Scrub Head Assembly - FaST - Disk

#PartDescription ReqNotesAvailability
1 N/A Not available 1 (detergent) (go directly to Tennant)
2a 275-6622 Detergent holder 1 (speed scrub ride)
2b 275-8230 Detergent holder (teal) 1 (T7)
2c 275-9332 Detergent holder (gray) (OBSOLETE) 1 (T7)
3 275-8076 Rubber seal 2
4a 275-4744 Female coupling 1 (speed scrub ride)
4b 175-5311 Female fitting with valve 11 (T7)
5 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel 1
6a 175-7934 24V solution pump 1 (includes 6b)
6b 275-1536 Solution pump head 1
7 175-5241 90 degree elbow 1
8 275-8231 FITTING, BRS, E90, PF06/PM06, SPCL (Tennant Industrial) 1
9 175-6863 Straight brass fitting 1
10 275-0341 Brass tee fitting 1
11 175-7937 90 degree plastic elbow 1
12 175-7941 Air vent valve 1
13 997-2009 Hose clamp 1
14 275-8232 Pump bracket 1
15 275-4736 Screw M8-1.25 x 20mm hex washer head stainless steel SEMS 2
16 175-5304 Hose clamp 2
17a 275-5316 Check valve 1 (before SN 10558841)
17b 175-7929 Check valve 1 (after SN 10558840)
18 175-3671 Hose clamp 3 (before SN 10558841)
19a 175-7938 Spring clip (black) 1 (before SN 10337090)
19b 175-4526 Spring clip 1 (between SN 10337090 and SN 10558840)
20 999-9106 Screw M4-.7 x 16mm hex head stainless steel 2
21 275-8233 FaST injector kit 1 (before SN 10337090)
22 275-1534 3 foot PVC hose (braided) (Tennant Industrial) 1
23 175-5305 Hose 1/4 x 3 foot 1
24 275-8238 BRACKET, SPRING (Tennant Industrial) 1
25 275-8239 Extension spring 1
26 175-5421 P clamp 1
27 275-0930 Pop rivet 1
28 275-0931 Washer 1/8 flat steel plated 1
29 275-5120 FaST injector kit 1
30 175-2366 Rubber grommet 1
31 175-5312 Male coupling strainer fitting 1
32 175-5313 Plastic cap fitting 1
33 175-6081 Hose clamp 4 (before SN 10558841)
34 275-8237 HOSE, AFMKT, PVC, BRD, 0.38ID, 02FT, CLR (Tennant Industria 1
