| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
350-1827
|
SS Braided Hose 20 inch 1/4 Comp x 1/2MIP |
1 |
|
|
2 |
350-1200
|
Nipple Brass 1/2 x Close |
1 |
|
|
3 |
350-1198
|
Fitting with Flow Disk |
1 |
|
|
4 |
350-1773
|
Plumbing Bracket |
1 |
|
|
5 |
350-1208
|
10-32 Lock Nut |
1 |
|
|
6 |
350-0589
|
1/4 SS Washer |
2 |
|
|
7 |
350-1191
|
1/2 Water Sol Valve JE120/60 |
1 |
|
|
8 |
350-0492
|
Nipple Brass 1/2 x 4 |
1 |
|
|
10 |
350-1193
|
1/2 Water Solenoid Bonnet |
1 |
|
|
11 |
350-0504
|
5/8 Compression Fitting Nut |
4 |
|
|
12 |
350-2062
|
1/2 Strainer Ball Valve NPT |
1 |
|
|
13 |
350-1153
|
Thermowell Tee |
1 |
|
|
14 |
350-0489
|
1/2 Tee F x F x F SS |
1 |
|
|
15 |
350-1309
|
Vacuum Breaker Line |
1 |
|
|
16 |
350-1202
|
Vacuum Breaker 1/2 inch |
1 |
|
|
17 |
350-0485
|
3/4 Vac Breaker Cap SS |
1 |
|
|
18 |
350-1203
|
1/2 Vac Breaker Bonnet Brass Watt |
1 |
|
|
19 |
350-1201
|
1/2 Vac Breaker Repair Kit Watts |
1 |
|
|
20 |
350-1200
|
Nipple Brass 1/2 x Close |
2 |
|
|
21 |
350-1164
|
1/8 Male Plug |
1 |
|
|
22 |
350-1634
|
Mixing Chamber SS CMA 180UC |
1 |
|
|
23 |
350-2225
|
1/2 x 2 1/2 braided hose |
1 |
|
|
24 |
999-0609
|
Nut 1/4-20 hex stainless steel |
2 |
|
|
25 |
350-0477
|
Adapter 1/2 Comp x 1/2 MIP |
2 |
|
|
26 |
350-1424
|
Long Support Bracket |
1 |
|
|
27 |
350-0520
|
SS Braided Hose 7 inch (OBSOLETE) |
1 |
|
|
28 |
350-1599
|
1/2 x 1/8 Bushing Brass |
1 |
|
|
29 |
350-1601
|
Pressure Gauge CMA-180UC/EST Conv |
1 |
|
|
31 |
350-1632
|
Chemical Inlet Check Valve 1/4 inch X 1/8 |
1 |
|
|
32 |
350-2063
|
1/2 Ball Valve Strainer Only |
1 |
|
|
33 |
350-0491
|
1/2 90Deg Street Elbow |
2 |
|
|
34 |
350-0466
|
1/2 Water Solenoid Repair Kit JE |
1 |
|
|
35 |
350-0484
|
Solenoid Coil JE 220V (3/4 & 1/2) |
1 |
|
|
36 |
350-0603
|
10-32 x 3/8 Truss Head Screw |
1 |
|
|
37 |
350-1119
|
Hose Clamp #4 Size #002 SS |
1 |
|
|
38 |
350-2049
|
1/4 Street Elbow 90Deg |
1 |
|
|
39 |
350-0505
|
5/8 Compression Fitting Ring |
1 |
|
|
N/S |
350-2119
|
Plumbing tube |
|
|
|
