| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
375-2532
|
Propel membrane bezel kit |
$775.39
|
1 |
(includes 2a, 3-5) (actuated down pressure without telemetry) (requires Tennant True service or an authorized Tennant service provider) (propel model) |
usually ships 10-16 days |
1b |
375-0238
|
Membrane bezel kit |
$912.67
|
1 |
(includes 2b, 3-5) (replaced by 1a) (actuated down pressure) (requires Tennant True service or an authorized Tennant service provider) (propel model) |
usually ships 10-16 days |
1c |
675-9915
|
Propel bezel kit |
$720.39
|
1 |
(includes 2c, 3-5) (manual down pressure without telemetry) (requires Tennant True service or an authorized Tennant service provider) (propel model) |
usually ships 10-16 days |
1d |
375-1674
|
Control panel assembly |
$894.08
|
1 |
(includes 2d, 3-5) (replaced by 1c) (manual down pressure) (requires Tennant True service or an authorized Tennant service provider) (propel model) |
ships same day |
1e |
375-2535
|
Push membrane bezel kit |
$191.18
|
1 |
(includes 2e, 3-5) (actuated down pressure without telemtry) (requires Tennant True service or an authorized Tennant service provider) (push model) |
usually ships 10-16 days |
1f |
375-0236
|
Membrane bezel kit |
$920.48
|
1 |
(includes 2f, 3-5) (replaced by 1e) (actuated down pressure) (requires Tennant True service or an authorized Tennant service provider) (push model) |
usually ships 10-16 days |
1g |
375-2537
|
Push membrane bezel kit |
$191.18
|
1 |
(includes 2g, 3-5) (manual down pressure with telemetry) (requires Tennant True service or an authorized Tennant service provider) (push model) |
usually ships 10-16 days |
1h |
375-4653
|
Membrane bezel kit |
$1,052.48
|
1 |
(includes 2h, 3-5) (replaced by 1h) (manual down pressure) (requires Tennant True service or an authorized Tennant service provider) (push model) |
usually ships 10-16 days |
1i |
375-0241
|
LCD bezel kit |
$1,852.84
|
1 |
(includes 3-5) (LCD) (requires Tennant True service or an authorized Tennant service provider) (propel model) |
usually ships 10-16 days |
1j |
375-0240
|
LCD bezel kit |
$1,715.67
|
1 |
(includes 3-5) (LCD) (requires Tennant True service or an authorized Tennant service provider) (push model) |
usually ships 10-16 days |
2a |
375-2533
|
Propel premium screen kit |
$264.77
|
1 |
(includes 3-4) (actuated down pressure without telemetry) (propel model) |
usually ships 10-16 days |
2b |
375-0239
|
Membrane screen kit |
$253.88
|
1 |
(includes 3-4) (replaced by 1a) (actuated down pressure) (propel model) |
usually ships 10-16 days |
2c |
375-2534
|
Screen kit |
$264.77
|
1 |
(includes 3-4) (manual down pressure without telemtry) (propel model) |
usually ships 10-16 days |
2d |
375-4652
|
Membrane screen kit |
$256.96
|
1 |
(includes 3-4) (replaced by 1c) (manual down pressure) (propel model) |
ships same day |
2e |
375-2536
|
Membrane screen kit |
$264.77
|
1 |
(includes 3-4) (actuated down pressure without telemetry) (push model) |
usually ships 10-16 days |
2f |
375-0237
|
Membrane screen kit |
$264.88
|
1 |
(includes 3-4) (replaced by 1e) (actuated down pressure) (push model) |
usually ships 10-16 days |
2g |
375-2538
|
Push membrane screen kit |
$264.77
|
1 |
(includes 3-4) (manual down pressure without telemetry) (push model) |
usually ships 10-16 days |
2h |
375-4654
|
Membrane screen kit |
$284.90
|
1 |
(includes 3-4) (replaced by 1h) (manual down pressure) (push) |
usually ships 10-16 days |
3 |
375-9374
|
Console gasket |
$39.82
|
1 |
|
usually ships 10-16 days |
4 |
275-5430
|
USB cap |
$7.37
|
1 |
|
usually ships 10-16 days |
5 |
375-1351
|
USB to USB mini cable |
$16.39
|
1 |
|
usually ships 10-16 days |
6 |
275-5452
|
Potentiometer |
$87.56
|
1 |
(propel model) |
ships same day |
7 |
275-5453
|
Toggle cap |
$7.37
|
1 |
(propel model) |
ships same day |
8 |
275-5454
|
Toggle switch assembly |
$81.84
|
1 |
(propel model) |
usually ships 10-16 days |
9 |
275-5434
|
Top handle housing |
$91.30
|
1 |
|
usually ships 10-16 days |
10 |
475-2983
|
SEAL, AFMKT, RBR, CLSD, ADH, 01FT |
$3.43
|
1 |
|
usually ships 10-16 days |
11 |
275-5436
|
Handle shaft assembly |
$20.35
|
1 |
|
usually ships 10-16 days |
12 |
275-5433
|
Switch |
$10.34
|
1 |
|
usually ships 10-16 days |
13 |
275-5435
|
Spring |
$31.35
|
1 |
|
usually ships 1-5 days |
14 |
999-1403
|
Screw M8 x 16mm torx head |
$2.90
|
2 |
|
ships same day |
15 |
275-5438
|
Bail |
$49.61
|
1 |
|
usually ships 10-16 days |
16 |
275-5439
|
Handle cover |
$19.36
|
1 |
|
usually ships 10-16 days |
17 |
375-4600
|
Speed range dial |
$8.80
|
1 |
(propel model) |
ships same day |
18 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$4.49
|
2 |
(before SN 10795905) (propel model) |
usually ships 10-16 days |
19 |
275-5893
|
Seal |
$27.61
|
1 |
|
usually ships 1-5 days |
20 |
375-3186
|
Screw |
$9.79
|
2 |
(after SN 10795904) |
usually ships 10-16 days |
21 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
2 |
|
usually ships 12-18 days |
22 |
175-7660
|
Screw #10-14 x .675 shoulder self-tapping |
$3.30
|
15 |
|
ships same day |
23 |
275-5437
|
Bottom handle housing |
$91.85
|
1 |
|
usually ships 10-16 days |
N/S |
275-5427
|
Wiring harness |
$9.79
|
1 |
|
usually ships 10-16 days |
N/S |
375-5019
|
Bezel Kit |
$2,091.43
|
1 |
|
ships same day |
