| # | Part | Description |
Req | Notes | Availability |
|---|
A5 |
372-1439
|
Steering controller |
1 |
|
|
CB10 |
272-6708
|
25amp circuit breaker |
1 |
|
|
E4 |
372-1443
|
Torque feedback device (OBSOLETE) |
1 |
|
|
K10 |
172-2805
|
36V contactor |
1 |
|
|
K14 |
172-1779
|
36V relay SPST |
1 |
|
|
M16 |
472-7286
|
MOTOR STEERING 36V |
1 |
|
|
R3 |
N/A
|
Not available |
1 |
(resistor) |
|
S16 |
272-8850
|
Proximity sensor |
1 |
|
|
S17 |
272-8850
|
Proximity sensor |
1 |
|
|
