| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
575-8540
|
BRACKET WLDT, SPPT, TANK (Tennant Industrial) |
1 |
|
|
2 |
175-9975
|
Screw M8-1.25 x 30mm hex head nylon lock |
2 |
|
|
3 |
175-7920
|
Washer M8 flat stainless steel |
2 |
|
|
4 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
11 |
|
|
6 |
575-3113
|
PLATE WLDT, MTG, PLATFORM (Tennant Industrial) |
1 |
|
|
7 |
675-6893
|
PLATFORM SET, OPRTR [T17] (Tennant Industrial) |
1 |
|
|
8 |
575-2944
|
PLATE, MTG (Tennant Industrial) |
1 |
|
|
9 |
999-0786
|
Screw M8-1.25 x 35mm hex head stainless steel |
2 |
|
|
10 |
275-6563
|
Seat kit |
1 |
|
|
11 |
275-2671
|
11 1/2 inch seat adjuster rail (Tennant Industrial) |
1 |
|
|
12 |
675-9511
|
Seat track no stud |
1 |
|
|
13 |
275-9333
|
Spacer |
4 |
|
|
14 |
275-9278
|
SCREW, PAN, PHL, .31-18 X 1.00, G2 (Tennant Industrial) |
4 |
|
|
15 |
275-9280
|
Seat switch |
1 |
|
|
16 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
4 |
|
|
17 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
4 |
|
|
18 |
575-0063
|
ANGLE, LATCH (Tennant Industrial) |
1 |
|
|
19 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
1 |
|
|
20 |
999-0016
|
Washer 1/4 flat plain finish |
1 |
|
|
21 |
675-9512
|
Bolt retention push nut |
4 |
|
|
22 |
275-3879
|
SCREW, HEX, .31-18 X 1.00, G5 (Tennant Industrial) |
4 |
|
|
