TRIDENT R30SC Axle Assembly

#PartDescriptionPriceReqNotesAvailability
1 283-1153 TUBE $4.29 1 usually ships 26-37 days
2 283-1158 SPACER $8.66 2 usually ships 26-37 days
3 283-1343 BRAKE PEDAL GROUP R28/30 2016 $449.11 1 usually ships 26-37 days
4 283-1344 ACCELERATOR PEDAL GROUP R28/30 2016 $738.68 1 usually ships 26-37 days
5a 283-1008 GEAR MOTOR MRP9D 24V 600W 140RPM+CONN $3,701.47 1 usually ships 26-37 days
5b 283-3118 GEAR MOTOR ELECTROBRAKE (MRP9D 24V) $767.95 1 (after sn 218002044) usually ships 26-37 days
6 283-1378 SPACER $105.92 2 usually ships 26-37 days
7 250-1320 Washer $10.48 2 usually ships 1-5 days
8 283-1457 NYLON CAP D.13 $15.22 1 usually ships 26-37 days
9 283-1497 CENTRAL SPLASH GUARD - C83/O32 $21.67 1 usually ships 26-37 days
10 283-1504 OIL SEAL 32x52x7 $17.60 2 usually ships 26-37 days
11 283-1518 SCREW M6X20 UNI 5739 DIN 933 (8.8) GA $4.58 2 usually ships 26-37 days
12 283-1574 BALL BEARING 6205-2RS(25X52X15) $62.74 4 usually ships 26-37 days
13 283-1614 SCREW M8X20 UNI 5739 DIN 933 (8.8) GA $15.55 2 usually ships 26-37 days
14 283-1646 SCREW M6X20 UNI 5931 DIN 912 (8.8) GA $4.58 10 usually ships 26-37 days
15 283-1657 SCREW $7.35 2 usually ships 26-37 days
16 283-1699 SCREW M6X16 UNI5933 DIN7991 (10.9) Z $4.58 12 usually ships 26-37 days
17 283-1700 SCREW 6X20 UNI 5933 A2 $4.58 4 usually ships 26-37 days
18 283-1765 WASHER 6X12X1.6 UNI 6592 GALV. $4.58 10 usually ships 26-37 days
19 283-1769 WASHER M6 D.24 UNI 6593 LARGE FL. GAL $4.58 2 usually ships 26-37 days
20 283-1770 WASHER 6X2.5X1.8 GROWER GALV. $4.58 12 usually ships 26-37 days
21 283-1779 WASHER 8X13X2.2 GROWER GALV. $4.58 10 ships same day
22 283-1871 PLASTIC CLAMP 4.5X200 $4.93 1 usually ships 26-37 days
23 283-2043 KEY $9.02 2 usually ships 26-37 days
24 283-2109 RIVET FAN SHROUD $2.84 4 usually ships 26-37 days
25 283-2248 SELF-TAPPING SCREW 4,2x13 TC T.C. $2.99 6 usually ships 26-37 days
26 283-2254 SOCKET HEAD SCREW M8x65 ZNT $3.06 6 usually ships 26-37 days
27 283-2260 CUT-OFF $15.11 2 usually ships 26-37 days
28 283-2452 BATTERY BASE ABS DIM. 532X394 $139.51 1 usually ships 26-37 days
29 283-3025 GEARMOTOR SHAFT SUPPORT $211.41 2 usually ships 26-37 days
30 283-3038 WHEEL D=300 d=24 S=85 HUB KEY $814.09 2 usually ships 26-37 days
31 283-3043 LEFT AXLE SHAFT $161.24 1 usually ships 26-37 days
32 283-3045 RIGHT AXLE SHAFT $165.25 1 usually ships 26-37 days
33 283-3052 FRAME $2,788.60 1 usually ships 26-37 days
34 283-3088 PIN D=12 L=158 $80.03 1 usually ships 26-37 days
36 283-3216 SPACER D=40-31 d=24,2 S=11 AVP $32.09 2 usually ships 26-37 days
37 283-3217 SPACER D=40 d=24,2 S=7,5 AVP $29.12 2 usually ships 26-37 days
