| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
675-5148
|
BRUSH, SWP, 28L, WEDGE, PYP, SPL (Tennant Industrial) |
1 |
|
|
2 |
275-1971
|
Polypropylene side broom (Tennant Industrial) |
2 |
|
|
3a |
275-6002
|
16 inch super abrasive scrubbing brush |
1 |
(includes 4) |
|
3b |
996-1034
|
16 inch nylon scrubbing brush |
1 |
(includes 4) |
|
3c |
996-1037
|
16 inch polypropelene scrubbing brush |
1 |
(includes 4) |
|
3d |
275-5860
|
16 inch stiff polypropelene scrubbing brush |
1 |
(includes 4) |
|
4 |
375-1157
|
Drive hub assembly |
1 |
|
|
5 |
275-7548
|
Pad driver assembly |
1 |
(includes 6-9) |
|
6 |
475-3623
|
BRUSH KIT, HUB ASSY, DRIVE, CI [HDPE] |
1 |
|
|
7 |
275-6264
|
Pad centering device |
1 |
|
|
8 |
175-2079
|
Screw M4-.07 x 35mm pan head stainless steel |
1 |
|
|
9 |
999-0266
|
Washer #8 SAE flat stainless steel |
1 |
|
|
11 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
1 |
|
|
12 |
275-4936
|
Brush hub 3 hole |
1 |
|
|
13 |
175-2071
|
Brush retaining spring |
1 |
|
|
14 |
175-2072
|
Spring retainer bracket |
1 |
|
|
15 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
1 |
|
|
16 |
175-0505
|
Screw M6-1 x 35mm pan head stainless steel |
3 |
|
|
17 |
175-2335
|
Brush adaptor |
1 |
|
|
18 |
175-2071
|
Brush retaining spring |
1 |
|
|
19 |
175-2072
|
Spring retainer bracket |
1 |
|
|
20 |
175-0505
|
Screw M6-1 x 35mm pan head stainless steel |
3 |
|
|
N/S |
275-6002
|
16 inch super abrasive scrubbing brush |
1 |
|
|
N/S |
996-1034
|
16 inch nylon scrubbing brush |
1 |
|
|
N/S |
175-2405
|
Pad driver assembly |
1 |
(OEM) |
|
N/S |
993-2047
|
PAD DRIVER ASSY. 16 inch |
1 |
(NON-OEM) |
|
