| # | Part | Description | Price | Req | Notes | Availability |
|---|
5 |
283-1719
|
NUT M8 UNI 5589 ST.STEEL LOW |
$2.58
|
5 |
|
usually ships 6-27 days |
15 |
283-3606
|
Knob |
Call for price
|
4 |
|
usually ships 6-27 days |
17 |
283-1538
|
COMPR. SPRING 26x1.5x30 |
$4.36
|
4 |
|
usually ships 6-27 days |
21 |
283-3608
|
Pin M8 x 60mm |
Call for price
|
4 |
|
usually ships 6-27 days |
25a |
283-3627
|
Right hand splash guard assembly |
Call for price
|
1 |
(includes 25b-25c, 25e-25f, 25h-25o, 5 (1pc)) (right hand) |
usually ships 6-27 days |
25b |
283-1947
|
BUSHING 8x12x58 |
$8.63
|
1 |
|
usually ships 6-27 days |
25c |
283-1737
|
NUT M8 AUTOBL. UNI 7474 INOX LOW |
$2.58
|
1 |
|
usually ships 6-27 days |
25e |
283-3612
|
Spacer |
Call for price
|
1 |
|
usually ships 6-27 days |
25f |
283-9058
|
Right side rubber |
$76.48
|
1 |
(right hand) |
usually ships 6-27 days |
25h |
283-3629
|
Splash guard |
Call for price
|
1 |
(after SN 220000912) (right hand) |
usually ships 6-27 days |
25i |
283-9077
|
Splash guard |
$158.67
|
1 |
(before SN 220000913) (right hand) |
usually ships 6-27 days |
25j |
283-1860
|
KNOB D.30 M6 |
$11.22
|
1 |
|
usually ships 6-27 days |
25k |
283-3611
|
Right hand squeegee blade |
Call for price
|
1 |
(right hand) |
usually ships 6-27 days |
25l |
283-1777
|
WASHER 9X24X2.5 UNI 6593 GALV. |
$3.03
|
2 |
|
usually ships 6-27 days |
25m |
283-2448
|
WHEEL D=80 d=12 H=60 |
$57.38
|
1 |
|
usually ships 6-27 days |
25n |
283-2420
|
VITE M8x20 TBEI ISO 7380 FL INOX |
$7.26
|
1 |
|
usually ships 6-27 days |
25o |
999-9079
|
Screw M8 x 80mm hex head stainless steel |
$4.41
|
1 |
|
ships same day |
25p |
283-3630
|
Left hand splash guard assembly |
Call for price
|
1 |
(includes 25b-25c, 25e, 25j, 25l-25u, 5 (1pc)) (left hand) |
usually ships 6-27 days |
25q |
283-9059
|
Left side rubber |
$76.48
|
1 |
(left hand) |
usually ships 6-27 days |
25s |
283-3613
|
Splash guard |
Call for price
|
1 |
(after SN 220000912) (left hand) |
usually ships 6-27 days |
25t |
283-9079
|
Splash guard |
$158.67
|
1 |
(before SN 220000913) (left hand) |
usually ships 6-27 days |
25u |
283-3614
|
Left hand squeegee blade |
Call for price
|
1 |
(left hand) |
usually ships 6-27 days |
42 |
283-3047
|
SCREW M4x8/8 ISO 7380-2 A2 |
$2.90
|
4 |
|
usually ships 6-27 days |
49 |
283-3282
|
LOCKING WHEEL M8 D=40 S=9 YELLOW |
$12.12
|
4 |
|
usually ships 6-27 days |
50a |
283-3597
|
Side skirt kit |
$228.35
|
1 |
|
usually ships 6-27 days |
50b |
283-3605
|
Splash guard |
$245.55
|
1 |
|
usually ships 6-27 days |
