| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
292-9137
|
Control board set |
1 |
(V1) (PERF standard/ ECO standard) |
|
2 |
292-9138
|
Control board set |
1 |
(V1) (Eco basic) |
|
3 |
292-9483
|
Handle w/ hall sensor |
1 |
(PERF standard) |
|
4 |
192-1595
|
Screw M40 x 16mm torx head |
6 |
|
|
5 |
292-9139
|
Intellitouch |
1 |
(V1) (optional) |
|
6 |
292-9449
|
Switch |
1 |
(V1) |
|
7 |
292-9141
|
Poweruser key |
1 |
(V1) (poweruser) |
|
8 |
N/A
|
Not available |
1 |
(V1) (operator) (use 292-9141) |
|
9 |
192-8848
|
Screw 60 x 25 torx |
4 |
|
|
10 |
292-9484
|
Handle |
1 |
(ECO basic / ECO standard) |
|
11 |
292-9566
|
Ultmaxx intellitouch |
1 |
(V2) (optional) |
|
12 |
292-9567
|
Control board |
1 |
(V2) (ECO Standard/ Perf Standard) |
|
13 |
292-9568
|
Control board |
1 |
(V2) (ECO Basic) |
|
14 |
292-9141
|
Poweruser key |
1 |
(V2) |
|
15 |
292-9570
|
Switch unit |
1 |
(V2) |
|
16 |
192-4662
|
Key ring |
1 |
|
|
N/S |
292-9134
|
Handle |
1 |
(Prior to V1) |
|
