Engine System Assembly

#PartDescription ReqNotesAvailability
1 999-0829 Screw 5/16-18 x 1 1/4 hex head plain finish 2 (included in KIT1 and KIT2)
2 999-1032 Screw 1/4-20 x 5/8 hex head stainless steel 2 (included in KIT1 and KIT2)
3 999-1532 Screw 1/4-20 x 1/2 hex head stainless steel 3 (LPG model) (included in KIT2)
4 N/A Not available 1 (screw) (LPG model) (only available in KIT2)
5 999-9004 Washer 5/16 SAE flat stainless steel 8 (qty 9 for diesel) (included in KIT1 and KIT2)
6 999-1862 Washer #10 flat SAE stainless steel 1 (LPG model) (included in KIT2)
7 N/A Not available 2 (screw) (qty 4 for diesel) (only available in KIT1 and KIT2)
8 999-0120 Washer 3/8 SAE flat 26 (included in KIT1 and KIT2)
9 999-0567 Screw 1/4-20 x 5/8 pan head phillips stainless steel 6 (included in KIT1 and KIT2)
10 N/A Not available 3 (screw) (included in KIT1 and KIT2)
11 999-0123 Washer 1/4 SAE flat zinc plated 11 (qty 13 for diesel) (included in KIT1 and KIT2)
12 N/A Not available 17 (screw) (qty 15 for diesel) (included in KIT1 and KIT2)
13 999-1857 Screw 5/16-18 x 1 hex cap stainless steel 10 (included in KIT1 and KIT2)
14 999-1531 Screw 3/8-16 x 1 hex washer head zinc plated 8 (qty 12 for diesel) (included in KIT1 and KIT2)
15 999-0211 Nut 5/16-18 hex nylon insert lock zinc plated 8 (included in KIT1 and KIT2)
16 999-1895 Screw 1/4-20 x 7/8 flat head phillips stainless steel 2 (LPG model) (included in KIT2)
17 999-1482 Nut 3/8-16 nylon lock stainless steel 1 (included in KIT1 and KIT2)
18 N/A Not available 4 (nut) (qty 7 for diesel) (only available in KIT1 and KIT2)
19 N/A Not available 5 (nut) (only available in KIT1 and KIT2)
20 N/A Not available 2 (screw) (only available in KIT1 and KIT2)
21 N/A Not available 1 (screw) (only available in KIT1 and KIT2)
22 N/A Not available 4 (washer) (only available in KIT1 and KIT2)
23 999-0894 Screw 3/8-16 x 2 1/2 carriage head stainless steel 1 (included in KIT1 and KIT2)
24 N/A Not available 1 (screw) (only available in KIT1 and KIT2)
25 999-1532 Screw 1/4-20 x 1/2 hex head stainless steel 3 (qty 4 for diesel) (included in KIT1 and KIT2)
26 999-0628 Nut 3/8-16 hex jam stainless steel 1 (LPG model) (included in KIT1 and KIT2)
27 N/A Not available 2 (washer) (only available in KIT1 and KIT2)
28 272-3872 Skid 1
29 272-7994 20 inch hose 1 (qty 2 for diesel)
30 172-9530 Cable clamp 1 (LPG model)
31 172-8493 #24 hose clamp SAE 1 (LPG model)
32 272-3274 Muffler clamp 1
33 272-1317 Plastic clamp 1
34 172-1139 Bushing 6
35 172-1014 P clamp 1
36 472-9240 MOUNT ISOLATOR 4
37 272-9976 #32 hose clamp SAE 2 (qty 3 for diesel)
38 N/A Not available 2 (muffler) (LPG model) (only available in KIT3)
39 272-3288 Service indicator 1
40 272-3270 Air cleaner 1
41 272-3273 Band assembly 1
44 372-2140 Regulator to engine hose 1 (LPG model)
45 372-1534 Tank guard plate 1
46 N/A Not available 1 (engine assembly) (LPG model)
47 372-1600 Tank support weldment 1 (LPG model)
