| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
292-5872
|
Suction hose |
1 |
|
|
2 |
292-5873
|
Adapter |
1 |
|
|
3 |
192-6345
|
Nut M6 self locking |
4 |
|
|
4 |
192-0216
|
Washer |
4 |
|
|
5 |
292-5874
|
Pressure spring |
4 |
|
|
6 |
192-5680
|
Pressure spring |
4 |
|
|
7 |
192-0902
|
Snap ring |
2 |
|
|
8 |
292-5875
|
Tank holder |
1 |
|
|
9 |
292-5876
|
Bolt |
2 |
|
|
10 |
292-5877
|
Bolt |
2 |
|
|
11 |
292-5878
|
Tension spring |
2 |
|
|
12 |
192-6475
|
Screw M4 x 12 socket head cap |
4 |
|
|
13 |
192-5942
|
Screw M6 x 16mm raised cheese head torx |
6 |
|
|
14 |
292-5879
|
Right hand lifter |
1 |
|
|
15 |
292-5880
|
Left hand lifter |
1 |
|
|
16 |
192-1872
|
Grease |
1 |
|
|
17 |
292-8528
|
.5ml capsule loctite medium strength thread lock (red) |
1 |
|
|
18 |
292-5881
|
Cable routing |
1 |
|
|
19 |
192-0209
|
Screw M3 x 8 recessed countersunk head |
4 |
|
|
20 |
292-5882
|
Hose bracket |
1 |
|
|
N/S |
192-0902
|
Snap ring |
4 |
(for Tank Holder) |
|
N/S |
292-5883
|
Slider |
1 |
(for Tank Holder) |
|
