| # | Part | Description |
Req | Notes | Availability |
|---|
0a |
675-8126
|
DRAIN KIT, CI [POSI CNTRL / RECVY ONLY] (Tennant Industrial) |
1 |
(standard) (includes 1-16) |
|
0b |
675-8477
|
DRAIN KIT, CI [POSI CNTRL / DUAL] (Tennant Industrial) |
1 |
(ES) (includes 1-16) |
|
1 |
275-4302
|
Dust cap |
1 |
(includes item 2) |
|
2 |
275-8694
|
Dust cap gasket |
1 |
|
|
3 |
375-6135
|
Rear bumper bracket (OBSOLETE) |
1 |
|
|
4 |
575-3722
|
BRACKET, BMPR, REAR LH (Tennant Industrial) |
1 |
|
|
5 |
175-9748
|
Hose assembly with 1 cuff |
1 |
|
|
6 |
175-9747
|
Female shank hose coupler fitting |
1 |
|
|
7 |
275-4304
|
CHAIN, SASH, 35, 07.2L 13 LINK (Tennant Industrial) |
1 |
|
|
8 |
999-0777
|
Screw M4-.7 x 10mm hex head plain finish |
1 |
|
|
9a |
675-6774
|
CAP ASSY, DRAIN, POSI CNTRL, SOLTN/RECVY (Tennant Industrial |
1 |
(includes 9b-11) |
|
9b |
175-3384
|
Tank cap |
1 |
|
|
9c |
175-9745
|
Valve handle kit |
1 |
|
|
9d |
275-4300
|
Ball and seal kit |
1 |
|
|
10 |
175-3628
|
Drain lid gasket |
1 |
|
|
11 |
175-9746
|
Washer flat 1.91b 4.38d .13 polyethylene |
1 |
|
|
12 |
675-2892
|
BUMPER, REAR, SOLTN CNTRL (Tennant Industrial) |
1 |
|
|
13 |
275-0033
|
Screw M10-1.5 x 30mm hex head 8.8 |
4 |
|
|
14 |
999-0032
|
Washer 3/8 USS flat plain finish |
4 |
|
|
15 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
4 |
|
|
16 |
999-0024
|
Washer 5/16 flat stainless steel |
4 |
|
|
