| # | Part | Description | Price | Req | Notes | Availability |
|---|
0a |
372-2308
|
Diesel gauge panel assembly (OBSOLETE) |
$1,033.67
|
1 |
(includes 1-2, 4-15) |
usually ships 17-28 days |
0b |
372-2062
|
LPG gauge panel assembly |
$1,164.11
|
1 |
(includes 1-8, 10-15) |
usually ships 17-28 days |
0c |
372-2063
|
Petrol gauge panel assembly (OBSOLETE) |
$1,416.53
|
1 |
(includes 1-15) |
usually ships 17-28 days |
0d |
372-2065
|
Gauge panel assembly (OBSOLETE) |
Call for price
|
1 |
(includes 1-16) (advance models) |
usually ships 17-28 days |
1 |
272-1449
|
Gasket |
$12.31
|
1 |
|
usually ships 1-5 days |
2 |
172-2162
|
Hour meter |
$215.00
|
1 |
|
usually ships 17-28 days |
3a |
472-9064
|
SWITCH STARTER |
$206.91
|
1 |
(LPG and petrol models) |
usually ships 17-28 days |
3b |
472-9190
|
KEY IGNITION - REPLACEMENT |
$26.04
|
1 |
(for 3a) |
usually ships 17-28 days |
3c |
572-0368
|
KEY SWITCH |
$152.05
|
1 |
(diesel models) |
usually ships 17-28 days |
3d |
372-2310
|
Key |
$31.10
|
1 |
(for 3c) |
usually ships 17-28 days |
3e |
472-6912
|
KEY SWITCH ASSY 3 POS |
$75.02
|
1 |
(model 56307252) |
usually ships 17-28 days |
3f |
372-2311
|
Replacement key |
$12.31
|
1 |
(for 3e) |
usually ships 17-28 days |
4 |
999-1862
|
Washer #10 flat SAE stainless steel |
$0.99
|
2 |
|
ships same day |
5 |
999-1036
|
Nut 8-32 hex NTM nylon insert jam lock stainless steel |
$0.99
|
2 |
|
ships same day |
6 |
999-0442
|
Nut 10-24 nylon insert lock stainless steel |
$1.76
|
2 |
|
ships same day |
7 |
172-4950
|
Screw 6-32 pan head phillips thread form black |
$12.31
|
2 |
|
usually ships 1-5 days |
8 |
999-0454
|
Screw 10-24 x 1/2 truss head phillips zinc plated |
$0.99
|
5 |
|
ships same day |
9 |
270-0644
|
Fuel gauge |
$176.52
|
1 |
(not used on LPG models) |
usually ships 1-5 days |
10a |
472-4080
|
PANEL LPG ASSY |
$314.39
|
1 |
(LPG nad petrol models) |
usually ships 17-28 days |
10b |
472-4081
|
PANEL DIESEL ASSY |
$298.77
|
1 |
(diesel and 56307252 models) |
usually ships 17-28 days |
11 |
472-4099
|
KIT-CONTROL BOX |
$444.17
|
1 |
|
usually ships 17-28 days |
12a |
372-2312
|
Petrol gauge cover plate |
$19.98
|
1 |
(petrol and diesel models) |
usually ships 17-28 days |
12b |
372-2313
|
LPG gauge cover plate |
$19.98
|
1 |
|
usually ships 17-28 days |
13 |
372-2314
|
Cover plate gasket |
$12.31
|
1 |
|
usually ships 17-28 days |
14 |
999-0452
|
Screw 8-32 x 3/8 pan head phillips zinc plated |
$0.99
|
1 |
|
ships same day |
15 |
372-1303
|
Quick connect |
$12.31
|
1 |
|
usually ships 17-28 days |
16 |
372-2315
|
Shaker washer (OBSOLETE) |
Call for price
|
1 |
(model 56307252) |
usually ships 17-28 days |
