| # | Part | Description |
Req | Notes | Availability |
|---|
101 |
292-9423
|
Water regulating set |
1 |
(includes 107-111) (eco) |
|
102 |
292-9424
|
Valve set |
1 |
(includes 112-116) (performance) |
|
103 |
192-1561
|
Screw 60 x 20 torx head |
1 |
|
|
104 |
292-9425
|
Double nipple |
1 |
(without pump) |
|
105 |
292-9426
|
Dosing pump |
1 |
(intellidose+) |
|
106 |
192-1595
|
Screw M40 x 16mm torx head |
1 |
(intellidose+) |
|
107 |
292-9263
|
Valve body |
1 |
|
|
108 |
292-9264
|
Dosing bolt |
1 |
(without pump) |
|
109 |
292-9266
|
O-ring |
1 |
|
|
110 |
192-5369
|
O-ring |
1 |
|
|
111 |
192-1595
|
Screw M40 x 16mm torx head |
1 |
|
|
112 |
292-9263
|
Valve body |
1 |
|
|
113 |
292-9265
|
Plug |
1 |
|
|
114 |
292-9266
|
O-ring |
1 |
|
|
115 |
192-5369
|
O-ring |
1 |
|
|
116 |
192-1595
|
Screw M40 x 16mm torx head |
1 |
|
|
