| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
350-0568
|
5/16-18 x 5/8 Hexhead Bolt |
3 |
|
|
2 |
350-0590
|
5/16 SS Washer |
3 |
|
|
7 |
350-1163
|
Volute O-Ring For SS Pump |
1 |
|
|
8 |
350-0095
|
Pump Seal Kit for SS Pump |
1 |
|
|
9 |
350-1155
|
Pump Impeller SS Threaded (OBSOLETE) |
1 |
|
|
10 |
350-2113
|
1 inch MPT x 1 inch Barb Brass (180T units) |
1 |
|
|
11 |
350-1246
|
SS Pump Cover |
1 |
|
|
14 |
350-0096
|
Slip Joint Nut 1 1/2 x 1 1/4 |
1 |
|
|
15 |
350-0108
|
3/8 Male Plug - Sq Head |
1 |
|
|
20 |
350-0577
|
10 mm Socket Head Screw |
6 |
|
|
