| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
283-3647
|
Squeegee assembly |
Call for price
|
1 |
(includes 2-13) |
usually ships 6-27 days |
2 |
283-2495
|
BASE WHEEL BUSHING R22 |
$20.51
|
2 |
|
usually ships 6-27 days |
3 |
283-3041
|
BUSHING De=19 Di=14,4 L=10 BRASS |
$16.95
|
2 |
|
usually ships 6-27 days |
4 |
283-3040
|
SQUEEGEE BUSHING |
$58.42
|
2 |
|
usually ships 6-27 days |
5 |
283-3044
|
STUD BOLT M8-M12 CH=13 H=51 - A2 |
$51.37
|
2 |
|
usually ships 6-27 days |
6 |
283-3042
|
SUPPORT BAR M8-M12 CH=13 H=73 - A2 |
$65.40
|
2 |
|
usually ships 6-27 days |
7 |
283-3131
|
SQUEEGEE OUTER BODY L=800 |
$152.00
|
1 |
|
usually ships 6-27 days |
8 |
283-3130
|
Squeegee body |
$41.02
|
1 |
|
usually ships 6-27 days |
9 |
283-1690
|
DOWEL M8X25 UNI 5923 ST.STEEL |
$3.60
|
2 |
|
usually ships 6-27 days |
10 |
283-3027
|
SQUEEGEE LOCK LEVER |
$8.45
|
4 |
|
usually ships 6-27 days |
11 |
283-3046
|
COMPRESSION SPRING De=14 Df=0,9L=25 S |
$12.86
|
2 |
|
usually ships 6-27 days |
12 |
283-3646
|
Blade |
Call for price
|
1 |
|
usually ships 6-27 days |
13 |
283-2496
|
BASE BUMPER WHEEL R22 |
$40.66
|
2 |
|
usually ships 6-27 days |
14 |
283-3047
|
SCREW M4x8/8 ISO 7380-2 A2 |
$2.90
|
4 |
|
usually ships 6-27 days |
15a |
283-3598
|
Squeegee blade kit |
$135.99
|
1 |
|
usually ships 6-27 days |
15b |
283-3645
|
Rubber squeegee assembly |
$235.22
|
1 |
|
usually ships 6-27 days |
