| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-7897
|
Antenna |
$61.93
|
1 |
(replaced by 1b) (before SN 11016001) |
usually ships 1-5 days |
1b |
375-9391
|
Telem antenna |
$60.28
|
2 |
(after SN 11016000) |
usually ships 5-16 days |
2 |
999-0740
|
Nut M5-.8 hex stainless steel |
$0.99
|
4 |
|
ships same day |
3 |
375-3988
|
Mount plate |
$55.55
|
1 |
|
usually ships 5-16 days |
4 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
1 |
|
ships same day |
5 |
999-0030
|
Bolt 5/16-18 x 5/8 hex head grade 5 zinc plated |
$1.14
|
1 |
|
ships same day |
6a |
275-2615
|
Telemetry control box assembly kit |
$2,207.40
|
1 |
(replaced by 6b and 1b) (before SN 11016001) |
usually ships 1-5 days |
6b |
375-7809
|
Telem control box assembly (Tennant Industrial) |
$1,526.14
|
1 |
(after SN 11016000) |
usually ships 5-16 days |
7 |
999-0393
|
Washer 3/16 flat aluminum |
$0.99
|
8 |
|
ships same day |
8 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
$0.99
|
4 |
|
ships same day |
9a |
475-2252
|
HARNESS, ELE [TELEM, T1B] |
$247.72
|
1 |
(includes 9b) |
usually ships 5-16 days |
9b |
275-7904
|
Fuse (Tennant Industrial) |
$2.40
|
1 |
|
usually ships 1-5 days |
10 |
175-7795
|
Cable tie |
$4.75
|
6 |
|
ships same day |
11 |
275-2364
|
Rubber grommet (Tennant Industrial) |
$4.40
|
1 |
|
usually ships 5-16 days |
12 |
275-7899
|
Telemetry decal |
$69.19
|
1 |
|
usually ships 1-5 days |
