| # | Part | Description |
Req | Notes | Availability |
|---|
10 |
N/A
|
Not available |
1 |
(Squeegee Holder) |
|
13 |
272-1999
|
Squeegee support hardware kit |
1 |
|
|
14 |
272-2008
|
Adjustment screw kit |
1 |
|
|
15 |
272-5530
|
Squeegee holder kit |
1 |
|
|
16 |
272-2020
|
Squeegee assembly |
1 |
|
|
17 |
272-5531
|
Squeegee assembly |
1 |
(includes 10, 13-16, and 18-19) |
|
18 |
272-5532
|
Spacer |
1 |
|
|
19 |
N/A
|
Not available |
1 |
(Squeegee Support Kit (includes 10, 13-15, and 18) |
|
N/S |
272-6569
|
Squeegee blade front neoprene |
1 |
|
|
N/S |
272-2026
|
Squeegee blade kit gum rubber |
1 |
|
|
