| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
350-0568
|
5/16-18 x 5/8 Hexhead Bolt |
4 |
|
|
2 |
350-0590
|
5/16 SS Washer |
4 |
|
|
3 |
350-0574
|
5/16-18 SS Nut |
4 |
|
|
4 |
350-0097
|
Slip Joint Nut Friction Ring Plastic |
1 |
|
|
5 |
350-0080
|
Wash Pump Motor CMA-180UC |
1 |
(includes 4-13, 16 and 17) |
|
6 |
350-0584
|
3/8-16 x 3/4 SS Hexhead Bolt |
8 |
|
|
7 |
350-1247
|
Pump Base Stainless Steel |
1 |
|
|
8 |
350-0093
|
Pump Seal Kit (11/07) |
1 |
|
|
9 |
350-1154
|
Impeller (Open) SS |
1 |
|
|
10 |
350-1248
|
Pump Cover Stainless Steel |
1 |
|
|
11 |
350-0098
|
Slip Joint Nut O-Ring Gasket Buna |
1 |
|
|
12 |
350-1245
|
Compression Nut 2.5 inch |
1 |
|
|
14 |
350-1118
|
Hose Clamp Size #16 1 inch |
2 |
|
|
15 |
350-1132
|
Transfer Hose 1 inch Reinforce 25 inch |
1 |
|
|
16 |
350-1162
|
Pump O-Ring Gasket |
1 |
|
|
17 |
350-0108
|
3/8 Male Plug - Sq Head |
2 |
|
|
