| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-8148
|
Left hand skirt support weldment |
$115.94
|
1 |
(Left hand) |
ships same day |
1b |
275-8136
|
Right hand skirt support weldment |
$115.94
|
1 |
(Right hand) |
ships same day |
2a |
275-8149
|
Left hand skirt retainer |
$66.11
|
1 |
(Left hand) |
ships same day |
2b |
275-8137
|
Right hand skirt retainer |
$73.59
|
1 |
(Right hand) |
ships same day |
3 |
275-8138
|
Hitch pin |
$8.80
|
2 |
|
ships same day |
4 |
275-8139
|
P/M sleeve stainless steel |
$6.49
|
1 |
|
usually ships 10-16 days |
5 |
375-1695
|
Guard block (yellow) |
$11.44
|
1 |
|
ships same day |
6 |
999-0788
|
Screw M8-1.25 x 55mm hex head stainless steel |
$1.54
|
1 |
|
ships same day |
7 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.34
|
1 |
|
ships same day |
8a |
175-3343
|
Side squeegee blade linatex |
$70.40
|
1 |
|
ships same day |
8b |
275-9741
|
Side squeegee blade urethane |
$91.30
|
1 |
(optional) |
ships same day |
8c |
275-9740
|
Side squeegee blade gum rubber |
$56.10
|
1 |
(optional) |
ships same day |
9 |
275-8141
|
Left hand skirt link |
$10.01
|
1 |
|
ships same day |
10 |
275-8142
|
Right hand skirt link |
$10.01
|
1 |
|
ships same day |
11 |
275-8143
|
Left hand torsion spring |
$7.37
|
1 |
|
usually ships 10-16 days |
12 |
275-8144
|
Right hand torsion spring |
$7.37
|
1 |
|
ships same day |
13 |
275-8145
|
Spring retainer |
$26.62
|
2 |
|
ships same day |
14 |
275-8146
|
P/M sleeve stainless steel |
$5.50
|
4 |
|
ships same day |
15 |
275-8147
|
Washer 1/3 flat stainless steel |
$5.28
|
8 |
|
ships same day |
16 |
999-1297
|
Screw M8 x 50mm hex head stainless steel |
$2.86
|
2 |
|
ships same day |
17 |
175-2854
|
Screw M8-1.25 x 45mm hex head stainless steel |
$5.28
|
2 |
|
ships same day |
18 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.34
|
2 |
|
ships same day |
