| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
272-3209
|
Left hinge pin weldment |
1 |
|
|
2 |
272-9727
|
Screw 1/4-20 x 1/2 hex head lock |
1 |
|
|
3 |
272-1652
|
Bolt 3/8-16 x 5/6 lock |
2 |
|
|
4 |
999-0793
|
Screw 10-24 x 3/8 hex washer slot thread cutting zinc |
1 |
|
|
5 |
272-8806
|
P clamp |
1 |
|
|
6a |
372-2832
|
Hydraulic power pack assembly |
1 |
(includes 6b-6e) |
|
6b |
372-2833
|
36V motor |
1 |
|
|
6c |
372-2834
|
Hydraulic pump/reservoir assembly |
1 |
|
|
6d |
372-2835
|
Orifice fitting |
1 |
|
|
6e |
272-2983
|
90 degree elbow |
2 |
|
|
6f |
372-2836
|
Hydraulic reservoir kit |
1 |
(for 6c) |
|
6g |
372-2837
|
Hydraulic reservoir cap |
1 |
(for 6c) |
|
6h |
472-7032
|
O-RING -132 NBR 70 HC350B |
1 |
(for 6c) |
|
7a |
N/A
|
Not available |
1 |
(hopper lift cylinder assembly) (includes 7b-7e) |
|
7b |
372-2818
|
Flange bearing |
2 |
|
|
7c |
372-2838
|
Hydraulic cylinder |
1 |
|
|
7d |
272-2983
|
90 degree elbow |
1 |
|
|
7e |
272-3151
|
90 degree elbow |
1 |
|
|
7f |
372-2839
|
Seal kit |
1 |
(for 7c) |
|
8 |
372-2840
|
Hose assembly |
2 |
|
|
