| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
175-7769
|
20 inch abrasive stripping brush |
1 |
(includes 2-3) (3 lug hub) |
|
1b |
175-7770
|
20 inch nylon scrubbing brush |
1 |
(includes 2-3) (3 lug hub) |
|
1c |
175-7771
|
20 inch polypropelene scrubbing brush |
1 |
(includes 2-3) (3 lug hub) |
|
1d |
996-6129
|
20 inch nylon scrubbing brush |
1 |
(includes 12) (magnetic hub) |
|
1e |
996-6130
|
20 inch polypropylene scrubbing brush |
1 |
(includes 12) (magnetic hub) |
|
1f |
996-6131
|
20 inch abrasive scrubbing brush |
1 |
(includes 12) (magnetic hub) |
|
2 |
175-7772
|
Drive lug |
3 |
(3 lug hub) |
|
3 |
999-1265
|
Screw M6-1 x 35mm flat head phillips stainless steel |
3 |
(3 lug hub) |
|
4a |
175-7774
|
20 inch pad driver assembly |
1 |
(includes 5-9) (3 lug hub) |
|
4b |
996-6132
|
20 inch pad driver |
3 |
(includes 7-8, 13) (magnetic hub) |
|
5 |
175-7772
|
Drive lug |
3 |
(3 lug hub) |
|
6 |
999-1265
|
Screw M6-1 x 35mm flat head phillips stainless steel |
3 |
(3 lug hub) |
|
7 |
999-0266
|
Washer #8 SAE flat stainless steel |
3 |
|
|
8a |
275-4705
|
Screw M4-.7 x25mm pan head phillips |
3 |
(3 lug hub) |
|
8b |
999-1898
|
Screw M4-.7 x 12mm pan head phillips stainless steel |
3 |
(magnetic hub) |
|
9 |
175-0182
|
Universal center lock |
1 |
|
|
10 |
175-5850
|
Pad driver retainer |
1 |
|
|
11a |
255-2020
|
20 inch premium white polishing pad (pkg of 5) |
1 |
|
|
11d |
255-2092
|
20 inch premium brown stripping pad (pkg of 5) |
1 |
|
|
11e |
255-2090
|
20 inch premium black stripping pad (pkg of 5) |
1 |
|
|
11f |
255-2047
|
20 inch Redwood maroon floor prep pad (pkg of 10) |
1 |
|
|
11g |
375-7835
|
20 inch polishing pad (yellow) |
1 |
|
|
12 |
375-0202
|
Safety decal |
1 |
(magnetic hub) |
|