48 N/A Not available 1 (fuel tank assembly) (LPG model)
49 372-2737 Tank support bracket (OBSOLETE) 1 (LPG model)
50 372-2730 Cable guard weldment (OBSOLETE) 1 (LPG model)
51 372-2731 Guard mount weldment (OBSOLETE) 1
52 372-2732 Tailpipe blanket (OBSOLETE) 1 (LPG model)
53 372-1601 Tank mount weldment 1 (LPG model)
54 372-2733 Muffler bracket (OBSOLETE) 1 (LPG model)
55 372-1521 Air cleaner mount weldment 1
56 N/A Not available 1 (tailpipe) (LPG model) (only available in KIT3)
57 372-2734 Muffler blanket (OBSOLETE) 1 (LPG model)
58 372-1537 Belt removal tool 1
59 372-1528 Plate guard 1
60 372-2742 Battery hold down (OBSOLETE) 1 (LPG model)
61 372-1146 Exhaust silencer 1 (LPG model)
62 372-1547 Carbureted exhaust system kit 1 (LPG model)
63 372-1603 Heat shield 1 (LPG model)
64 372-1523 Heat shield muffler 1 (LPG model)
65 372-1524 Foam insulation 1 (LPG model)
66 372-2736 Radiator seal mount 1
67 372-1525 Trim seal 1
68 N/A Not available 1 (tailpipe blanket) (LPG model) (only available in KIT1)
69 170-5169 Hose clamp SAE #4 2 (qty 9 for diesel)
70 272-7769 3/4 inch double wire clamp 4 (qty 5 for diesel)
71 272-7997 Overflow bottle assembly 1
72 999-0830 Screw 1/4-20 x 1 hex head plain finish 4 (diesel model) (included in KIT1)
73 999-0294 Nut 1/4-20 hex nylon lock type NE stainless steel 4 (diesel model) (included in KIT1)
74 999-0990 Screw 1/4-20 x 5/8 flat head phillips stainless steel 2 (diesel model) (included in KIT1)
75 999-0696 Screw 5/16-18 x 1 pan head phillips zinc plated 1 (diesel model) (included in KIT1)
76 172-7339 Pin 1 (diesel model)
77 172-3357 9 inch wire rope 1 (diesel model)
78 172-4008 Bushing 1 (diesel model)
79 272-3286 Hose 1 (diesel model)
80 172-2122 P clamp 1 (diesel model)
81 372-2178 Muffler clamp 1 (diesel model)
82 372-1532 Tank pivot weldment 1 (diesel model)
83 372-1529 Fuel tank support 1 (diesel model)
84 372-1536 Tank pivot bracket 1 (diesel model)
85 372-2737 Tank support bracket (OBSOLETE) 1 (diesel model)
86 372-2738 Tailpipe 1 (diesel model)
87 372-2739 Tailpipe bracket 1 (diesel model)
88 372-2740 Tailpipe blanket (OBSOLETE) 1 (diesel model)
89 372-2741 Muffler blanket (OBSOLETE) 1 (diesel model)
90 372-1522 Mount weldment 1 (diesel model)
91 372-2742 Battery hold down (OBSOLETE) 1 (diesel model)
92 372-2743 Diesel tank assembly 1 (diesel model)
93 372-2744 Fuel hose 1 (diesel model)
N/S N/A Not available 1 (nut) (diesel model) (only available in KIT1)
N/S 272-3351 P clamp 1 (diesel model)
N/S 572-0322 TUBE RUBBER.312X60 E00556 1 (diesel model)
N/S N/A Not available 1 (engine assembly)
N/S 372-2746 Cable bracket weldment 1 (diesel model)
N/S 372-2747 Fuel hose 1 (diesel model)
N/S 272-3775 Double clamp 1 (diesel model)
KIT1 372-2748 Diesel engine hardware kit 1 (includes 1-2, 5, 7, 8-15, 17-25, 27)
KIT2 372-1546 LPG engine system hardware kit 1 (includes 1-27)
KIT3 372-2749 Exhaust system kit 1 (includes 38, 56, 68)
