S16 Headlight and Tail Light Assembly-Optional

#PartDescriptionPriceReqNotesAvailability
1 375-8439 Light bracket weldment $219.34 1 usually ships 10-16 days
2 275-4736 Screw M8-1.25 x 20mm hex washer head stainless steel SEMS $4.49 4 usually ships 10-16 days
3 375-4398 LED strobe light (Tennant Industrial) $318.23 1 usually ships 10-16 days
4 999-1403 Screw M8 x 16mm torx head $2.90 4 ships same day
5 275-7768 Backup alarm (Tennant Industrial) $178.04 1 usually ships 1-5 days
6 175-5310 Screw 4 x 45/64 x 16 pan head $4.36 2 usually ships 1-5 days
7 999-1383 Screw M6-1 x 16mm hex head stainless steel $3.96 1 ships same day
8 275-8550 SWITCH, ROCKER, PRGRSV (Tennant Industrial) $44.34 1 usually ships 1-5 days
9 275-5483 2.5amp circuit breaker $14.08 2 usually ships 10-16 days
10 375-8441 Harness $76.01 1 usually ships 10-16 days
11 275-5197 Fir tree clip $2.38 1 usually ships 10-16 days
12 275-7763 Pre-sweep light assembly (Tennant Industrial) $337.57 2 usually ships 1-5 days
13 275-7761 Left hand headlight bezel $9.13 1 usually ships 1-5 days
14 275-7762 Right hand headlight bezel $14.85 1 usually ships 10-16 days
15 999-1222 Screw M3-.5 x 10mm pan head stainless steel $0.99 6 ships same day
16 175-2146 Screw 6-20 x 1/2 pan head $3.30 6 usually ships 10-16 days
17 375-8442 Taillight $260.04 1 usually ships 10-16 days
