| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-8105
|
Dust hub cap |
2 |
|
|
2 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
2 |
|
|
3 |
203-6210
|
Washer M8 split |
2 |
|
|
4 |
999-0785
|
Screw M8-1.25 x 30mm hex head stainless steel |
2 |
|
|
5 |
203-6236
|
Die-cast aluminum alloy rear wheel |
2 |
|
|
6 |
375-8106
|
Ball bearing |
4 |
|
|
7 |
203-6238
|
Snap ring |
2 |
|
|
8 |
375-8107
|
Washer seal |
2 |
|
|
9 |
375-8080
|
Axle shaft weldment |
1 |
|
|
