEU, 16X6.0X08, 10PLY [1C12] (Tennant Industrial) |
$586.45
|
1 |
|
usually ships 10-16 days |
19 |
575-6743
|
INNERTUBE, 16 X 6-8 (Tennant Industrial) |
$75.18
|
1 |
|
usually ships 10-16 days |
20 |
575-3418
|
FLAP, TIRE, 8.00 [ZF500] (Tennant Industrial) |
$34.34
|
1 |
|
usually ships 10-16 days |
21 |
275-3952
|
CAP, VALVE, TIRE, TUBELESS [SCHRADER] (Tennant Industrial) |
$49.84
|
1 |
|
usually ships 1-5 days |
22 |
575-9233
|
ROD-END, 0.75-16RH FEM 0.75B (Tennant Industrial) |
$125.86
|
1 |
|
usually ships 10-16 days |
23 |
575-9134
|
ROD-END, 0.75-16RH MAL 0.75B [PTFE] (Tennant Industrial) |
$123.69
|
1 |
|
usually ships 10-16 days |
24 |
575-2087
|
SLEEVE, NYL, 1.81ID 20.0L (Tennant Industrial) |
$22.50
|
1 |
|
usually ships 10-16 days |
25 |
175-2162
|
Nylon wire tie |
$3.04
|
1 |
|
usually ships 10-16 days |
26 |
575-0706
|
SCREW, HEX, .75-10 X 5.00, G5 (Tennant Industrial) |
$14.34
|
1 |
|
usually ships 10-16 days |
27 |
575-4270
|
BRACKET, MOTOR, DRIVE (Tennant Industrial) |
$47.01
|
1 |
|
usually ships 10-16 days |
28 |
275-4108
|
CYLINDER, HYD, 2.0B 15.0L 08.00STRK 1500 (Tennant Industria |
$873.51
|
1 |
|
usually ships 1-5 days |
29 |
675-6842
|
HOUSING, SPPT, DRIVE, REAR (Tennant Industrial) |
$1,225.91
|
1 |
|
usually ships 10-16 days |
30 |
575-3166
|
SEAL, GREASE CAV (Tennant Industrial) |
$34.34
|
1 |
|
usually ships 10-16 days |
31 |
475-9172
|
WASHER, FLAT, 1.91B 3.00D .16, FELT (Tennant Industrial) |
$6.17
|
1 |
|
usually ships 10-16 days |
32 |
275-2944
|
NUT, HEX, JAM, .75-16 (Tennant Industrial) |
$5.17
|
2 |
|
usually ships 1-5 days |
33 |
275-2932
|
SCREW, HEX, .75-10 X 3.00, G5 (Tennant Industrial) |
$10.34
|
1 |
|
usually ships 1-5 days |
34 |
999-0630
|
Washer 3/4 SAE flat |
$0.99
|
8 |
|
ships same day |
35 |
275-2942
|
NUT, HEX, LOCK, .75-10, NL (Tennant Industrial) |
$6.17
|
2 |
|
usually ships 1-5 days |
36 |
175-6824
|
Screw M12-1 3/4 x 60mm hex |
$4.88
|
4 |
|
usually ships 1-5 days |
37 |
999-0519
|
Nut M12-1.75 nylon insert lock stainless steel |
$3.85
|
4 |
|
ships same day |
38 |
275-9575
|
SCREW, HEX, M8 X 1.25 X 25, 9.8, SEMS (Tennant Industrial) |
$4.60
|
2 |
|
ships same day |
39 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
$3.92
|
2 |
|
ships same day |
40 |
275-2926
|
SCREW, HEX, M10 X 1.50 X 70, 8.8 (Tennant Industrial) |
$6.17
|
2 |
|
usually ships 1-5 days |
41 |
999-0120
|
Washer 3/8 SAE flat |
$0.99
|
4 |
|
ships same day |
