| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
170-0290
|
Strainer (OBSOLETE) |
1 |
|
|
2 |
170-4695
|
Vacuum gasket (OBSOLETE) |
1 |
|
|
3 |
999-0343
|
Screw 1/4-20 x 1/4 pan head phillips stainless steel |
2 |
|
|
4 |
N/A
|
Not available |
1 |
(Solution tank) |
|
5 |
170-6085
|
Bushing (OBSOLETE) |
3 |
|
|
6 |
170-4697
|
Connector 3/8 x 1/4 (OBSOLETE) |
1 |
|
|
7 |
170-6086
|
Hose barb connector |
2 |
|
|
8 |
170-4698
|
Recovery tool (OBSOLETE) |
1 |
|
|
9 |
170-4699
|
Recovery shoe (OBSOLETE) |
2 |
|
|
10 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
2 |
|
|
11 |
170-4700
|
Shoulder bolt |
2 |
|
|
12 |
170-4701
|
Recovery hose (OBSOLETE) |
1 |
|
|
13 |
997-2007
|
Hose clamp |
3 |
|
|
14 |
170-4702
|
Solution drain hose (OBSOLETE) |
1 |
|
|
15 |
170-4672
|
Squeegee vacuum hose (OBSOLETE) |
1 |
|
|
16 |
170-4703
|
Weldment adaptor (OBSOLETE) |
1 |
|
|
17 |
170-4704
|
Solution screen (OBSOLETE) |
1 |
|
|
18 |
999-0068
|
Screw 10-32 x 1/4 round head slotted zinc plated |
2 |
|
|
19 |
999-0311
|
Washer #10 external star lock zinc plated |
1 |
|
|
20 |
170-4705
|
Lift here label (OBSOLETE) |
1 |
|
|
21 |
997-2001
|
Hose clamp |
3 |
|
|
22 |
170-4706
|
Ground wire (OBSOLETE) |
1 |
|
|
23 |
170-1791
|
Hose (OBSOLETE) |
1 |
|
|
