| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
350-1818
|
Power Block |
1 |
|
|
2 |
350-0444
|
120V ice cube relay |
3 |
|
|
3 |
350-1149
|
Dual Temp Display Kit (CMA-180UC) KDW |
1 |
|
|
4 |
350-1146
|
Thermometer Transformer |
1 |
|
|
6 |
350-1820
|
Start Switch-Amber 115V |
1 |
|
|
7 |
350-0258
|
Rocker Switch Auto Fill |
1 |
|
|
8 |
350-1822
|
Power Rocker Switch Red 115V |
1 |
|
|
9 |
350-1496
|
Ground Block |
1 |
|
|
10 |
350-0297
|
Snap Bushing Universal 875-11 |
1 |
|
|
11 |
350-0618
|
6-32 x 1 Phillips Panhead Screw |
2 |
|
|
12 |
350-0610
|
6-32 Nylon Insert Lock Nut |
2 |
|
|
13 |
350-0591
|
8-32 Nylon Lock Nut |
5 |
|
|
14 |
350-0570
|
8-32 x 1/2 Panhead Screw |
6 |
|
|
15 |
350-0361
|
Reed Switch - ISI |
1 |
|
|
16 |
350-0580
|
8-32 PM Nut |
4 |
|
|
17 |
350-1206
|
Sponge Strips -Neoprene |
2 |
|
|
18 |
350-1148
|
Thermocouple |
2 |
|
|
19 |
350-0615
|
4-40 Nylon Lock Nut |
2 |
|
|
20 |
350-1189
|
Switch Guard (Undercounter Units) |
1 |
|
|
22 |
350-0443
|
Timer Relay 120V |
1 |
|
|
