Squeegee Control Assembly - After 08.2001

#PartDescription ReqNotesAvailability
1 175-3067 Vacuum hose 1 1/2 x 30 inch with cuffs 1
2 175-3068 Squeegee lift cable 1
3 999-0152 Nut 1/4-20 nylon insert lock zinc plated 2
4 999-0687 Bolt 1/2-13 x 1 1/4 hex head stainless steel 1
5 175-3701 Screw 1/2 - 13 x 1 1/4 1
6 999-0559 Washer 1/2 x 1/4 flat stainless steel 6
7 175-2743 Sleeved bushing 2
8 999-1208 Nut 1/2-13 nylon insert lock stainless steel 1
9 275-6137 Squeegee pivot mounting bracket (OBSOLETE) 1
10a 275-4796 Squeegee caster kit 1 (from 09.2001 to 02.2005)
10b 175-8742 Squeegee mount bracket 1 (after 02.2005)
11 999-0050 Nut 1/2-13 hex jam plain finish 2
12 175-3069 Screw 1/2-13 x 5 1/2 1
13a 999-0126 Washer 1/2 split lock 2 (after 02.2005)
13b 999-0278 Nut 5/16-18 nylon insert lock jam zinc plated 2 (from 09.2001 to 02.2005)
14 999-0497 Nut M6-1 nylon insert lock stainless steel 1
15 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 1
16 175-3704 Spring 1
17 999-0786 Screw M8-1.25 x 35mm hex head stainless steel 1
18 999-0553 Washer 5/16 medium split lock stainless steel 2
19 999-0024 Washer 5/16 flat stainless steel 2
20 175-3077 Squeegee lift handle 1
21 175-2723 Handle grip (rubber) 1
22 175-3078 Bushing spacer (OBSOLETE) 1
23 175-2728 Locking plate 1
24 999-0499 Bolt M8-1.25 x 20mm hex head full thread stainless steel 1
25 999-1120 Nut M10-1.5 nylon insert lock stainless steel 2
26 999-0311 Washer #10 external star lock zinc plated 2
27 175-3080 Squeegee lock plate 1
28 275-7544 Mounting plate 1 (FaST model)
29 175-4629 P clamp 2 (FaST model)
30 999-0497 Nut M6-1 nylon insert lock stainless steel 3 (FaST model)
31 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 3 (FaST model)
32 999-0278 Nut 5/16-18 nylon insert lock jam zinc plated 1 (from 09.2001 to 02.2005)
33 991-2013 Wheel 2 (from 09.2001 to 02.2005)
34 175-2830 Spacer 1 (from 09.2001 to 02.2005)
35 275-5175 Bolt shoulder 5/16-18 x 5 1/2 inch 1 (from 09.2001 to 02.2005)
