| # | Part | Description |
Req | Notes | Availability |
|---|
1b |
275-8280
|
BRUSH, SCB, 39L, 20SR, SAB, SPL (Tennant Industrial) |
2 |
|
|
5 |
375-4291
|
Drive assembly brush hub kit |
1 |
(after SN 019999) |
|
6 |
275-6264
|
Pad centering device |
1 |
(after SN 019999) |
|
7 |
175-0514
|
DISK, DRIVER, PAD, W/ FACE, 20.0D (Tennant Industrial) |
1 |
(after SN 019999) |
|
8 |
175-2079
|
Screw M4-.07 x 35mm pan head stainless steel |
3 |
(after SN 019999) |
|
9 |
999-0266
|
Washer #8 SAE flat stainless steel |
3 |
(after SN 019999) |
|
11a |
175-0504
|
Scrub brush disk assembly 20 D Nylon (Tennant Industrial) |
2 |
(includes 12-16) (before SN 011000) |
|
11b |
996-1019
|
Polypropelene scrubbing brush ( Tennant Industrial) |
2 |
(includes 12-16) (before SN 011000) |
|
12 |
175-2335
|
Brush adaptor |
1 |
(before SN 011000) |
|
14 |
175-2072
|
Spring retainer bracket |
1 |
(before SN 011000) |
|
17 |
175-0513
|
DRIVER ASSY, PAD, 20.0D (Tennant Industrial) |
2 |
(includes 18-26) (before SN 011000) |
|
21 |
175-2072
|
Spring retainer bracket |
1 |
(before SN 011000) |
|
22 |
175-0515
|
Centering device (OBSOLETE) |
1 |
(before SN 011000) |
|
23 |
175-2079
|
Screw M4-.07 x 35mm pan head stainless steel |
3 |
(before SN 011000) |
|
