| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
278-0323
|
P clamp |
6 |
|
|
2 |
999-9100
|
Washer M5 flat stainless steel |
20 |
|
|
3 |
999-9109
|
Screw M5-.8 x 12mm pan head phillips stainless steel |
9 |
|
|
4 |
999-0953
|
Nut M5-.8 hex nylon insert lock stainless steel |
6 |
|
|
5 |
278-0994
|
Bracket |
1 |
|
|
6 |
278-0995
|
Charger cap |
1 |
|
|
7 |
999-6714
|
Washer M6 x 12mm flat stainless steel |
12 |
|
|
8 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
10 |
|
|
9 |
999-1425
|
Screw M5-.8 x 25mm pan head stainless steel |
4 |
|
|
10 |
278-0412
|
24V 25amp onboard battery charger |
1 |
|
|
11 |
278-0583
|
Onboard battery charger cord (Old style-charger 8132020-US) |
1 |
(old style for charger 8132020-US) |
|
12 |
278-0412
|
24V 25amp onboard battery charger |
1 |
(includes 9-11) |
|
13 |
278-0121
|
Screw |
2 |
|
|
14 |
278-0122
|
Power cord hook |
2 |
|
|
15 |
278-0444
|
Cover |
1 |
|
|
16 |
999-1645
|
Screw M4-.7 x 12mm hex head stainless steel |
4 |
|
|
17 |
278-0085
|
Screw |
2 |
|
|
18 |
278-0668
|
Solution fill cap |
1 |
|
|
19 |
278-0996
|
Solution tank |
1 |
|
|
20 |
278-0029
|
ICE decal |
2 |
|
|
21 |
278-0981
|
Site hose |
1 |
|
|
22 |
278-0066
|
Clamp |
1 |
|
|
23 |
278-0997
|
Left hand decal |
1 |
|
|
24 |
278-0442
|
6AWG jumper cable (black) |
3 |
|
|
25 |
278-0072
|
Battery spacer |
2 |
|
|
26 |
162-0003
|
6V 225Ah wet battery (SNSR) |
4 |
|
|
27 |
278-0998
|
Battery tray |
1 |
|
|
28 |
278-0556
|
Battery boot |
8 |
|
|
29 |
278-0999
|
Front cover |
1 |
|
|
30 |
278-0076
|
Screw |
3 |
|
|
31 |
999-9089
|
Washer M4 flat stainless steel |
5 |
|
|
32 |
278-0078
|
LED light kit |
1 |
|
|
33 |
278-0079
|
LED light base |
1 |
|
|
34 |
999-1671
|
Screw M5-.8 x 20mm pan head phillips stainless steel |
3 |
|
|
35 |
278-0081
|
LED light cover |
1 |
|
|
36 |
278-0468
|
Knob |
2 |
|
|
37 |
278-0141
|
Screw M6 x 30mm |
2 |
|
|
38 |
999-1803
|
Washer M6 flat fender stainless steel |
6 |
|
|
39 |
278-0052
|
Bushing |
2 |
|
|
40 |
278-1000
|
Right hand decal |
1 |
|
|
41 |
278-0082
|
Seal |
1 |
|
|
42 |
278-0083
|
Cover |
1 |
|
|
43 |
278-0084
|
Strap |
1 |
|
|
44 |
278-0925
|
24V 30amp relay |
1 |
|
|
45 |
999-1117
|
Washer M6 split lock stainless steel |
6 |
|
|
46 |
278-0405
|
Insulator |
2 |
|
|
47 |
278-0676
|
Circuit breaker |
1 |
|
|
48 |
278-1001
|
4 inch hinge stainless steel |
2 |
|
|
49a |
278-1002
|
60amp fuse assembly |
1 |
|
|
49b |
278-1003
|
60amp fuse |
1 |
|
|
50 |
278-1004
|
Solenoid switch |
1 |
|
|
51 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
4 |
|
|
52 |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
2 |
|
|
53 |
278-1005
|
Battery connect cable |
1 |
(includes 54) |
|
54 |
278-1006
|
Connector |
2 |
|
|
55 |
278-0681
|
Screw M6 x 36mm |
2 |
|
|
56 |
278-1007
|
Battery connect cable |
1 |
(includes 54) |
|
58 |
278-1008
|
Solenoid switch bracket |
1 |
|
|
