| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-2508
|
Swivel fitting |
1 |
|
|
2a |
375-0204
|
5 foot solution hose |
1 |
(OEM) |
|
2b |
991-1405
|
Vinyl tubing 1/2 x 3/4 (sold by the inch) |
1 |
(NON-OEM)(order qty 60 inches) |
|
3 |
375-0137
|
Plastic fitting |
2 |
|
|
4a |
375-0138
|
In-line filter |
1 |
(includes 4b-4d) |
|
4b |
375-0139
|
Gasket |
1 |
|
|
4c |
375-0140
|
Mesh filter screen |
1 |
|
|
4d |
175-5868
|
Short clear filter bowl |
1 |
|
|
4e |
991-3109
|
Strainer assembly |
1 |
(NON-OEM) |
|
5 |
375-4232
|
Plastic fitting |
1 |
|
|
6 |
375-4617
|
Solution solenoid valve |
1 |
|
|
7 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
2 |
|
|
8 |
375-0136
|
Straight plastic fitting |
1 |
|
|
9 |
275-5197
|
Fir tree clip |
2 |
|
|
10 |
375-0156
|
90 degree elbow |
2 |
|
|
