| # | Part | Description |
Req | Notes | Availability |
|---|
101 |
292-1000
|
Rollerbrush unit 45 |
1 |
|
|
102 |
192-3445
|
Eccentric shaft hex head (black) |
1 |
|
|
103 |
192-2084
|
Bolt |
1 |
|
|
104 |
192-0604
|
Washer M8 |
2 |
|
|
105 |
192-0510
|
Nut M8 self locking |
2 |
|
|
106 |
192-4831
|
Locking lever |
1 |
|
|
107 |
292-9328
|
Lever |
1 |
|
|
108 |
192-6347
|
Screw M4 x 10mm self tapping form |
2 |
|
|
109 |
192-3437
|
Spacer |
1 |
|
|
110 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
1 |
|
|
111 |
292-1001
|
18 inch ultimaxx roller brush |
2 |
|
|
112 |
292-1002
|
18 inch ultimaxx pad roll |
2 |
(optional) |
|
