| # | Part | Description |
Req | Notes | Availability |
|---|
2 |
183-9784
|
Washer |
1 |
|
|
3 |
183-9785
|
Gasket |
1 |
|
|
17 |
183-9728
|
Protection sleeve (OBSOLETE) |
2 |
|
|
45 |
183-9786
|
Water tank |
1 |
|
|
46 |
183-9712
|
Water filter |
1 |
|
|
47 |
183-9787
|
Gromet |
1 |
|
|
48a |
183-9788
|
120V pump (OBSOLETE) |
1 |
(before SN 50001) |
|
48b |
183-9789
|
120V pump |
1 |
(after SN 50000) |
|
48c |
183-9790
|
Wire (blue) |
1 |
(after SN 50000) (for 183-9789) |
|
48d |
183-9791
|
Wire (brown) |
1 |
(after SN 50000) (for 183-9789) |
|
49 |
183-9792
|
Gromet |
1 |
|
|
50 |
183-9793
|
Water tank cap |
1 |
|
|
51 |
183-9794
|
Complete control board |
1 |
|
|
53 |
183-9795
|
O-ring |
2 |
|
|
54 |
183-9796
|
Control board cover (OBSOLETE) |
1 |
|
|
55 |
183-9797
|
Push button switch |
1 |
|
|
56 |
183-9798
|
Switch cover |
1 |
|
|
65 |
183-9739
|
Top cover (OBSOLETE) |
1 |
|
|
102 |
183-9799
|
Screw M3.5 x 12 (OBSOLETE) |
7 |
|
|
130 |
183-9800
|
Hose |
1 |
|
|
131 |
183-9771
|
Hose |
1 |
|
|
140 |
183-9776
|
Hose clip 7.5-9.0 |
2 |
|
|
141 |
183-9775
|
Hose clip |
1 |
|
|
160 |
183-9801
|
Filling funnel |
1 |
|
|
