| # | Part | Description |
Req | Notes | Availability |
|---|
1b |
675-9595
|
TUBE WLDT, OHG, RH (Tennant Industrial) |
1 |
(after SN 012999) |
|
2a |
675-6966
|
TUBE WLDT, OHG, LH (Tennant Industrial) |
1 |
(before SN 013000) |
|
4 |
175-7920
|
Washer M8 flat stainless steel |
8 |
|
|
10 |
275-0033
|
Screw M10-1.5 x 30mm hex head 8.8 |
4 |
|
|
12 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
10 |
|
|
13 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
4 |
|
|
17 |
575-2576
|
BRACKET WLDT, MTG, OHG (Tennant Industrial) |
1 |
|
|
18 |
575-4321
|
COVER, OHG, TRIM, RH (Tennant Industrial) |
1 |
|
|
19 |
575-4322
|
COVER, OHG, TRIM, LH (Tennant Industrial) |
1 |
|
|
20a |
675-6891
|
KIT, REPLMT, COVER, BATTERY, OHG [T17] (Tennant Industrial) |
1 |
(before SN 010300) |
|
20b |
675-9597
|
COVER, BATTERY, OHG [T/M17] (Tennant Industrial) |
1 |
(after SN 012999) |
|
