Side/ Front View Assembly

#PartDescriptionPriceReqNotesAvailability
1 286-0086 Hood $307.13 ships same day
2 286-0038 Digital throttle $355.47 ships same day
3 286-0074 Arm weldment $234.22 ships same day
4 286-0076 Wheel stop kit $74.72 ships same day
5 286-0075 Front cover $70.85 ships same day
6 179-0093 Cradle kit $913.32 ships same day
7 286-0052 Hood handle $8.64 ships same day
8 286-0051 1/4 turn slotted latch arm $34.61 ships same day
9 286-0080 Lug nut $11.32 ships same day
10 179-0093 Cradle kit $913.32 ships same day
11 286-0079 Eye bolt $7.15 ships same day
N/S 286-0096 Bolt $2.57 4 ships same day
N/S 286-0097 Washer 5/16 $0.99 4 ships same day
