| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-4532
|
Recovery tank cover with decal |
1 |
(includes 2) |
|
2 |
275-7372
|
SEAL, AFMKT, BULB, DUAL, 08FT [F/.30GAP] |
1 |
|
|
3 |
375-4533
|
Round bar |
1 |
|
|
4 |
375-4534
|
Prop rod mounting bracket |
1 |
|
|
5 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
1 |
|
|
6 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
1 |
|
|
7 |
999-0531
|
Screw M5-.8 x 16mm pan head slotted zinc |
1 |
|
|
8 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
1 |
|
|
9 |
675-9891
|
Spacer |
1 |
|
|
10 |
375-4535
|
Recovery cover plate weldment |
1 |
|
|
11 |
175-3057
|
Bushing |
1 |
|
|
12 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
1 |
|
|
13 |
999-1312
|
Screw M6-1 x 20mm hex head stainless steel |
1 |
|
|
